INSTALLATION INSTRUCTIONS
NEXUS ALTITUDE
NXA-03S
NO PART OF THIS MANUAL OR DOCUMENT MAY BE COPIED OR RE-PRODUCED IN ANY FORM OR BY ANY MEANS WITHOUT THE EXPRESS
WRITTEN PERMISSION OF HAGS-SMP
- W: smp.co.uk -
T: +44(0)845 260 1655
E: sales@hags-smp.co.uk

Advertisement

loading
Need help?

Need help?

Do you have a question about the nexus altitude nxa-03s and is the answer not in the manual?

Questions and answers

Summary of Contents for HAGS nexus altitude nxa-03s

  • Page 1 INSTALLATION INSTRUCTIONS NEXUS ALTITUDE NXA-03S NO PART OF THIS MANUAL OR DOCUMENT MAY BE COPIED OR RE-PRODUCED IN ANY FORM OR BY ANY MEANS WITHOUT THE EXPRESS WRITTEN PERMISSION OF HAGS-SMP - W: smp.co.uk - T: +44(0)845 260 1655 E: sales@hags-smp.co.uk...
  • Page 2 NEXUS ALTITUDE NXA-03S Page 2 ISSUE B 21-01-2013...
  • Page 3 NEXUS ALTITUDE NXA-03S Section 1: x 2= T NXA-03S 4.99 x 4.82 x 3.57 550.0 1.56 11.0 x 10.0 3.0m T = 20h 3416 2766 3288 1502 R1000 TYP R2200 18.4° R2700 R1500 R1500 R2700 R1500 TYP 45° 1374 2000 48.4 m...
  • Page 4 NEXUS ALTITUDE NXA-03S TYPE 1/2 & 3 101/144 4490 3740 3.0 m 18.5° 2695 1770 30° 1520 600 SQ. 30° 1510 30° 1400 2187 90° Section 1 Page 4 ISSUE B 21-01-2013...
  • Page 5 NEXUS ALTITUDE NXA-03S ITEM NXA-03S 92003001 49.00 4200 92003005 24.00 92003010 24.00 92003015 31.00 91010030 11.00 91070010 2.00 ISSUE B 21-01-2013 Section 1 Page 5...
  • Page 6 NEXUS ALTITUDE NXA-03S ITEM NXA-03S 92003020 7.00 91050230 15.00 91070240 3.20 92003025 2.50 91070410 16.5 45032100 47.00 70032701 4.50 45039001 5.80 Section 1 Page 6 ISSUE B 21-01-2013...
  • Page 7 NEXUS ALTITUDE NXA-03S ITEM NXA-03S 45039003 10.50 45039005 13.10 92004005 20.00 91010040 8.00 92002025 2.00 92002020 4.80 92002010 14.30 ISSUE B 21-01-2013 Section 1 Page 7...
  • Page 8 NEXUS ALTITUDE NXA-03S ITEM NXA-03S 92002015 7.80 92002001 43.00 92002005 5.30 92006001 5.80 38008027 1.50 92004010 0.75 91070241 0.42 92004020 0.40 15715000 0.10 Section 1 Page 8 ISSUE B 21-01-2013...
  • Page 9 NEXUS ALTITUDE NXA-03S ITEM NXA-03S 19023802 0.05 19023803 0.05 10121065 0.050 10121040 0.037 10121035 0.032 10121030 0.028 10121025 0.024 10121020 0.020 10120610 0.004 10251016 0.020 ISSUE B 21-01-2013 Section 1 Page 9...
  • Page 10 NEXUS ALTITUDE NXA-03S ITEM NXA-03S 10260600 0.002 10931000 0.020 38001019 0.002 10309999 0.011 10291000 0.002 10301200 0.002 10301000 0.001 19024501 0.001 10121000 10120600 Section 1 Page 10 ISSUE B 21-01-2013...
  • Page 11 NEXUS ALTITUDE NXA-03S STEP 1 ISSUE B 21-01-2013 Section 1 Page 11...
  • Page 12 NEXUS ALTITUDE NXA-03S STEP 2 A X 2 Section 1 Page 12 ISSUE B 21-01-2013...
  • Page 13 NEXUS ALTITUDE NXA-03S ISSUE B 21-01-2013 Section 1 Page 13...
  • Page 14 NEXUS ALTITUDE NXA-03S STEP 3 39 41 1.5° Section 1 Page 14 ISSUE B 21-01-2013...
  • Page 15 NEXUS ALTITUDE NXA-03S STEP 4 A X 2 ISSUE B 21-01-2013 Section 1 Page 15...
  • Page 16 NEXUS ALTITUDE NXA-03S STEP 5 Section 1 Page 16 ISSUE B 21-01-2013...
  • Page 17 NEXUS ALTITUDE NXA-03S STEP 6 ISSUE B 21-01-2013 Section 1 Page 17...
  • Page 18 NEXUS ALTITUDE NXA-03S STEP 7 Section 1 Page 18 ISSUE B 21-01-2013...
  • Page 19 NEXUS ALTITUDE NXA-03S STEP 8 1400 2187 90° ISSUE B 21-01-2013 Section 1 Page 19...
  • Page 20 NEXUS ALTITUDE NXA-03S STEP 9 Section 1 Page 20 ISSUE B 21-01-2013...
  • Page 21 NEXUS ALTITUDE NXA-03S STEP 10 M10 x 25 ISSUE B 21-01-2013 Section 1 Page 21...
  • Page 22 NEXUS ALTITUDE NXA-03S STEP 11 Section 1 Page 22 ISSUE B 21-01-2013...
  • Page 23 NEXUS ALTITUDE NXA-03S STEP 12 M10 x 35 ISSUE B 21-01-2013 Section 1 Page 23...
  • Page 24 NEXUS ALTITUDE NXA-03S STEP 13 M10 x 65 Section 1 Page 24 ISSUE B 21-01-2013...
  • Page 25 NEXUS ALTITUDE NXA-03S STEP 14 TYP . ISSUE B 21-01-2013 Section 1 Page 25...
  • Page 26 NEXUS ALTITUDE NXA-03S Section 1 Page 26 ISSUE B 21-01-2013...
  • Page 27 NEXUS ALTITUDE NXA-03S Appendix A: 9281 6741 2766 2677 1862 ZONE 1 90° 158.4° ZONE 2 ZONE 3 65.2° 2100 2775 5960 6990 7561 9670 ZONE 1 FREEFALL HEIGHT = 3M ZONE 2 FREEFALL HEIGHT = 2.7M ZONE 3 FREEFALL HEIGHT = 2.2M...
  • Page 28 NEXUS ALTITUDE NXA-03S 9650 6529 2796 1306 2694 3167 1256 6325 1967 TYPE 1/2 LOOSEFILL Appendix A Page 28 ISSUE B 21-01-2013...
  • Page 29 NEXUS ALTITUDE NXA-03S 6750 2761 1500 3000 BASE LAYER 7000 3011 1500 1000 SECOND LAYER 10000 TYPE 5 GRASSMATT FR ISSUE B 21-01-2013 Appendix A Page 29...

