Delta 3300 - Quick-Reference Manual-660-417

Table of Contents

Need help?

Do you have a question about the Delta 3300 and is the answer not in the manual?

Questions and answers

Summary of Contents for Netech Delta 3300

Page 1 Delta 3300 Quick Reference Manual (Full version of the manual is included in the CD) ►►►►Compact ►Easy to Use ► Best Value► Defibrillator and Transcutaneous Pacemaker Analyzer Innovative Instruments Since 1987 PN:-660-417 Delta 3300 - Quick-Reference Manual-660-417...
Page 2: Table Of Contents
Contact Information ................1 Warnings ..................1 Intended User .................. 2 Environment ..................2 Introduction ..................3 Delta 3300 Features ................ 3 Intended Use ................... 4 Specifications ..................4 Defibrillator Analyzer ................ 4 Transcutaneous Pacemaker ............5 General Specifications ..............7 Part Numbers and Ordering Information...........
Page 3 P a g e Saving Test Results ............... 16 Cardio version Test ................ 17 Charge Time Test ................18 AED Shock Advisory Test ..............19 Transcutaneous Pacemaker Test ............21 Pacer Pulse Measurement ............. 21 Pace Refractory Test ..............22 Sense Refractory Test ..............
Page 4: Notices
Notices Unpacking and Inspection of the unit Before unpacking the DELTA 3300 inspect the shipping box for any visual damage. If damage is found, do not unpack the unit and immediately notify the shipping carrier. If no damage is found to the shipping box, open the box and perform a visual inspection of the Delta 3300.
Page 5: Intended User
The Delta 3300 Defibrillator Analyzer intended for testing and verifying the performance of specifications of Defibrillators. The Delta 3300 should never be used in a patient care location where it might come in contact with a patient. The Delta 3300 Defibrillator Analyzer is intended to be used within the published specifications.
Page 6: Introduction
The DELTA 3300 has a built-in load resistance of 50 ohms, simulating the human body Impedance. The DELTA 3300 contact plates provide the electrical connection between the defibrillator paddles and the load resistance.
Page 7: Intended Use
 1M internal flash memory for storing test records.  Rs 232 interface for uploading test data. Intended Use The Delta 3300 is indented to be used to determine the performance specifications of the defibrillators and transcutaneous pacemakers Specifications Defibrillator Analyzer...
Page 8: Transcutaneous Pacemaker
P a g e Sync Time Measurements: Timing Window: Starts at each R wave peak Test Waveforms: User selectable ECG rates. Delay Time Accuracy: ±1 ms. Charge Time Measurement: Countdown Timer: User selectable - 30, 45, and 60 seconds. Energy Charge Time: Display the charge time measured from the time the start button is pressed to the discharge.
Page 9 P a g e Pacer Input (Load dependent): Amplitude (50 ohm): 0 - 10 mV Resolution (50 ohm): 25 μV Amplitude: (500 ohm): 0 - 100 mV Resolution: (500 ohm): 1 mV Accuracy: ±2% Immunity Test: Interference Signal: 50Hz / 60 Hz ECG signal Amplitude:0.5 to 5.0mV Refractory Period Measurement: 20 to 500 ms (both Pacing and Sensing)
Page 10: General Specifications
P a g e Performance Waveforms: Sine, Square, Triangle: Rate: 0.2, 0.3, 0.4, 0.5, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 15, 20, 25, 30, 35, 40, 45, 50, 55, 60 Hz. Amplitude: 0.1, 0.25, 0.50, 1, 1.5, 2.0, 2.5, 3.0, 3.5, 4.0, 4.5, 5.0 Amplitude accuracy: ±2 % (Square Wave -Lead II 1.0 mV ) Pacer Pulse: Pulse width: 10 mS.
Page 11: Part Numbers And Ordering Information
660: DELTA 3300 Defibrillator / Transcutaneous Pacemaker Analyzer (All Standard Accessories are included). Standard Accessories: 661: Internal Paddle Contact Adapters 660-CD: User and Service Manual DELTA 3300 660-HHS-001: Li-ion Battery (7.4V/850mA) 660-PADDLE-ADAP: Defibrillator Paddle Adapter (2) 660-610-6353: Standard Pacemaker Adapter cable...
