Summary of Contents for iSysmart SGZB11C
- Page 1 ZigBee - Motion Detector with On/Off Switch and Temperature Sensor User Manual Motion Detector with On/Off Switch and Temperature Sensor Model: SGZB11C Firmware: V2.1/V2.2/V2.3/V2.4/2.5 Hardware:V1.0...
- Page 2 1. Introduction ISysmart SGZB11C, an infrared motion On-Off light switch with the temperature sensor, acts as an End Device in ZigBee network. It does not perform permit-join function as a coordinator or a router for other devices to join the network. Users can assign specific ON/OFF task to the binding devices according to different command.
-
Page 3: Product Appearance
2. Product Appearance Indicator (Red/ Green) Binding Key Auxiliary Key Infrared Sensor Light Sensitivity Adjustor Sensor Sensitivity Adjuster Release Button... -
Page 4: Specification
3. Specification Fully IEEE 802.15.4 compliant (ZigBee Pro) Utilizes 2.4GHz ISM band; up to 16 channels Power supply: 2 x ER14505 3.6V AA batteries Operating consumption: ≤ 45mA Standby consumption: ≤ 100uA Temperature Sensing Range: 0~60℃ ... - Page 7 Double-sided stickers tips: 1. Clean two surfaces to stick with. 2. Tear sticker on one side; stick to the position shown product base, and smoothly press it. 3. Rip the remaining side and stick to the clean side of the wall (the direction of arrow shows up ) and press firmly around 20 seconds.
- Page 8 5-2. Join the ZigBee Network After SGZB11C is turned on, it will search for an existing ZigBee network and send a request to join the network automatically. While SGZB11C is under the coverage from a coordinator or a router whose permit-join feature is enabled, SGZB11C will be permitted to join the network.
-
Page 9: Sleeping Mode
A. While the device is in the network → the sleeping period is 5 minutes; it will wake up every 5 minutes to keep online. B. When it doesn’t find a network to join → SGZB11C will go to sleeping mode. It will wake up every 15 minutes to search a network to join. - Page 10 SGZB11C would be in active status for 2 minutes for communication. 5-7. Battery SGZB11C will send a low-power report to the ZigBee network when the operating voltage is lower than 3.2V by default. The related data: Power configuration cluster (ID:0x0001) ...
-
Page 11: Important Maintenance Instructions
Until no additional movement is detected within the period of 120 seconds, SGZB11C will send a light- off message. Users could change the light sensitivity by adjusting the Light Sensitivity Adjuster. Clockwise adjustment → Brighter 5-10. Tamper Alarm SGZB11C features tamper alarm. When the cover is opened, SGZB11C will notify the central security unit, CIE (Control and Indicating Equipment) device, to send a command to a Warning Device. - Page 12 FCC Statement: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
