Co-pilot DAB-011 Instruction Manual

In-car dab & fm transmitter

In-Car DAB & FM Transmitter DAB-011

Features:

1. Wireless transmission for DAB+/DAB radio to your existing car

radio amplifier by FM transmission technology

2. Quick SCAN to search the next available free DAB stations/FM frequency

3. FM transmitter function is combined in this model

4. Line-out function, to get the best sound quality through connecting to Car's Aux-in.

5. With 2.1AMP charging function, charge your mobile devices on the way.

6. Draws power from the car's cigarette lighter.

7. With goose neck easy to adjust the angle of the device

8. Solution: Silicon labs

9. With service following

10. With RDS

11. Supports language: English, Deutsch and Norwegian

1. Frequency range: DAB Band III 174-240MHz.

2. FM transmit range: 87.6-107.9MHz.

3. Output Connectors: 3.5mm stereo output connecting to car stereo aux-in (if available).

4. LCD display: 37*23mm

5. Car Charge output: 5V/2.1AMP

CAUTIONS:

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE ANY COVER. NO USER-

SERVICEABLE PARTS INSIDE, REFER ANY SERVICING TO A QUALIFIED SERVICE PERSONNEL.

1. Read and keep these instructions available for future reference.

2. To reduce the risk of fire or electrical shock, do not expose this unit to rain or moisture.

The apparatus should not be exposed to dripping or splashing.

No objects filled with liquids shall be placed on the apparatus.

Instruction Manual

Table of Contents

Do you have a question about the DAB-011 and is the answer not in the manual?

Page 1: Instruction Manual
In-Car DAB & FM Transmitter DAB-011 Instruction Manual Features: 1. Wireless transmission for DAB+/DAB radio to your existing car radio amplifier by FM transmission technology 2. Quick SCAN to search the next available free DAB stations/FM frequency 3. FM transmitter function is combined in this model 4.
Page 2 Take care that liquids are not spilled onto the product 6. If this should happen, refer to qualified service personnel before attempting to use. 7. Do not install near any heat source, such as radiators, or other equipment that produces heat. To clean the DAB-01 1 radio, wipe the case with a slightly moist, lint-free cloth.
Page 3 3. It will perform a Full Scan of DAB stations automatically within 5 seconds after “Full scan” shows on the display 4. Press TX button on the DAB-011 will get to the “FM Transmit Mode” and the screen will show the current FM transmitting frequency, make a note of that number. You can change to other frequencies manually to suit better to the district you are driving in.
Page 4 USING THE AUX OUTPUT To get better sound quality, you can use the LINE OUT function below: Connect the AUX connect wire (included) from the out jack of the DAB-011 car adaptor to the AUX input jack of your car.