Page 12: Preparation For Use
P a g e Preparation for Use The Delta 3300 is shipped with the following items included in the customized hard case: • Delta 3300 Defibrillator / Transcutanious Analyzer. • Li Ion Battery Charger (110/220 V input) • Paddle contact adapter for AEDs (2 Pieces) •...
Page 13 P a g e | 10 Display The Delta 3300 incorporates a high contrast 20 X 4 LCD display with LED back lighting for easy viewing. Key Pads The keypad utilizes soft touch tactile keys, providing a fluid resistant barrier to the internal circuitry. When a key is pressed a beeping sound will be heard to indicate that the key is activated.
Page 14 P a g e | 11 Paddle Contacts Plate. Defibrillator paddle contacts are marked “APEX” and “STERNUM”. Do not use AED pads directly on the paddle contacts. Use the insulated paddle contact cover included with the unit and the recommended cables for the particular AED model.
Page 15: Serial Interface Connector
P a g e | 12 Serial Interface Connector: D-sub 9 connector located on the right side panel provided for establishing communication with PC for uploading test data using the supplied RS232 or the optional RS232 /USB interface cable. Battery Compartment: The Battery compartment is located on the back of the unit.
Page 16: Defibrillator Testing
| 13 Defibrillator Testing Introduction The Delta 3300 can be turned ON by sliding the ON/OFF switch located on the right side panel. When the unit is first powered, the screen momentarily shows the software version and the build number then will display the Main Menu as shown below.
Page 17: Clock Setup
P a g e | 14 Clock Setup The Analyzer has a real time clock. The clock is setup at the factory. The test results saved under the Equipment ID set along with date and time. Therefore it is important to reset the time clock to the region where the unit is used.
Page 18: Defibrillator Energy Measurement
The three measurement functions of the defibrillator are energy, Cardio version (sync time), charge time. Defibrillator Test Menu The contact plates of Delta 3300 are marked APEX (+) and the STERNUM. Securely place the defibrillator’s APEX and STERNUM to the respective contact plates on the Delta 3300.
Page 19: Saving Test Results
• An important feature of the Delta 3300 is the auto ranging function, which ensures precision energy measurements. Energy readings under 10 will be displayed with 2 decimals, 10 joules to 100joules one decimal, and over 100 Joules no decimal.
Page 20: Cardio Version Test
P a g e | 17 For uploading test results to a PC refer to “Print” section in this manual. Cardio version Test 1. From the defibrillator menu select “Card” with F1 for the cardio version menu as shown below. The default waveform is set to ECG @ 80BPM.
Page 21: Charge Time Test
P a g e | 18 Charge Time Test The charge time function is used to test the charging time of the capacitor and the battery of the defibrillator. 1. Set the defibrillator energy to maximum (do not charge at this time). 2.
Page 22: Aed Shock Advisory Test
P a g e | 19 AED Shock Advisory Test This tests the automatic and semiautomatic external defibrillators ability to analyze and prompt the energy discharge. A series of arrhythmias as well as normal sinus (ECG) waveforms are available for analysis by the AED that should prompt the user to shock or no shock.
Page 23 P a g e | 20 5. Connect the AED using the optional AED cables specific to the model to the jack on the paddle cover. 6. Turn the AED on and follow the manufacturer’s test procedures.. 7. The AED will analyze the waveform and audio alert for ‘shock’...
Page 24: Transcutaneous Pacemaker Test
P a g e | 21 Transcutaneous Pacemaker Test The Delta 3300 tests various types of transcutaneous pacemakers. All pacer test functions are menu driven and simple to operate. It measures and displays a pacer pulse’s amplitude (current), peak voltage, rate, width and energy.
Page 25: Pace Refractory Test
