INSTALLATION HANDBOOK
Installation of SafetyLink Anchor Points
( Full Installation Guide available from website www.safetylink.com.au)
ROOF ANCHORS
HORIZONTAL LIFELINE
PERMANENT LADDERS
LADDER STABILIZERS
TEMPORARY ANCHOR
Read entire handbook before installing
SafetyLink products. All products must be
installed in accordance with SafetyLink's
installation handbook, using only products
supplied by SafetyLink Pty Ltd. Failure to
follow all warnings and instructions may
result in a serious injury or death.
FROG
EXTRACT FROM
SafetyLink Pty Ltd
AU: 1300 789 545
INT: +61 2 4964 1068
FA X : +6 1 2 4 9 6 4 1 0 6 9
info@safety link.com.au
www.safetylink.com.au
LINK
Advertisement
Table of Contents
Summary of Contents for SafetyLink Froglink anchor
- Page 1 LINK FROG INSTALLATION HANDBOOK EXTRACT FROM Installation of SafetyLink Anchor Points ( Full Installation Guide available from website www.safetylink.com.au) ROOF ANCHORS HORIZONTAL LIFELINE PERMANENT LADDERS LADDER STABILIZERS TEMPORARY ANCHOR Read entire handbook before installing SafetyLink products. All products must be installed in accordance with SafetyLink’s...
- Page 2 APPENDIX – Diagram 2 – Anchor Positioning Layout ............7 LAYOUT EXAMPLE ....................7 IN CASE OF ACCIDENT ....................... 8 Install Installation Video www.safetylink.com.au Catalogue Webinar Guide Installation Terms/Conditions/Warranties Table of Contents SafetyLink Anchor Handbook Extract - FrogLink - Version 08.17 Page 2 of 8...
- Page 3 Visually inspect ladder support brackets for any signs of deterioration or the protective coating being removed. (Note: LadderLink is made from marine grade aluminium and therefore should not corrode). Ensure LadderLink is firmly secured to the structure as per SafetyLink Installation Handbook. (refer to Installing LadderLink).
- Page 4 Products are maintained in accordance with Australian Standard 1891.4 (section 9). you notify any claim under this warranty to SafetyLink in writing to the address below no later than 14 days after the event or occurrence concerning the produce giving rise to the claim and you pay all costs related to your claim.
- Page 5 ➢ For Brownbuilt/Kliplok roof sheeting fix the sheeting down with eight (8) 12 gauge roofing screws into the purlin/batten, four (4) above and four (4) below the FrogLink anchor. ➢ FrogLink is to be installed into the pan, be sure not to create an area where leaves or debris can collect.
- Page 6 2. Drill Seven (7) x 8mm holes into the roof sheets through the locating holes on the FrogLink. 3. Secure the FrogLink to the roof by riveting through the holes in the FrogLink Anchor and the roof sheet using 8mm Gesipa rivets. Use QR code over for video installation.
- Page 7 LAYOUT EXAMPLE THIS IS A GUIDE ONLY All working at heights safety procedures must be complied with when installing SafetyLink anchor points. For more information refer to your state or territories current legislation, regulations, policies and codes of practices. IF ANY DOUBT EXISTS WITH THE STRENGTH OF THE STRUCTURE OR ROOF SHEETS AN ENGINEER SHOULD MAKE THE ASSESSMENT.
- Page 8 PERSONS WORKING AT HEIGHTS SHOULD NOT WORK ALONE. It is critical that before using any SafetyLink Systems a fall rescue plan is in place for any persons suspended mid-air following a fall. Serious injury or death can occur in a matter of minutes, particularly if a person’s movement or breathing is restricted or loss of consciousness has occurred.
