Summary of Contents for Orion Technology 19MDM
-
Page 1: User Manual
19/21.5/23” MARINE MONITOR TFT-LCD MARINE MONITOR • 19MDM : 19.0inch Marine Monitor • 215MDM : 21.5inch Marine Monitor • 23MDM : 24.0inch Marine Monitor USER MANUAL Please read this manual thoroughly before use, and keep it handy for future reference. - Page 2 19/21.5/23-INCH VALUE TFT-LCD MARINE MONITOR...
-
Page 3: Table Of Contents
INSTRUCTION MANUAL ··············· 01 CONTENTS SAFETY INSTRUCTION ..................CAUTIONS ......................FCC RF INTERFERENCE STATEMENT ............... CONNECTING WITH EXTERNAL EQUIPMENT ........... CONTROL AND FUNCTIONS ................D-SUB CONNECTOR PIN ASSIGNMENTS ............POWER MANAGEMENT ..................SPECIFICATIONS....................TROUBLE SHOOTING GUIDE ................This Monitor was Manufactured by ISO 9001 Certified Factory... -
Page 4: Safety Instruction
02 ··············· INSTRUCTION MANUAL SAFETY INSTRUCTION Important Safety Instruction 1. Read these instructions. 2. Keep these Instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. - Page 5 INSTRUCTION MANUAL ··············· 03 SAFETY INSTRUCTION - The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed no the apparatus. - Minimum distances(e.g. 10cm) around the apparatus for sufficient ventilation. “...
-
Page 6: Cautions
04 ··············· INSTRUCTION MANUAL CAUTIONS ► CAUTION The power supply cord is used as the main disconnect device, ensure that the socket-outlet is located/installed near the equipment and is easily accessible. ► ATTENTIONN Le cordon d`alimentation est utillsé comme interrupteur général. La prise de courant doit être située ou installée à... -
Page 7: Fcc Rf Interference Statement
INSTRUCTION MANUAL ··············· 05 FCC RF INTERFERENCE STATEMENT NOTE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 8: Connecting With External Equipment
06 ··············· INSTRUCTION MANUAL CONNECTING WITH EXTERNAL EQUIPMENT 1. AC POWER IN 2. VGA 3. DVI 1. DVI 2. VGA 3. DC 12V IN... -
Page 9: Control And Functions
INSTRUCTION MANUAL ··············· 07 CONTROL AND FUNCTIONS B. Bottom Key Control B-1. 19 inch 1. SOURCE / Select input source, and move the previous menu. 2. MENU Activates and exits the On Screen Display. This button can also be used to move previous menu or status. 3, 4. - Page 10 08 ··············· INSTRUCTION MANUAL CONTROL AND FUNCTIONS B. Bottom Key Control B-2. 21.5/23 inch 1. SOURCE / Select input source, and move the previous menu. 2. MENU Activates and exits the On Screen Display. This button can also be used to move previous menu or status. 3, 4.
-
Page 11: Osd Menu Description
INSTRUCTION MANUAL ··············· 09 CONTROL AND FUNCTIONS 1. SELF-TEST DISPLAY When there is no connection at PC, the On Screen Display will show for 3 seconds. (POWER SAVING MODE) 2. OSD MENU DESCRIPTION 2-1 AUTO ADJUST Adjust screen size when input is Analog(VGA). 1280 X 1024 64.4kHz 60Hz... - Page 12 10 ··············· INSTRUCTION MANUAL CONTROL AND FUNCTIONS 2-3. COLOR 1) COLOR TEMP. Adjust color temperature to 9300, 6500, user. 2) RED Adjust red color for user. 3) GREEN Adjust green color for user. 4) BLUE 1280 X 1024 64.4kHz 60Hz Adjust blue color for user.
- Page 13 INSTRUCTION MANUAL ··············· 11 CONTROL AND FUNCTIONS 2-6. OSD 1) OSD TIMEOUT. Select the OSD display timing. 2) OSD H.POSITION Move the OSD position to right or left. 3) OSD V.POSITION Move the OSD position up or down. 1280 X 1024 64.4kHz 60Hz 4) OSD TRANSPARENCY...
-
Page 14: D-Sub Connector Pin Assignments
12 ··············· INSTRUCTION MANUAL D-SUB CONNECTOR PIN ASSIGNENTS ► PIN ASSIGNMENTS Pin 1 RED VIDEO GREEN VIDEO SIGNAL CABLE DETECT BLUE VIDEO GROUND GROUND SDA (for DDC) GROUND H-SYNC (or H+V SYNC) RED GROUND V-SYNC GREEN GROUND SCL (for DDC) BLUE GROUND ►... -
Page 15: Power Management
INSTRUCTION MANUAL ··············· 13 POWER MANAGEMENT This monitor features a power management system to “power down” upon receipt of the VESA DPMS(The display power management signaling) from a VESA DPMS video card. The VESA DPMS-compliant video card performs this signaling system through not sending horizontal, vertical, or sync signal. -
Page 16: Specifications
14 ··············· INSTRUCTION MANUAL SPECIFICATIONS 19’’ 21.5’’ 19˝ Diagonal AM-TFT (Active-Matrix) 21.5˝ Diagonal AM-TFT(Active-Matrix) Pixel pitch(mm) : 0.294(H) x 0.294(V) Pixel pitch(mm) : 0.294(H) x 0.294(V) Contrast ratio : 1000:1(Typical) LCD-Type Viewing angle : 170°/160° (H/V) Response time : 5ms (Typ., on/off) Brightness : 250cd/m²... - Page 17 INSTRUCTION MANUAL ··············· 15 SPECIFICATIONS 23’’ 23˝ Diagonal AM-TFT(Active-Matrix) Pixel pitch(mm): 0.248(H) x 0.248(V) Brightness: 250cd/m² (Typical) LCD-Type Contrast ratio: 1000:1(Typical) Viewing angle: 160°/160°(H/V) Response time: 5ms(Typical) 1920x1080@60Hz RESOLUTION (H x V) Horizontal: 31~80kHz FREQUENCY Vertical: 56~75Hz DVI-D INPUT SIGNAL VGA (RGB-PC) 548mm x 330.1 x 54.6mm OUTLINE DIMENSION...
-
Page 18: Troubleshooting Guide
16 ··············· INSTRUCTION MANUAL TROUBLESHOOTING GUIDE TROUBLE TROUBLESHOOTING TIP 1. Check that power cord or the Monitor have been connected securely into wall outlet or grounded extension cable or strip No image on display screen 2. Power switch should be in the ON position and LED is it 3. - Page 20 P/N : L39ME0401 Rev.0...
