Page 2 STARTING PEBBELL 2 STARTING PEBBELL™ v2 Thank you for purchasing PEBBELL v2 GPS. PEBBELL v2 is especially built for real time monitoring and can be used in all areas of life from travelling and lone worker protection to specialized care and security services.
Page 3 PEBBELL™ is a registered trademark of HoIP Telecom. Correct disposal of this product: The PEBBELL device(s) should not be disposed with household or other commercial waste. Remove the battery from the device and dispose it according to local battery recycling laws.
Page 4 Never try to disassemble or service the product. Only qualified personnel may repair the product. Use only approved accessories and batteries. Do not connect incompatible battery charger or charge other devices with the PEBBELL GPS charger. A wrong charger may damage the device. -We wish you enjoyable moments with PEBBELL v2-...
Page 5 STARTING PEBBELL 2 RECOMMENDED PACKAGE CONTENT IN UK AC Charger Adapter PEBBELL v2 Desktop Docking Charger USB Charging Cable 4 – www.pebbell-gps.com...
Page 6 STARTING PEBBELL 2 ① GETTING TO KNOW YOUR DEVICE...
Page 7: Device Charging
STARTING PEBBELL 2 ② DEVICE CHARGING The PEBBELL v2 device is equipped with an internal rechargeable battery. The autonomy of the battery may vary depending on the GPS and GSM activity and the use of the device. When charging for the first time use, please fully charge the battery for around 2-3 hours, using the USB charger or the docking station.
Page 8: Switching On The Device
STARTING PEBBELL 2 LOW BATTERY ALARM When the unit’s battery is less than 15%, it will send an SMS alarm “BAT: LOW!” to all authorized numbers. If the battery is less than 15%, the blue light will flash rapidly to advise the user to charge the device as soon as possible.
Page 9 STARTING PEBBELL 2 ⑤ WHAT DO THE LIGHTS MEAN? POWER STATUS - LED Blue ON (solid) Blue blinking quickly Blue OFF or blinking slowly STATE The device is charging Battery power is lower than 15% Device has been fully charged or it’s not charging GSM LED –...
Page 10  Using your mobile phone, send SMS with a text A1 to the phone number of the device. It will reply: “Set mobile number 1 OK!” To delete this number, send command A0 to the Pebbell. NOTE: It is not mandatory for all three of the authorized numbers to be set, however a minimum of one must always be set.
Page 11 STARTING PEBBELL 2 ⑦ ACTIVATING THE SOS “BUDDY” ALARM Press and hold the SOS button for 3 seconds until the device vibrates, after which the green light will start flashing rapidly to confirm the request. Following this, an SOS alarm “Help me” –an SMS message with location coordinates–...
Page 12 STARTING PEBBELL 2 ⑨ RECEIVING A NORMAL PHONE CALL To receive a normal call (only from authorized A1, B1 or C1 numbers), PEBBELL will vibrate.In order to start the call press SOS button. To end the call, press the SOS button.
Page 13 STARTING PEBBELL 2 ⑫ TURNING OFF THE LEDs Send SMS command: LED1 The device will reply “LEDs OFF!” and after a short while the LEDs will stop flashing, but the device is actually on. To turn off this function, send command LED0 to the device ⑬...
Page 14 STARTING PEBBELL 2 ⑭REGUESTING A SINGLE LOCATION 1. Reply with coordinates and web link Send SMS Command: The device will reply. “Time: xxxxx; Lat: xxxx; Lon: xxxx; Spd: xxxxx; Altitude:xxxx Bat: xxx” and a link to Google Maps: maps.google.com/maps?q=48.148838,11.542140 By clicking on the link, the location will be...
Page 15 STARTING PEBBELL 2 2. Reply with Address (not in standard usage) Send SMS command: add The device will reply with an address, e.g. “Add: Coombe Lane, Awbridge, SO51 0HN Hampshire, UK” NOTE: This function needs DATA server function support to activate, for which please contact: sales@hoip-telecom.co.uk.
Page 16  X=No. of Geo-fences (1~3), user can set 3 Geo-fences  Y=0; turn off the function  Y=1; turn on the function  Z=1; set alarm when the PEBBELL enters the preset area  Z=0; set alarm when the tracker breaches the district...
Page 17: Movement Alert
NOTE: xxx must be given in 3 digits. M stands for meters, KM stands for kilometres. PEBBELL must be stationary when setting this function. Example: M1,100M When PEBBELL moves beyond 100 meters, it will send an SMS alarm to the preset numbers. 16 – www.pebbell-gps.com...
Page 18 STARTING PEBBELL 2 To turn off this function, send command M0 to the device. The minimum setting is 100 meters. ⑲ MOTION ALARM Send SMS command: V1,xx S/M/H (Default V0) NOTE: No spaces in between, S stands for seconds, M stands for minutes, H stands for hours, xx stands for the time you set and must be given in two digits.