ECG wave. Measurement of the pace refractory takes a few cycles of the pacemaker output. Delta 3300 measures the pacer pulse interval and puts out a QRS wave @ 40 milliseconds wide, delayed by a time, determined initially by checking the pacer...
Page 26 P a g e | 23 rate. The pacemaker senses this QRS wave. The delay time is gradually decremented until the QRS waveform is not sensed by the pacemaker. The maximum value of the delay time, for which the pacemaker does not sense the square wave, is the paced refractory period.
Page 27: Sense Refractory Test
QRS wave is not sensed. The sensed refractory period is measured similar to the pace refractory, except that DELTA 3300 now generates a QRS outside of the paced refractory period. The pacemaker senses the QRS. The QRS time is slightly increased each time with the pacer pulse until the pacer pulse senses the QRS and resets.
Page 28: Noise Immunity Test
The amplitude of the QRS is gradually increased from 0.1 mV steps or 0.25mv until Delta 3300 detects pacer pulse. The amplitude at which the pacer pulse is sensed is the sensitivity in 1. Select (F2) from the Pacer Test Menu. The sense refractory menu will be displayed.
Page 29: Ecg Simulation
P a g e | 26 ECG Simulation The Delta 3300 simulates ECG, Arrhythmia and performance waveforms as well as pacer pulse. The amplitude and rate of these waveforms is user selectable from the menu. Select the simulator function key marked “SIM“. The following waveform selections are available in Simulator menu.
Page 30 P a g e | 27 5. The selected waveform, rate, and amplitude is displayed and the waveform can be observed on the monitor of the DUT. 6. The selected waveform and the rates and amplitudes are saved until it is changed. 7.
Page 31: Save And Print Test Results
P a g e | 28 Save and Print Test Results Introduction As mentioned earlier, test results can be stored into the memory under the user specific “ID” and available to be uploaded to a PC using the serial to USB cable. Saving Test Results When the test results are displayed in any of the test functions, press “save”...
Page 32 P a g e | 29 Run the ProComPrint by double clicking the ProComPrintSetup.EXC. Follow the on screen instructions. When the installation is complete a window appears as shown below. • To setup the software follow the instructions below. • Insert the ProCom Software CD in the PC.
Page 33 P a g e | 30 The destination folder to which the results are to be saved need to be set. The default folder is set to C:\Program Files\x86\ProComPrint. To change the folder click, on “Browse” and set the folder in the desired directory. •...
Page 34 P a g e | 31 • Click Next. The following screen will appear. • Click Install. • Click “Finish” in the next screen. The following ProPrint Main screen will appear.
Page 35: Uploading Test Results To Pc
Once the ProComPrint software installation is completed, follow the procedure to upload the test results to the PC. Connect the Delta 3300 to the PC using the RS232 or (RS232/USB) cable to the PC. Turn the Delta 3300 Power ON.
Page 36 Equipment ID using the “v” arrow. “CLR MEMORY” :- This will clear all the saved records from the Delta 3300 Memory. “Notepad”: - The down loaded test results can be opened in the notepad for filling necessary Device information and save in...
Page 37: Uploading Test Results
P a g e | 34 “Clear Screen”:- This will clear the test results displayed in the screen. “Data Sheet”:- A sample “Word” template of the printout (as shown below) is included in the “ProComPrint Ver 1.0. Note: Sample Data Sheet can be opened and printed only if a licensed copy of the word is installed in the PC.
Page 38 P a g e | 35...
Page 39: Warranty
If the it fails to conform to these warranties, Netech will repair or replace the unit and/or its components within a reasonable period of time if the DELTA 3300 is returned, shipping prepaid, to Netech’s facility at Farmingdale, NY, USA within the warranty period as expressed above.
