Fiscal module FM3000

Service manual

Table of Contents

Need help?

Do you have a question about the FM3000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Varos FM3000

Page 1 Fiscal module FM3000 Service manual (c) VAROS...
Page 2: The Conditions For The Certificate Acknowledgement
CD ROM for e.g. 3. General information The device is introduced under a business name FM3000. Device FM3000 is an intelligent fiscal module with its won processor that communicates with the computer through serial interface RS232 or USB 2.0 interface.
Page 3: Attributes Of The Fiscal Module
ESC sequences, it informs FM3000 about their importance. Said in the other words, if you are satisfied with your current business managing software and the program providers are willing to modify printing output slot in accordance with this guide, the installation of FM3000 is and ideal solution for you.
Page 4 Fiscal module has own timer ( real time clock – RTC). Date and time printed on particular receipts is automatically supplied from internal timer. Picture No.1. Block diagram of the fiscal module Main module Procesor Program Memory Memory Timer Input Output EEPRO RS232 Centronics Output Input Output Output cash USB2.0 RS232 RS232 Fiscal module FM3000 3/33 www.varos.sk...
Page 5 Storage 200 monthly balances per program Storage 3,000 daily balances per program Storage of receipts (30,000.00 receipts, maximum 50 MB of electronic tape) Picture No. 4: Cooperation of the fiscal module with other devices Fiscal module FM3000 Input Input Output Output Output...
Page 6 OUTPUT PRINTER Centronics Fiscal module FM3000 is extending input/output module. Extended with USB 2.0, input to serial printer, connector to connect cash display RS232, connector for cash drawer opening with 12-24V coil. Meaning of the connectors SW1 - data protection in EEPROM...
Page 7 ON - LED is on, OFF – LED is off LED1 LED2 LED3 Condition of fiscal module FM3000 The MMC memory does give any response or is not initialised. Normal situation. Module is OK printer is connected. Timer error. Printer is in mode BUSY. Test is performed before each printing.
Page 8: Features Of Communication Ports
Data terminal ready. „0“ - PC informs of ability to receive from fiscal module (module can send data to PC only if „0“ state is detected on this pin). Output Call on transmission Input Readiness for transmission Input Calling indicator Fiscal module FM3000 7/33 www.varos.sk...
Page 9 Classical cable so called Centronics cable is used for connection. On side of module is connector Cannon 25PIN/F (female) and on printer side is connector MC36SP. ! Never use other type of interface than specified! ! Connect the port only when power off! Fiscal module FM3000 8/33 www.varos.sk...
Page 10 Connector RJ45 connects cash register display to fiscal module. From connector RJ45 comes outlet of serial port RS232. Data to be shown on display are sent with prefix ESC “>” (see programmer manual) DESCRIPTION 1, 2 Display feeding voltage 5V 3, 4 Fiscal module FM3000 9/33 www.varos.sk...
Page 11: Programmer Manual
8. Programmer manual Control of fiscal module FM3000 is very similar to control and driving of printers. It means that it has defined operate characters called also ESC sequences. All defined functions are called by these sequences. Programmer does no program heading, tax number, cash register number, he/she also does not calculate daily, monthly and annual balances nor calculates tax on receipts.
Page 12 - character 0A <H> = 10 <D> enter - character 03 <H> = 3 <D> end of chain - character 0C <H> = 12 <D> pagination <H> - hexa symbol value <D> - decimal symbol value Fiscal module FM3000 11/33 www.varos.sk...
Page 13: Balance And Auxiliary Esc Sequences
________ C U M M U L A T E D ________ defined in receipt the GT1 Gross: 2190.00 summary of them will be printed Max. 5 GT2 Net: 1690.00 GT3 Negative: 500.00 Cumulated values of ____________________________________ grand totals from last annual balance Fiscal module FM3000 12/33 www.varos.sk...
Page 14 ____________________________________ annual balance Note: Monthly balance automatically controls accomplishing of daily balance. If user forgets to accomplish last daily balance after calling monthly balance device will automatically accomplish daily balance first. Fiscal module FM3000 13/33 www.varos.sk...
Page 15 M. of pay. 1: 1190.00 ________ C U M U L A T E D ________ Cumulated values of GT1 Gross 1490.00 grand totals from last GT2 Net: 1190.00 annual balance GT3 Negative: 300.00 ____________________________________ Fiscal module FM3000 14/33 www.varos.sk...
Page 16 Annual balance automatically controls accomplishing of monthly and daily balance. If Note : user forgets to accomplish last daily or monthly balance after calling monthly balance device will automatically accomplish daily and monthly balance first. Fiscal module FM3000 15/33 www.varos.sk...
