Summary of Contents for Xineron HEM191BP
-
Page 3: Warnings And Cautions
Warnings and Cautions WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECT THROUGH VENTILATION GRILLS. CAUTION Explanation of Graphical Symbols The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage”... -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. -
Page 5: Table Of Contents
Table of Contents 1. Features - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2. -
Page 6: Operating Instruction
2. Operating instruction FRONT controls 1. Menu / Exit This button is used to bring up or disappear the controls menu. Exits from the OSD system and the selected function 2. ▼ (Down) / ( ) Brightness Moves down the menu lists in the OSD / Selected brightness 3. - Page 7 REAR connection 1. DC JACK Place the plug from the supplied table-top power supply into the DC 12V connector. Input at the monitor is 12 volts DC from the TT universal AC supply. (100-240 Vac, see specifications table for AC/DC details) 2.
-
Page 8: Connections
3. Connections To make a normal connection to the monitor, bring a cord from a camera, or other video source to one of the BNC jacks or from a PC to the PC jack on the back of the monitor. Either the left or right BNC jack can be used for input. -
Page 9: User Controls - Menu Operations
4. User Controls - Menu Operations 4.1. RGB (& DVR) Mode RGB Mode: General PC input mode DVR Mode: The optimized format to synchronize a monitor and a DVR for the best resolution. NTSC: 640x480 (60Hz), 672x480 (60Hz) PAL: 672x580(50Hz), 800x600 (75Hz) Press the MENU button to display the RGB menu. -
Page 10: Osd Menu
• Color Temp is used to control color temperature. (Normal, Warm, Cool, User) • Alarm is input for the alarm level (Max 5Vdc) of sensor or any alarm device. - Alarm menu (pull-down menu) Enable is used ON or OFF the alarm function. Alarm Source select the input source the alarm screen. -
Page 11: Cvbs Mode
4.2. CVBS Mode Press the MENU button to display the VIDEO menu. The follow setup menu will appears. ● VIDEO menu Video Contrast Brightness Sharpness Color Tint Under Scan < OFF > • Contrast, Brightness Change the contrast & brightness according to personal preference. •... -
Page 12: Hdmi Mode
4.3. HDMI Mode Press the MENU button to display the HDMI menu. The follow setup menu will appears. ● HDMI menu HDMI Contrast Brightness Tint Color Sharpness Panel scale < 16:9 > • Contrast, Brightness Change the contrast & brightness according to personal preference. •... -
Page 13: Specifications
5. Specification 17.0" Color TFT-LCD Monitor NO. ITEM SPECIFICATION LCD Panel 17.0" TFT LCD Panel Active Display Area (Diagonal) 17.0 inches Pixel Format 1280(H) x 1024(V), RGB Vertical Stripe Pixel Pitch 0.264mm x 0.264mm Color Depths 16.7M Colors Contrast Ratio 1000 : 1 (Typical) Brightness 250 cd/m... - Page 14 19.0" Color TFT-LCD Monitor NO. ITEM SPECIFICATION LCD Panel 19.0" TFT LCD Panel Active Display Area (Diagonal) 19.0 inches Pixel Format 1280(H) x 1024(V), RGB Vertical Stripe Pixel Pitch 0.294mm x 0.294mm Color Depths 16.7M Colors Contrast Ratio 1000 : 1 (Typical) Brightness 250 cd/m Viewing Angles (Left/Right/Up/Down)
-
Page 15: Dimensional Drawings
6. Dimensions drawings... - Page 16 50302918C...
