Fourier Multi Log Pro Quick Reference Manual

Integrating student
computing & science
Plug the 1st sensor here

Getting started with MultiLogPRO

Before you first use MultiLogPRO, charge the unit for 10 to 12
hours when turned off.
1. Press the On
2. Plug in the sensors
Start with the first input on the right. If MultiLogPRO is in
Auto ID mode (the default mode – for more details see section
1.2.9 'Configure your MultiLogPRO' in the user guide) it will
display the setup menu and will identify the sensors you've
plugged in.
NOTE: Sensors must be added successively, starting with input-
1. If a single sensor is used it must be connected to I/O-1. If two
sensors are used in an experiment, they must be connected to
I/O-1 and I/O-2.
The arrow indicates that MultiLogPRO is ready to accept a
new sampling rate.
If the MultiLogPRO is in 8 inputs mode you have to select the
sensors manually.
3. Select Rate
input-1 Microphone
input-2 Light
input-3
input-4
RATE= 10/s
SAMPLES= 500
DISPLAY= numeric
w w w . f o u r i e r - s y s . c o m
button
Use the Forward
Backward arrow buttons
to select the desired rate, then
press the Enter
MultiLogPRO automatically
MultiLogPRO
Quick reference guide
moves to the next step in the setup process and the arrow
now points to the "samples" row.
4. Select total number of samples
input-1 Microphone
input-2 Light
input-3
input-4
RATE=
SAMPLES= 500
DISPLAY= numeric
5. Choose display
input-1 Microphone
input-2 Light
input-3
input-4
RATE=
SAMPLES= 200
DISPLAY= numeric
6. Start recording
input-1 Microphone
input-2 Light
input-3
input-4
SAMPLES= 200
DISPLAY= graphic
START=
You can stop recording any time by pressing the Escape
button.

7. The Cursor

46:32.800
displayed automatically after logging has ended.
Use the Forward and Backward arrow buttons to move the
cursor
Zooming: Position the cursor in the area you want to zoom
into.
Press the Forward and Backward arrow buttons
simultaneously. You will zoom in around the cursor in a 2:1
ratio. Press the Forward and Backward arrow buttons again
to zoom in further.
Press the Escape button to zoom out.
and
8. Download data
To download data that was recorded while MultiLogPRO
was not connected to a computer, connect
button.
MultiLogPRO to the computer with the serial or
USB cable, run the MultiLab program and click
Use the Forward
Backward
to select the desired number
Every sec
of samples, then press the
Enter button.
Use the Forward
Backward
to select the desired display,
Every sec
then press the Enter
button.
Press the Forward
button to start recording.
Or press the Enter
if you want to go back to the
(>).
first item (Rate).
Use the Cursor (dotted vertical
line) in Graphic Display mode
to read data values or
to zoom in to the area around
60.5°C
a selected point. The cursor is
™
and
arrow buttons
and
arrow buttons
arrow
button
>>
