Summary of Contents for UDP Technology NVE40K

  • Page 1 NVE40K Hardware Manual...

  • Page 2: Table Of Contents

    NVE40K Hardware Manual Table of Contents 1. Introduction ............................5 2. Subrack .............................. 6 2.1. Specifications ..........................6 2.2. Unit view ..........................7 2.3. Mechanical characteristics ......................9 3. NVE blade ............................10 3.1. Specifications .......................... 10 3.2. Unit view ..........................10 3.3.
  • Page 3 NVE40K Hardware Manual Safety and Regulatory Information WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. THE APPARATUS MUST NOT BE EXPOSED TO DRIPPING OR SPLASHING AND NO OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES, SHOULD BE PLACED ON THE APPARATUS.
  • Page 4 NVE40K Hardware Manual CE COMPLIANCE This is A class product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. UDP Co., Ltd.

  • Page 5: Introduction

    NVE40K Hardware Manual 1. Introduction NVE40K compress video/audio data and transmit the compressed video/audio data through the network in real time. NVE provides a high quality video image with a limited bandwidth and storage capacity. These products are ideally suited for a wide range of surveillance and remote monitoring applications.

  • Page 6: Subrack

    NVE40K Hardware Manual 2. Subrack 2.1. Specifications NVE40K and NVE4000A-R specification is shown as following Construction Aluminum, 19” / 4U Sub-Rack Applied Device NVE4000A-R Available Slots 10 ea (Hot Swappable Blades) Power Input 85 ~ 264 VAC, 47~63Hz, 2A Type...

  • Page 7: Unit View

    NVE40K Hardware Manual 2.3. Unit view Figure 1. NVE subrack UDP Co., Ltd.
  • Page 8 NVE40K Hardware Manual Figure 4 Figure 3 Figure 5 Ethernet 1 Ethernet 2 Ethernet 3 Ethernet 4 Ethernet 5 Ethernet 6 Ethernet 7 Ethernet 8 Ethernet 9 Ethernet 10 USB 1 USB 2 USB 3 USB 4 USB 5 USB 6...

  • Page 9: Mechanical Characteristics

    NVE40K Hardware Manual 110-220V~ 50/60Hz PSU2 PSU1 Figure 4. Detailed rear view of subrack (power cord) RACK ID Figure 5. Detailed rear view of subrack (RACK ID) 2.4. Mechanical characteristics Mechanical characteristics of subrack: Dimension Width (inch): 19 " Height (U): 4 U Depth (mm): 288 mm UDP Co., Ltd.

  • Page 10: Nve Blade

    NVE40K Hardware Manual 3. NVE blade 3.1. Specifications NVE4000A-R 4ch MPEG-4 100/120fps@D1 Single Mode Dual Mode Input channel Output Channel 1 Quad 2 Loop Out Compression MPEG-4, MJPEG Selectable per Channel Resolution D1, 2CIF, CIF, QCIF Compression FPS 100/120fps@D1 Input/Output Channel...

  • Page 11: Mechanical Characteristics

    NVE40K Hardware Manual Figure 6. NVE blade Figure 7. Front, top, side view of a blade 3.3. Mechanical characteristics Mechanical characteristics of a blade: Dimension (Unit: mm): 30.1 (W) x 128.4 (H) x 220 (D) 3.4. Ejecting and inserting blades Ejecting a blade UDP Co., Ltd.

  • Page 12: Inserting A Blade

    NVE40K Hardware Manual 1. Unscrew four collar screws. 2. Grasp the inject/eject handle of the blade and push it down as shown in below figure. 3. Remove the blade from the rack. Figure 8. Ejecting a blade Inserting a blade 1.

  • Page 13: Rebooting

    NVE40K Hardware Manual 3.6. Rebooting Reset can be carried out as follows: 1. Press Reset for 1 second. When Reset function is activated, Status LED and Network LED will blink together, twice. User may stop pressing Reset at this point.

  • Page 14: Power Supplier Unit

    NVE40K Hardware Manual 4. Power Supplier Unit 4.1. Specifications AC/DC Switched Mode Power Supplier Unit (PSU) 19" 3U Rack Mountable, 10HP, DC12V, 150W 4.2. Unit view Figure 9. Power supplier unit UDP Co., Ltd.

  • Page 15: Electrical Characteristics

    NVE40K Hardware Manual 4.3. Electrical characteristics Specification for only Power supply Parameter Units Value Nominal Output Voltage Maximum Output Current Maximum Output Power Efficiency(Typical) (*1) 100V AC 200V AC Input Voltage Range (*2) 85~265VAC(47~63Hz) Input Current(Typical) (*1) 1.9/0.95 Inrush Current(Typical)

  • Page 16: Environmental Characteristics

    NVE40K Hardware Manual 4.4. Environmental characteristics Parameter Units Value Operating Temperature (*1) -10~+60℃ (-10~+40℃:100%, +50℃:60%, +60℃:20%) Operating Humidity 30~90%RH (No Dewdrop) Storage Temperature -30~+85℃ Storage Humidity 10~95%RH (No dewdrop) - NOTE - *1. Load (%) is percent of maximum output power or maximum output current, whichever is greater.

  • Page 17: Pin Description

    NVE40K Hardware Manual 4.6. Pin Description Mating Connector: DIN61412-H15 Female Pin # Signal Name Output +12V DC OUTPUT Sense +V Assorted Signal Sense 0V Output 0V DC OUTPUT AC LINE AC INPUT AC Neutral Figure 11. Pin connection of PSU...

  • Page 18: Ejecting And Inserting Psu

    NVE40K Hardware Manual 4.7. Ejecting and inserting PSU Ejecting a PSU 1. Unscrew four collar screws. 2. Grasp the inject/eject handle of the PSU and push it down as shown in below figure. 3. Remove the PSU from the rack.

  • Page 19: Fan Unit

    NVE40K Hardware Manual 5. Fan Unit 5.1. Description 19” 1U rack mountable fan unit 3 DC fans 5.2. Unit view Figure 13. Fan unit Name Remarks Status LED Fan on & off DC Status Lamp In power switch DC Inlet...

  • Page 20: Electrical Characteristics

    NVE40K Hardware Manual Figure 14. fan unit 5.3. Electrical characteristics Parameter Units Value Input Voltage Rated Voltage DC 12 Operating Voltage DC 6 ~ 13.8 Input Power 3.60 Maximum Air Flow m3/min 0.63 x 3EA = 1.89 (At Average Value in Free Air)
  • Page 21 NVE40K Hardware Manual Mechanical characteristics of fan unit: Dimension Width (inch): 19 " Height (U): 1 U Depth (mm): 270 mm Number of DC fans (EA): 3 UDP Co., Ltd.

  • Page 22: Revision History

    NVE40K Hardware Manual Revision History Rev. Date History 2007-01 25 Created. 2008-10-14 Power consumption is added 2008-11-25 Video input range of blades added 2009-05-04 Resolution modified (Half D1 - > 2CIF) UDP Co., Ltd.
