Energy Systems & Design Easy Tune Stream Engine Owner's Manual page 21

21
Note pressure gauge installed by drilling and tapping the T fitting and using a small valve. This allows
removal of the gauge to prevent freezing damage to the gauge.
Following is an example of what NOT to do for a Stream Engine installation. An installation of this sort
will result in a huge loss of power. To optimize the output of the generator all aspects of installation
should be well done. It is important to pay attention to plumbing, nozzle size, intake conditions, siting,
electrical components, as well as regular maintenance.
Do NOT install a stream engine in this manner
WRONG: 90° bends in undersized line
WRONG: Valve smaller than pipeline
WRONG: Same undersized line for both nozzles
