Goodway UH684 User Manual

Usb 2.0 4-port
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Safety Instructions

Always read the safety instructions carefully
Keep this User's Manual for future reference
Keep this equipment away from humidity
Lay this equipment on a reliable flat surface before setting it up
If any of the following situation arises, get the equipment checked by a service
technician:
o The equipment has been exposed to moisture
o The equipment has been dropped and damaged
o The equipment has obvious sign of breakage
o The equipment is not working properly or you cannot get it to work
according to User's Manual

Introduction

The USB 2.0 High Speed 4-port hub allows you to add multiple high performance
USB 2.0 peripheral devices to your PC. Moreover, this product is fully backwards
compatible with the USB Revision 1.1 products, which means your previous USB 1.1
devices can continue to function as usual. The USB 2.0 high-speed hub is fully
compliant with the USB 2.0 specification and permits you to connect up to a
maximum of 127 USB devices to your PC through daisy-chain.

Features:

1. Compliant with Universal Serial Bus Specification Revision 2.0 (Data Rate 1.5/
12/ 480 Mbps) and USB 1.1.
2. Supports both OHCI and UHCI.
3. Supports Self-power mode only
4. Include one(1) upstream and four(4) downstream USB ports.
5. One (1) Red LED indicator for Power On LED, and four (4) Green LED
indicators for downstream port status.
6. Supports Plug & Play specification.
7. Over-current detection and protection with LED status indicators
8. Stackable one by one.

User Manual

USB 2.0 4-Port Hub
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UH684 and is the answer not in the manual?

Questions and answers

Related Manuals for Goodway UH684

Summary of Contents for Goodway UH684

  • Page 1: User Manual

    User Manual USB 2.0 4-Port Hub Safety Instructions Always read the safety instructions carefully Keep this User’s Manual for future reference Keep this equipment away from humidity Lay this equipment on a reliable flat surface before setting it up If any of the following situation arises, get the equipment checked by a service technician: o The equipment has been exposed to moisture o The equipment has been dropped and damaged...
  • Page 2 9. Connects up to a maximum of 127 USB devices through cascading multiple hubs System Requirements IBM Compatible Pentium-233 MHz or faster & MAC PCs 64 MB RAM or more PC or MAC with available USB 2.0 port OS support: Win98SE/Win ME /Win 2000/Win XP & Mac 10.1 up. Package Contents USB 2.0 4-Port Hub USB 2.0 Cable...

  • Page 3: Software Installation

    is version 2.0, it will ask for the system’s USB 2.0 driver Software Installation After you connecting this hub to PC by a USB 2.0 cable, the system will detect the device and install the required drivers automatically. Windows System After completing the installation of the USB 2.0 4-Port Hub, go to My Computer and right click to select Properties.

  • Page 4: Led Indicators

    LED Indicators The 4 Port iStack USB 2.0 Hub is equipped with LED indicators: LED Indicator (red): The indicator lights up red when the USB 2.0 Hub is receiving power from its external power source. LED Indicator (green): Each port has one status LED. When the LED is on the downstream port means it is ready to use.
  • Page 5 Magnet Screws Stand U-shaped metal A. Vertically Figure 2 Figure 1 Track Bottom Track Long Top Cover Track Track Clipper Clipper Short Stopper 1. Push the USB 2.0 Hub from A all the way 2. Push the USB 2.0 Hub all the way in down until you meet the stopper.
  • Page 6 C. Fastening Magnetically You can secure the USB 2.0 Hub on the computer table or steel frame. Figure 4 Figure 5 Screw Bottom Magnet Magnet U-shaped Stand Metal Screw Bottom Magnet Stand Bottom Magnet U-shaped metal 1. Please follow these figures in order and 2.
  • Page 7 D. Fastening with Screws Figure 6 1. Secure the stand to the desk and fasten the screws on both side of the stand. 44 mm Screw * Package doesn’t in clude screws for the desk. 2. Slide the USB 2.0 Hub into the stand. Do the same for both vertically and horizontally Figure 6 placed hubs.
  • Page 8 DISCLAIMER formation in this document is subject to change without notice. The manufacturer oes not make any representations or warranties (implied or otherwise) regarding the ccuracy and completeness of this document and shall in no event be liable for any loss of profit or any commercial damage, including but not limited to special, incidental, con sequential, or other damage.
