Quick Installation Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the phenom mini-itx and is the answer not in the manual?

Questions and answers

Related Manuals for BitFenix phenom mini-itx

Summary of Contents for BitFenix phenom mini-itx

  • Page 1 Quick Installation Guide...

  • Page 2: Box Contents

    Box Contents • Phenom Mini-ITX Case • Phenom Mini-ITX Quick Installation Guide o Accessories: 5.25" drive bay adapter: x 1 Cable Clip: x 1 o Screws: Thumbscrews M3: x 4 (For 5.25" drive bay adapter) Standard Screw 6-32 Hex: x 4 (For PSU)

  • Page 3: Basic Installation

    Front Back Side Basic Installation Removing side panels Remove thumbscrews Remove side panels...
  • Page 4 Installing 3.5" drives a. Remove hard disk tray b. Install drive by bending rails of tray to the side d. If needed, add extra 6-32*10mm c. Slide tray into place Round screw for increased stability...
  • Page 5 Installing 2.5" drives a. Remove hard disk tray b. Install drive using M3*5mm Round screws c. Slide tray into place...
  • Page 6 Installing 2.5" drives a. Remove FlexCage™ and position b. Secure with screws (M3*5mm Round) drive(s) on PSU cage c. Remove FlexCage™ and position d. Secure with screws (M3*5mm Round) drive on floor...
  • Page 7 Installing 2.5" drives a. Slide drives into place b. Secure with screws (M3*5mm Round)

  • Page 8: Microphone Jack

    A. SuperSpeed USB3.0 ports B. Headphone jack C. Microphone jack D. Reset button E. Power button...
  • Page 9 Top Fan Installation (120mm) Remove top filter Install fans Secure with screws Replace top filter...
  • Page 10 Front Fan Installation b. Install fans (If necessary, remove a. Remove front panel by pushing FlexCage™) tabs from inside chassis c. Secure with screws...
  • Page 11 Rear Fan Installation Install fan Secure with screws...
  • Page 12 FlexCage™ Hard Disk Rack a. Press tabs on HDD cage b. Pull to remove Removing FlexCage™ a. Remove plastic rail b. Remove screws from bottom of HDD cage...
  • Page 13 Rotating FlexCage™ a. Remove and rotate the HDD cage b. Secure screws from bottom of HDD cage c. Rotate the plastic rail and secure d. Insert HDD cage from other side screws...

  • Page 14: Power Supply Installation

    Power Supply Installation a. Remove PSU Back Plate b. Secure PSU Back Plate on PSU Standardscrew 6-32 hex c. Slide PSU into place d. Secure with screws...
  • Page 15 Installing 5.25" drive bay adapter Install device using M3*5mm Round b. Use A or B depending on device screws Slide tray into place d. Secure with screws Thumbscrews M3...
  • Page 16 PSU Filter PSU Filter...
  • Page 17 3F, No.79, Sec. 1, Xintai 5th Rd., Xi Zhi District, New Taipei City, Taiwan, R.O.C. For the most updated information, please visit our official website: http://www.bitfenix.com © 2013 BITFENIX Co., Ltd. All Rights Reserved. All trademarks are registered to their respective owners. Ver 1.0 : 2013/09...
