Slide & Photo Scanner
Please read and retain these instructions for future reference
PLEASE SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
Package contents:
 Film & photo scanner
 USB cable
 Negative film holder
 Positive holder
 4 in 1 photo tray (with brackets)
 OCR CD (not pictured)
 AC/DC adaptor (not pictured)
 User manual (this manual)
 4GB SD card
General notes:
 Do not expose this product to water or any moisture.
 Do not disassemble this unit.
 To prevent the risk of electric shock, do not remove cover.
 Do not block ventilation openings as this could cause unit to overheat.
 The scanner should be stored and used away from high sources of heat such as
radiators, fires and ovens.
 Clean the glass of the slide holder using a clean, dry, non-alcohol cotton swab. Wipe
over the body of the unit using a clean dry cloth.
 The USB cable should be unplugged from your computer when not in use.
 Overloading the USB connections on your computer will seriously diminish the
operational capacity of the device.
 If the unit fails, please return to the retailer or have it reviewed by a qualified service
engineer.
 The design of the film holder follows ISO standards (International Organisation for
Standardisation). In some cases the holes on the film will not exactly match the
alignment of the holder. In this case there will be a small black line on the edge of
the frame. This can be easily cropped out using photo edit software.
 In the interest of conserving energy and protecting the environment, the device will
power off automatically after 30 minutes.
Note:
The unit does not power off automatically whilst in playback or USB mode.
Instructions for Use
10084
v003:15/03/17

Advertisement

loading
Need help?

Need help?

Do you have a question about the 10084 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Coopers 10084

  • Page 1 Slide & Photo Scanner Instructions for Use 10084 Please read and retain these instructions for future reference v003:15/03/17 PLEASE SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE. Package contents:  Film & photo scanner  USB cable  Negative film holder  Positive holder ...
  • Page 2 Slide & Photo Scanner Instructions for Use 10084 Please read and retain these instructions for future reference v003:15/03/17  Please unplug the adaptor from the mains when not in use. Loading slides:  Hold up the slide to the light with the trademark side of the slide away from you.
  • Page 3 Slide & Photo Scanner Instructions for Use 10084 Please read and retain these instructions for future reference v003:15/03/17  Position the brackets according to the marked dimensions on the photo tray.  Place the brackets into the slots and slide the brackets downwards to secure.
  • Page 4 Slide & Photo Scanner Instructions for Use 10084 Please read and retain these instructions for future reference v003:15/03/17 1 = Language mode 2 = USB mode 3 = Capture mode 4 = Playback mode 5 = Film type 6 = Resolution ...
  • Page 5: Mirror/ Flip

    Slide & Photo Scanner Instructions for Use 10084 Please read and retain these instructions for future reference v003:15/03/17 Adjusting brightness and colour of image  You can adjust the brightness and the colour of an image in capture mode.  When in capture mode, press Enter button. The following screen option will appear: EV means brightness;...
  • Page 6 Slide & Photo Scanner Instructions for Use 10084 Please read and retain these instructions for future reference v003:15/03/17 Capture - save, cancel or home 1= Save captured image 2 =Cancel editing to image 3 =Home takes you back to main menu ...
  • Page 7 Slide & Photo Scanner Instructions for Use 10084 Please read and retain these instructions for future reference v003:15/03/17 Playback: audio slide selection  Only images captured by the film and photo scanner are available in playback mode.  The screen will automatically display all images stored in the internal memory or memory card with 2 second intervals between each.
  • Page 8 Slide & Photo Scanner Instructions for Use 10084 Please read and retain these instructions for future reference v003:15/03/17 1 = Negative film 2 = Slides 3 = B&W  When the film scanner mode is selected, you can change the film type by scrolling through film options and pressing enter to confirm your selection.
  • Page 9 Slide & Photo Scanner Instructions for Use 10084 Please read and retain these instructions for future reference v003:15/03/17 1 = 5M resolution 2 = 10M resolution Language  Select the language option from the main menu.  Scroll through language options, then press Enter to confirm your selected language.
  • Page 10 Slide & Photo Scanner Instructions for Use 10084 Please read and retain these instructions for future reference v003:15/03/17 Technical Specification Lens 2G3P F/NO=3.97, f=4.04 Film Range: 51:5mm, F/NO = 4 f=3.93 Photo Range:170mm Sensor 5.1 mega pixels CMOS sensor 2.4 inch LTPS LCD display...
