LDD / TEC 19" Rack Enclosure
Suitable for:
TEC-1089
TEC-1090
TEC-1122
TEC-1123
Meerstetter Engineering GmbH
Schulhausgasse 12
3113 Rubigen, Switzerland
Meerstetter Engineering GmbH (ME) reserves the right to make changes without further notice to the product described herein. Information
furnished by ME is believed to be accurate and reliable. However typical parameters can vary depending on the application and actual performance
may vary over time. All operating parameters must be validated by the customer under actual application conditions.
LDD-1124
LDD-1121
LDD-1125
Third-Party Devices
User Manual
LTR-1200
Valid for SN:006 to SN:XYZ
Phone: +41 31 712 01 01
Email: contact@meerstetter.ch
Website: www.meerstetter.ch
SWISS MADE
Advertisement
Table of Contents
Summary of Contents for MEERSTETTER LTR-1200
- Page 1 Website: www.meerstetter.ch Meerstetter Engineering GmbH (ME) reserves the right to make changes without further notice to the product described herein. Information furnished by ME is believed to be accurate and reliable. However typical parameters can vary depending on the application and actual performance...
-
Page 3: Table Of Contents
Device-specific Documentation Getting Started Menu Structure 2.3.1 Available Device Parameter Communication Interfaces 2.4.1 LTR-1200 Communication Concept 2.4.2 Connecting LTR-1200 over Ethernet 2.4.3 Service Software Default Address 2.4.4 Access over Third Party Software 2.4.5 Communication Fault Management Technical Data Elements and Configurations Front Panel 3.2.1... -
Page 4: Device Overview
1 Device Overview Features General Description Rack Enclosure Size: 1U, 400mm in Depth The LDD / TEC 19" rack enclosure LTR-1200 is a highly configurable, ready-made carrier system AC Input Voltage: 100..240V / 50..60Hz facilitating the integration of up to 4 devices... -
Page 5: Functional Description
2 Functional Description 2.1 Device-specific Documentation The following devices can be installed into the LTR-1200. Some of these devices can be connected in parallel to achieve higher output currents. Please contact Meerstetter Engineering if you have requirements which currently are not covered by any of these devices. -
Page 6: Menu Structure
Errors are shown on the overview screen with a symbol. For a description of the different Symbols see 3.2.1 LCD. A detailed Error Report will be shown on the device specific Menu screen. Page 6 (18) 31.07.13 TB LTR-1200 User Manual 5171 22.10.14 TB... -
Page 7: Available Device Parameter
2.3.1 Available Device Parameter Additional Parameters are available on request. Please contact Meerstetter Engineering for an inquiry. 2.3.1.1 LTR-1200 IPv4 Address Gateway IPv4 Address IPv4 Network Mask Service Software Default Device Interface RS232 Baud Rate ... -
Page 8: Communication Interfaces
A connection is always between one control software and one device. The Terminal, device number and Channel are not directly associated. Terminal represents only the output on the Back-Plane of the LTR-1200. One device can be connected to more than one Terminal. -
Page 9: Service Software Default Address
Please refer to 2.1 Device-specific Documentation to connect the Service Software over Ethernet. The Device Address (Device to be addressed) can be found on the LTR-1200 Menu or on the Built-in web site. It usually is the same as the Terminal Number. The LTR-1200 provides a total of six connections (TCP/IP, Port 50000, Timeout: 10s) to control the LDD/TEC Drivers over Ethernet. -
Page 10: Technical Data
The number of required power supplies and fans depends on types, numbers and applications of the built-in devices. Meerstetter Engineering equips the LTR-1200 accordingly. The LTR-1200 is back panel configurable, the standard panel offers 4 power output terminals and 4 sensors inputs connectors. (Up to 8 Terminals are possible) ... -
Page 11: Led
Static on 'Error' status, output stages disabled Slowly blinking Unknown Device Status, but no Error 3.2.4 Digital I/O 3.2.4.1 Pinout Type DIG IO Label LDD-112x TEC-1122/1123 TEC-1089/1090 LTR-1200 Input 1 IN1 RES8 RES8 RES1 Special Input 2 IN2 RES7... -
Page 12: Rs485
High-level Output Voltage TxD at R = 3kΩ to GND Low-level Output voltage TxD at R = 3kΩ to GND -5.4 Positive Input Threshold Voltage Negative Input Threshold Voltage Page 12 (18) 31.07.13 TB LTR-1200 User Manual 5171 22.10.14 TB... -
Page 13: Usb
Optional IEEE 1588: Precision Time Protocol (available on request) 3.2.8.2 LED Description Green Orange Not connected 10Mbit/s Blink Activity Connected 100Mbit/s 3.2.8.3 Available Features Small embedded website Service Software communication MeCom protocol Page 13 (18) 31.07.13 TB User Manual LTR-1200 5171C 22.10.14 SK... -
Page 14: Back Panel
(e.g. GND of one laser diode) may be tied to a given potential; it is however recommended to keep all loads and sensors potential-free. Upon customer request, individual outputs can be equipped such that they are potential-free (i.e. independent of other built-in devices). Please contact Meerstetter Engineering with your enquiry 3.3.1 TEC Sensors Pinout Fully pre-confectioned cables are available from Meerstetter Engineering at request. -
Page 15: Ldd Sensors Pinout
3.3.2 LDD Sensors Pinout Fully pre-confectioned cables are available from Meerstetter Engineering at request. 3.3.2.1 Part List Description Manufacturer Manufacturer Part Nr. Connector Solder 4-Way Binder 99-4909-00-04 Cable 4-Way, Shielded Kabeltronik 2-LifYCY TP (820400800) 3.3.2.2 Pinout Function Cable Color Temperature Sense A... -
Page 16: Ac Mains Supply
* When operated on 110V mains supply, the max input power is derated to 1100W due to the 10A fuse built into the standard IEC C13 housing. Please contact Meerstetter Engineering if you require an alternative connector. 3.4 Error Numbers Error Numbers 1 to 99 are universal error numbers, which are identically on each device. -
Page 17: Physical Dimensions
3.5 Physical Dimensions Air-Flow All dimensions are in mm Rack mounting brackets are removable 3.6 License Notice The LTR-1200 Software is built on FreeRTOS (http://www.freertos.org). Page 17 (18) 31.07.13 TB User Manual LTR-1200 5171C 22.10.14 SK... -
Page 18: Quotation Request Form
The TEC outputs need to be independent. (If an Error occurs on one output, the others continue) Pre-confectioned Sensor Cables are required. Cable Length: _____m Third-party devices need to be installed: Please send us more information about this device Page 18 (18) 31.07.13 TB LTR-1200 User Manual 5171 22.10.14 TB...
