Page 2
! Caution Failure to follow these recommendations may severely reduce the amount of hearing protection provided by the earplugs. • Earplugs comply with EN-352 standard of measurement. • Eartips fit ear canal diameters of 6-13 mm. See Eartip section for details. •...
Page 3
! Caution (continued) of the protection attainable against impulsive noise such as gunfire. • Earplugs must be fitted, adjusted and maintained to the manufacturer’s instructions to achieve the expected attenuation and hearing protection. • Use earplugs at all times in noisy surroundings. •...
Page 4
Identifi cation Eartip Battery 2-Position Door Switch Flexible Protective Case Neck Cord Filter Tool and Filters ™ Cleaning Tool Batteries...
Selecting an Eartip Eartips Frost Gray Long Stem Long Stem Beige Black 3-flange 3-flange Frost 3-flange White 3-flange Foam Foam 7-11mm 8-13 mm 7-11mm 8-13 mm 6-9 mm 8-13 mm Selecting an eartip: No two ears are exactly alike. The eartip that is most comfortable is the best choice, but it must seal well to provide proper protection.
Battery Insertion 1. The battery compartment is located on the underside of the device. Battery Battery 2. Open the battery door. Compartment 3. Remove the yellow tab Battery from the battery. Door 4. Insert the battery with the fl at side facing up. 5.
Insertion & Removal Insertion • Make sure the eartip is clean. • Pull the ear up and out while inserting. • Twist and push gently until the eartip seals in the ear canal. • When using 3-flange eartips, moistening may ease insertion. •...
Operation ON/OFF Earplugs turn on and off by opening and closing the battery door. Note: It is not necessary to remove the battery as long as the door is open wide enough to disable the circuit. Battery Door ON = Closed 15-dB 9-dB OFF = Open...
Batteries Zinc-Air Batteries Use commonly-available #10 zinc-air hearing aid batteries. They are easy to find in pharmacies, online, and at various retail locations. • Zinc-air batteries have a long shelf life, but once the tab is removed, battery life is about 9 days for continuous operation.
Changing Filters Each device has a special filter that enhances sound quality and prevents earwax from entering the device. A filter should be changed if the volume decreases or sound quality declines. Filter Removal Note: Use the tool to remove the filter. 1.
Maintenance Simple cleaning with the tool provided will keep the eartips clean and the devices working properly. • Clean after each use. Wipe clean with a damp cloth. • Do not immerse earplugs in water. • Do not clean with harsh chemicals. Alcohol is not recommended.
Page 12
Noise DECIBELS Reduction Rating (WHEN USED AS DIRECTED) THE RANGE OF NOISE REDUCTION RATINGS FOR EXISTING HEARING PROTECTORS IS APPROXIMATELY 0 TO 30 (HIGHER NUMBERS DENOTE GREATER EFFECTIVENESS) MP915-BN ETYMOTIC RESEARCH, INC. ELK GROVE VILLAGE, IL 60007 Federal law prohibits LABEL REQUIRED BY removal of this label U.S.
Page 13
164/PB/2011/NA dated 20.05.2011 and 202/CR/2012/NA dated 26.04.2012 Passive Attenuation Frequency (Hz) 1000 2000 4000 8000 Mean Attenuation (dB) 25.3 24.0 24.3 25.6 29.6 32.5 34.8 Standard Deviation (dB) APV (dB) 19.4 19.5 18.8 20.9 26.3 28.7 30.8 H = 26 dB M = 21 dB L = 20 dB SNR = 25 dB Active Attenuation –...
Warranty Etymotic will repair or replace defective product at its option if returned within one year of purchase to our designated service facility. This warranty is in lieu of all other warranties, expressed or implied, including, but not limited to, any implied warranty of merchant- ability or fitness for a particular purpose.
