Tel +1 (717) 767-6511
Fax +1 (717) 764-0839
www.redlion.net
MODEL DSPZR – DATA STATION PLUS
U L
C
US LISTED
R
IND. CONT. EQ.
34AD
U L
C
US LISTED
FOR USE IN HAZARDOUS LOCATIONS:
R
3PWL
Class I, Division 2, Groups A, B, C, and D
PROGRAMMABLE
CONTROLLERS
GENERAL DESCRIPTION
The DSPZR was designed to act as a nexus for industrial data collection and
management. The unit offers multiple protocol conversion, data logging and
remote machine access. With three built in serial ports and a 10 Base-T/100
Base-TX Ethernet port, the unit performs protocol conversion, allowing
disparate devices to communicate seamlessly with one another. The Ethernet
port supports up to ten protocols simultaneously using C3, so even Ethernet to
Ethernet protocols can be converted.
The DSPZR leverages over 250 communications drivers via three independent
serial ports and an Ethernet port, to connect and collect data from virtually any
PLC, drive, bar code scanner, etc.
The DSPZR's built-in data-logger will log tags at user-programmable rates,
and automatically time/date stamp them. The information is stored in open CSV
file format, allowing you to access them with virtually any application. The
DSPZR can synchronize the log files with any FTP server and/or Microsoft's
SQL Server for further analysis.
DIMENSIONS In inches (mm)
3.35 (85.2)
STS
5.21
(132.4)
CF
review. The files are stored in simple CSV file format allowing common
applications, such as Microsoft Excel and Access, to view and manage the data.
The CompactFlash card may also be used to load new configuration files into
the DSPZR
email and text alerts, and its built-in webserver allows information to be
monitored via any networked PC or smart-phone. If enabled, remote personnel
can take partial or full control of the system remotely, allowing a maintenance
person to effect changes without a site visit.
DSPZR's CompactFlash card as an external drive to your PC. The DSPZR's
DIN rail mounting saves time and panel space and snaps easily onto standard
top hat (T) profile DIN rail.
SOFTWARE
Service Pack 2 or later platforms. The software is an easy to use, graphical
interface which allows the configuration of communications, logging, and
stunning visual displays through simple drag and drop steps.
4.18 (106.1)
CONTENTS OF PACKAGE
CompactFlash is a registered trademark of CompactFlash Association.
1
z PROTOCOL CONVERSION FEATURE CONVERTS NUMEROUS
PROTOCOLS SIMULTANEOUSLY
®
z COMPACTFLASH
SLOT ALLOWS PROCESS DATA TO BE
LOGGED DIRECTLY TO CSV FILES
z VIRTUAL HMI OFFERS BUILT-IN PC-BASED SCADA
FUNCTIONALITY
z 250+ COMMUNICATIONS DRIVERS FOR COMMUNICATING
DIRECTLY WITH PLCs, DRIVES, ETC.
z BUILT-IN WEBSERVER ALLOWS REMOTE VIEW OR CONTROL
FROM ANY INTERNET CONNECTED PC
z PROVIDES EMAIL AND SMS TEXT MESSAGE ALERTS
z SYNCS DATA LOGS TO FTP SERVERS AND MICROSOFT SQL
®
SERVER
z USB HOST CAPABILITY ALLOWS PROGRAMMING AND LOG
FILE STORAGE USING THUMB DRIVES AND ALLOWS
CONNECTION TO OTHER USB DEVICES
z 10 BASE-T/100 BASE-TX ETHERNET CONNECTION CAN
CONNECT TO AN UNLIMITED NUMBER OF DEVICES VIA TEN
PROTOCOLS SIMULTANEOUSLY
The CompactFlash card allows data to be collected and stored for later
The DSPZR extends production monitoring to remote personnel by providing
The USB port may be used for blazing fast file downloads, or to mount the
The DSPZR is programmed with Crimson 3.0 software for Windows
- Data Station
- Terminal Block for connecting power
Bulletin No. DSPZR-D
Drawing No. LP0913
Released 04/15
®
XP