Page 19 STARTING PEBBELL 2 To turn off this function, send command FL0 to the device. ②① A-GPS Send SMS Command: AGPS1 (Default on) A-GPS serves for accelerated positioning and helping position a device when GPS signals are weak or not available. GPS satellite signals may be impeded by tall buildings and do not penetrate building interiors well.
Page 20 STARTING PEBBELL 2 ②③ GPS SIGNAL LOST AND RECOVERY ALERT Send SMS command: GR1 (Default GR0) The device will automatically send the latest available GPS information to the preset numbers when it enters an area without GPS signal. If the user goes into an area that does not have a GPS signal, such as a tunnel, cave, parking garage etc., the device will...
Page 21 STARTING PEBBELL 2 ②④ CHECKING THE SETTINGS Send command: STATUS device will reply e.g. “A+44xxxxxxxxxx B+44xxxxxxxxxx C+44xxxxxxxxxx; Speed: 0,110km/h; GEO: 0,0,0; VB: 0,0S; MV: 0,0; LBS: 1; LED: 0; Z:0; TZ: 2.0; LI: 0; PS: 1; DS: 0,15M; FL: 1; Bat: 61%;...
Page 22 STARTING PEBBELL 2 ②⑤ DEVICE POWER MODES 1. No Power Saving Mode Send command: PS0 In this mode, both GSM and GPS are on, battery can last 18~36 hours. 2. Smart Power Saving mode Send SMS command: PS1 (Default mode) In this mode, the GSM chip is working and receives calls as well as SMS and transmits location.
Page 23: Reboot Device
STARTING PEBBELL 2 The device can be only activated by movement. Once movement is detected, it will run for the set time (15 minutes) and sleep again if no movement is detected. The battery can last 40 days if there is no movement at all.
Page 24: Hardware Specification
STARTING PEBBELL 2 ②⑧ BUILT –IN MEMORY The device has a built-in 8MB flash memory. It will store the GPS information when there is no GSM network coverage (e.g. very low population density areas, mountainous terrain, and underground areas). The device will transmit GPS locations to the web server automatically once the GSM network is recovered.
Page 25 5%-95% non-condensing ORIGINAL PEBBELL™ v2 WARRANTY The purchaser of the PEBBELL GPS device and its accessories, included in the box as sold, has a limited warranty. HoIP Telecom undertakes that during the period covered by the limited warranty, any defects in...
Page 26: Warranty Period
(hereinafter “Warranty Period”). The different Warranty Periods are: 1. Twelve (12) months for PEBBELL device and three (3) months for accessories (whether included in the device sales package or sold separately). Other than the consumable parts and accessories as listed in “2.”...
Page 27 The original proof of purchase and a copy of the contract subscribing to the PEBBELL LIVE Services, indicating clearly the name and address of the vendor as well as the date and place of purchase.
Page 28 STARTING PEBBELL 2 All parts of the PEBBELL GPS device and its accessories, or any other item replaced by HoIP Telecom shall remain the property of HoIP Telecom. Warranty exclusions 1 – This limited warranty does not cover the user manuals included in the box as sold with the PEBBELL GPS device.
Page 29 Such removal, deletion etc. is to be determined solely by HoIP Telecom. 5 – This limited warranty is not applicable if the socket for charging the PEBBELL GPS device is rusty because the protective rubber cover has not been properly closed.
Page 30 STARTING PEBBELL 2 An estimate will be provided, on request, if the PEBBELL GPS device and its accessories are no longer under warranty or do not comply with the conditions of application of the warranty. To send a request for an estimate for repairs outside the warranty period or where the warranty...
Page 31: Limitation Of Liability
PEBBELL GPS device and accessories will be sent to you. If you do not accept the estimate or fail to reply in the time-frame of one (1) month, the PEBBELL GPS device and its accessories will be returned to you without repairing and the cost of the estimate as well as the cost of dispatching the PEBBELL GPS device and its accessories will be invoiced as a global and lump sum of fifteen (15) GBP, including tax.
Page 32 STARTING PEBBELL 2 However this limited warranty shall not, under any circumstances, exclude or limit your rights under the laws in force in your country or your rights against the vendor of the PEBBELL GPS device and its accessories. Within the limits authorised under current legislation, HoIP Telecom waives all liability with regard...
Page 33 Our web-based tracking system incorporates the TCP/IP protocol and allows users to monitor it in real time over the Internet. If you have a web tracking license, please register your PEBBELL LIVE license at: http://www.pebbell-gps.com/live-registration-2. If you do not have a web tracking license, you can purchase one at: http://www.pebbell-gps.com/apps/webstore/products/show/6670029.
Page 34 STARTING PEBBELL 2 FAQ can be found at: http://www.pebbell-gps.com/apps/blog/...
