Summary of Contents for Marunaka PHT1560 TU26PFD
- Page 1 MARUNAKA POLE HEDGE TRIMMER MODEL PHT1560 TU26PFD PHT1560 TJ27DX PHT1560 GX25 PHT1560 EH025 OPERATING MANUAL 11 MUKAIDANISHI-MACHI.KISSHOIN.MINAMI-KU.KYOTO, JAPAN.601-8307 info-e@marunaka-japan.co.jp http://www.marunaka-japan.co.jp CODE: 800203122 UK/BC 0612...
-
Page 2: Table Of Contents
INTRODUCTION Read this manual carefully to understand all safety precautions, controls, proper operation and maintenance of your MARUNAKA Pole hedge trimmer. Failure to do so could result in serious injury. Safety first Instructions contained in warnings within this manual and warning seals marked with a... -
Page 3: Safety Precautions
[1] SAFETY PRECAUTIONS □ In order to ensure proper and safe operation of your trimmer ・Read this pole hedge trimmer operating manual carefully. Be sure you understand how to operate this unit properly before you use it. Failure to do so could result in serious injury. ・Be sure to keep this manual handy so that you may refer to it later whenever any questions arise. - Page 4 ・After starting up the engine, check to make sure that the blades stop rotating when the throttle is moved fully back to its original position. If the blades continue to rotate even after the throttle has been moved fully back, turn off the engine and take the unit to your authorized MARUNAKA servicing dealer for repair.
- Page 5 ・When replacing blades or any other parts or when replacing the oil or any lubricants, always be sure to use only MARUNAKA products or products which have been certified by MARUNAKA for use with the MARUNAKA trimmer.
-
Page 6: Technical Data
[2] TECHNICAL DATA PHT1560 Model GX25 EH025 Engine Model TJ27DX TU26PFD 2546 2552 2585 2557 Length Overall size Width Height Dry Weight Centrifugal clutch, spiral bevel gear, cam clank Transmission Reciprocating double blade Type teeth Tooth Cutting head Tooth pitch Effective cut width 135°(＋90°,-45°from cutting head position Angle adjust range... -
Page 7: General Description
[3] GENERAL DESCRIPTION 1. Engine 6. Control handle 11. Gear case 2. Fuel tank cap 7. Trigger 12. Blades 3. Air filter cover 8. Safety grip 4. Spark plug 9. STOP switch 5. Muffler 10. Harness [4] FUEL MIX (TJ27DX,TU26PFD) ・This product is fitted with a 2-stroke engine and therefore requires a 2-stroke fuel and oil mix. -
Page 8: Engine Assembly
[5] ENGINE ASSEMBLY Assemble the engine onto the shaft housing. Make sure that the shaft housing is fully and correctly up to the shank, then tighten the four screws. Our standard tightening torque of bolt, screw and nut is As follows; Size M8 M10 Torque(daN.m) 1.6... -
Page 9: Starting And Stopping The Engine
2. Adjusting the blade angle DANGER ・make sure to stop the engine when adjusting the blade angle. ・make sure to press the support handle (b) when adjusting the blade angle. ・Never press the blade with your hand. NOTE ・The clamp handle (a) has the ratchet structure in which a spring is assembled. -
Page 10: Work Method
[8] WORK METHOD ・When using the pole hedge trimmer, make sure to securely hold it with both hands. Never hold it with only one hand; it is extremely dangerous. ・When moving or storing the pole hedge trimmer with the blade mounted, attach the blade cover. 1. -
Page 11: Storage After Operation
3. Adjust the clearance of the blade using the following procedure. (1) Loosen the blade coupling nuts. (2) Completely tighten the blade coupling bolts, and then loosen them by a half turn. (3) With each bolt fixed in the position in which it is loosened by a half turn from the completely tightened position, tighten the blade coupling nuts. -
Page 12: Declaration Of Conformity
Guaranteed sound power level(L ):dB(A) Declare under our sole responsibility that the product, PHT1560 TU26PFD, PHT1560 TJ27DX, PHT1560 GX25, PHT1560 EH025, to which this declaration relates is in conformity with the following the provisions of the following Directive. 89/336/EEC...
