Summary of Contents for NXT Digital CH-1000M
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS 1. Read, follow and keep these instructions safely. 2. Heed all warnings. 1. Do not use this apparatus near water. 2. Clean only with dry cloth. 3. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. -
Page 3: Technical Specifications
TECHNICAL SPECIFICATIONS AREA SPECIFICATION Input Frequency 47 ~ 862 MHz Tuner Input level range 47 ~ 64 dBuV Input Impedance 75 ohm CODEC MPEG-2 MP@ML, H.264 Video Output system Video Resolution 720 x576 90 ~ 270Vac, 47~63Hz Input voltage Adaptor 5V DC power supply Output voltage Rated output Power... -
Page 4: Front Panel
FRONT PANEL 1. USB Interface 2. Remote sensor/ status indicator REAR PANEL 1. Input, CABLE IN. link with cable 2. 3. Terminals AUDIO. L/R 4. Terminal, VIDEO 5. DC IN for power supply input. DC 5V. 6. RESET button for restoring STB to factory settings... -
Page 5: Remote Control
INFO. Display program synopsis & information window LIST. Display channel list VOD. Video on demand services VAS. NXT DIGITAL value-added services REC. Start program recording REW. Rewind program recorded on the personal video recorder ... -
Page 6: Preparation Of Remote Control
PREPARATION OF REMOTE CONTROL 1. Open the battery cover. 2. Insert the batteries in the correct direction. Please ensure that the anode and cathode ends of the battery are corresponding to the polarity indicated in the remote control. 3. Replace the battery cover. OPERATION SCOPE OF THE REMOTE CONTROL Point the remote control towards the Set Top Box in order to control the apparatus, ensuring that the Set Top Box is not... -
Page 7: System Connection
SYSTEM CONNECTION Use the RCA video cable supplied with this apparatus for connecting to the television. RF Cable Connection 1. Prepare your equipment Make sure that your TV has VIDEO, AUDIO R, and AUDIO L input connections which are usually located at the back or side of the television (yellow, red and white connectors). -
Page 8: The First Time Using This Receiver
Set Top Box to your personal setup. When the STB is powered ON from your mains electricity supply, it will display the NXT DIGITAL Splash Screen. A pop-up will come on the screen after the Set Top Box has booted up. Check that your cable is properly connected to the Set Top Box (see above) and press OK. -
Page 9: Manual Installation
MANUAL INSTALLATION If you are facing problems installing channels automatically you can try manual installation of the Set Top Box (this procedure is reserved for trained engineers or the Service Center). ● Navigate to the Main menu (hit “Menu” key on the remote control) ●... - Page 10 USING THIS SET TOP BOX RECEIVER Using your Set Top Box While watching your favorite TV programs you can press the “Info” button at any time to get information on the current TV channel. By pressing “Info” twice you can display more details on the program content.
- Page 11 appear asking “Do you want to factory reset?”. Press OK button and enter the PIN number for the Set Top Box. The default PIN number is “0000”. ● DELETE ALL CHANNELS – Navigate to the Installation menu and select “Delete All Channels”...
-
Page 12: Frequently Asked Questions
FREQUENTLY ASKED QUESTIONS Why does my Digital Set Top Box not show the POWER ON indicator? Check that the 5V DC Adaptor is properly connected to +5V DC Input of your Digital Set Top Box. Check the mains supply is switched on. Why am I not able to see Video (Picture) on my Television? Check for proper connection of cables to your Set Top Box and on the back of the television. - Page 13 ● Do not allow any kind of liquid to come in contact with the Set Top Box. ● Please refer to the troubleshooting tips to resolve any problems with the Set Top Box. ● Only NXT DIGITAL trained personnel are authorized to conduct repairs. Non- compliance can result in the warranty being null and void.
-
Page 14: Troubleshooting
TROUBLE-SHOOTING Problem Possible causes What to do Power cord is not Check that the power cord is plugged connected. in to the mains supply. The indicators on the front panel do not light up Power adapter may be Check whether the power adapter is faulty.