Page 17 MM - month of document issuance <01 - 12>. It has to contain two digits. DD - day of document issuance <01 - 31>. It has to contain two digits. yyyy - number of cash receipt <1-9998>. Fiscal module FM3000 16/33 www.varos.sk...
Page 18 Note: Fiscal module has its own timer that is not depending from the feeding voltage. This sequence is used when is synchronized time with PC or when is change to daylight saving and vice versa. Fiscal module FM3000 17/33 www.varos.sk...
Page 19 Description : After sending of this sequence fiscal module gives back information, it provides identification data: name of fiscal module "FM3000" and firmware version /2Byte/. The new firmware version can be burnt into module with the help of service program.
Page 20 Fiscal module does not process text chains; it only redirects them to cash register display Redirecting is automatically ended after characters ETX are received. It is possible to use Note: sequence also in the framework of cash register document. Fiscal module FM3000 19/33 www.varos.sk...
Page 21 Fiscal module does not erase balances. Function is used after are cash sale document downloaded to PC and stored on DVD or CD medium. Note: Deletion of cash receipts is possible to perform only after daily balance accomplishing. Fiscal module FM3000 20/33 www.varos.sk...
Page 22: The Creating Of The Cash Register Receipt
Date and time is printed after sequences ESC b. · The body of the receipt itself consists of the particular items of the goods. The sum for the particular goods should be preceeded by ESC sequence, which informs fiscal Fiscal module FM3000 21/33 www.varos.sk...
Page 23 Payment with various means of payment is printed in the footing of cash receipts. Cumulated values are in daily and running balances. ESC P 1 - information about payment with mean number 1 Fiscal module FM3000 22/33 www.varos.sk...
Page 24 (cancelled/discount/negative items), about mean of payment (Cash/Bank card/Meal tickets/Cheques/EURO. These information uses fiscal module during summary, daily and monthly and running balances. Means of payment are also printed in cash receipts. Fiscal module FM3000 23/33 www.varos.sk...
Page 25 The length of one receipt line is not limited. So it is possible to use for receipts printing wide paper and documents can be wider than 40 characters. Document printed by fiscal module printer: According to ESC b fiscal module Product of VAROS union prints graphic and text heading, 53 Rudlovska cesta AURIS ordinal receipt number/or...
Page 26 ; customer ESCe ; End of cash receipt Document printed by printer connected to fiscal module Product of VAROS union According to ESC b fiscal module prints 53 Rudlovska cesta AURIS graphic and text heading, ordinal receipt 974 01 Banska Bystrica...
Page 27 ESCe ; End of cash receipt Document printed by printer connected to fiscal module According to ESC b fiscal module Product of VAROS union prints graphic and text heading, 53 Rudlovska cesta AURIS ordinal receipt number/ordinal 974 01 Banska Bystrica...
Page 28 ..; about customer ESCe ; End of cash receipt Document printed by printer connected to fiscal module Product of VAROS union 53 Rudlovska cesta AURIS 974 01 Banska Bystrica DIC :1020555294 IC VAT:SK1020555294 DKP: xxxxxxxxxxxx Document: 4/1 Date:25.05.2004 Time:10:45...
Page 29 ; End of cash receipt Document printed by printer connected to fiscal module According to ESC b fiscal module prints graphic and text heading, Product of VAROS union ordinal receipt number/ordinal 53 Rudlovska cesta AURIS number of daily balance, where will...
Page 30 ; Change of font type Goods 1 10pcs 10.00 ESC1 100.00 Sk<CR><LF> ; Positive item tax 1 ESC> "shows item on display connected to FM3000" ETX ; Sending the text on display Goods 3 10pcs 10.00 ESC3 100.00 Sk<CR><LF> ; Positive item tax 3 ESC>...
Page 31 Document printed by printer connected to fiscal module Product of VAROS union 53 Rudlovska cesta AURIS 974 01 Banska Bystrica DIC :1020555294 IC VAT:SK1020555294 DKP: xxxxxxxxxxxx Document: 4/1 Date:25.05.2004 Time:10:45 --------------------------------------------------------- Name Pcs Prc/PU Tax Goods 1 10pcs 10.00 19% 100.00 Sk...
Page 32: Error Messages Of Receipt Printing
LED2 LED3 Text of error message printed by printer Error 1 - MMC memory * Normal state FM3000 is OK, printer is connected. Error 2 - Timer error * Printer is in state BUSY Error3 - EEPROM error * Loading of turnover from issued receipts in MMC memory MASTER RESET ZAC / MASTER RESET END / FLASH * Fiscal module is not connected to feeding voltage.
Page 33: Cash Register Book
DB or MB are simply in particular balances printed by fiscal module. We recommend to fill out values of daily balance in new page (you can check comparison MB with DB for each month). Fiscal module FM3000 32/33...
