Summary of Contents for Guru-Z GX3-440x
- Page 1 V1.1...
-
Page 2: Key Features
V1.1 Preface Thanks for purchasing Guru-Z products. This Fiber Frame provides a durable and well-designed structure for different size of tail boom, including 5mm, 8mm and 12mm tail rotor, for both 300/400class helicopter. Please read the manual carefully before assembling the model. You may always get the latest online version of the manual via http://www.guru-... - Page 3 V1.1 Install the bearing in the slot as shown in the diagram. Bearing size varies to model. The Swash holder is installed opposite to the stock version of the King.
- Page 4 V1.1 Make sure the belt guide can be freely rotate after securing the screws.
- Page 5 V1.1 Install the parts as shown in the diagram. NOT all holes need screws at this stage. Install Servo at this stage will be easier...
- Page 6 V1.1 If you plan to use a bigger motor, you should install the motor at the stage. GE38H Brushless motor are able to be installed after finishing the frame.
- Page 7 V1.1 There are 2 kinds of inter-frame support. The 2 longer rods should be install at the rear part of the frame.
- Page 8 V1.1 You may choose to use the stock King 2 Landing ski. Congratulation, you have finished the assembly of the Fiber Frame and ready for further electronics installation.