  • Page 30: Control Measures

    NEXUS ALTITUDE NXA-03S SAFE WORKING PRACTISE A full risk assessment should be carried out prior to commencing the installation, which will be specific to the site selected. The major risks associated with purely the assembly of this product are highlighted below, which can form part of this overall assessment.
  • Page 31 NEXUS ALTITUDE NXA-03S ESTABLISH ORIENTATION See Specifications for equipments ‘Minimum space’. Measure out the site to ensure the space required fits into the allotted area, it is horizontal and free from trip points or other obstructions. iii) Slides must not face south, run down or uphill.
  • Page 32 NEXUS ALTITUDE NXA-03S viii) Offer Slide (item 12) up to Entry Frame (item 4) ensuring the top of the slide rests on the cross member. The walls of the slide must be positioned on the outside of the gussets on the Entry Frame. Shim under the slide feet to set the slide plumb and square, adjust the slide exit to the required height.

  • Page 33: Post Installation Inspection

    NEXUS ALTITUDE NXA-03S xxiii) Attach the Gantry Panels (item 20) to each of the LH & RH Gantry Frames (item 2 & 3) using 7 off M10 x 25 Resistorx bolts (item 37), M10 Tee Nuts (item 42), M12 Shockproof Washers (item 46) and M10 Washers (item 45).
  • Page 34 NEXUS ALTITUDE NXA-03S Appendix A Page 34 ISSUE B 21-01-2013...
