IDT 89HPES16NT2 User Manual

Pci express switch
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
®
IDT
89HPES16NT2
™
PCI Express® Switch

User Manual

April 2008
6024 Silver Creek Valley Road, San Jose, California 95138
Telephone: (800) 345-7015 • (408) 284-8200 • FAX: (408) 284-2775
Printed in U.S.A.
©2008 Integrated Device Technology, Inc.
