Tri-Fold Sofa
OWNER'S AND SERVICE MANUAL
Page 1
Rev: 05.23.2017
Tri Fold Sofa Owners and Service Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Tri-Fold Sofa and is the answer not in the manual?

Questions and answers

Related Manuals for LCI Tri-Fold Sofa

Summary of Contents for LCI Tri-Fold Sofa

  • Page 1 Tri-Fold Sofa OWNER'S AND SERVICE MANUAL Page 1 Rev: 05.23.2017 Tri Fold Sofa Owners and Service Manual...

  • Page 2: Table Of Contents

    Warranty Introduction Our one-piece, steel frame Tri-Fold Sofa requires no spare mattress to store. In just four simple steps, it transforms into a comfortable bed. Traditional hide-a-beds have uncomfortable mattresses with support bars that can make sleeping uncomfortable. Air mattress hide-a-beds eliminate the support bar issue, but can be damaged more easily and become unusable.

  • Page 3: Safety Requirements

    NOte: Lippert Components, Inc. recommends that the following inspections, troubleshooting, component replacement, and verifications be completed only by certified RV technicians. Safety Requirements Moving parts can pinch, crush or cut. Keep clear and use caution. Failure to follow the instructions provided in this manual may result in death, serious injury, unit damage, or voiding of the component warranty.

  • Page 4: Preparation

    Preparation Tools Required • Cordless or electric screw gun or drill • 1/2" Socket (Import tri-fold sofas may use a 8mm socket) • Appropriate screw drivers • Appropriate drive bits Back Cushion Replacement Instructions Full Cushion Assembly Remove cushion from sofa. The cushions are held in place by hook and loop fabric strips (Fig. 2). Place new cushion back on sofa.

  • Page 5: Stationary Back Replacement Instructions

    Stationary Back Replacement Instructions Fig. 3 Full Stationary Back Assembly Remove back cushions from sofa and set aside. Unfold front seat and middle seat to expose mounting bolts and nuts (Fig. 3). Remove the 2 nuts and 2 bolts from each mounting bracket and set aside (Fig.

  • Page 6: Couch Seat Replacement Instructions

    Couch Seat Replacement Instructions Fig. 5 Couch Seat Assembly Remove cotter pins from the end of the clevis pins (Fig. 5). NOte: There is one clevis pin on each side of the Tri- fold sofa at the bottom of the seat. The clevis pins are attached to the steel tab connected to Clevis Pin the middle seat.

  • Page 7: Middle Seat Assembly

    Middle Seat Replacement Instructions Fig. 9 Middle Seat Assembly Remove one side of V2 Frame first. Start by removing 3 screws using a combo head square V2 Frame drive (Fig. 9). Remove cotter pin (Fig. 10). Lift up, push clevis pin out from the steel tab using a screw driver (Fig.

  • Page 8: Front Kick Rail Replacement Instructions

    V2 Frame Replacement Instructions Fig. 12 NOte: To replace the V2 frame the middle seat, couch seat and stationary back asssembly needs to be removed first for easier access. Remove the V2 frame by removing the 3 screws on each side. Install the V2 frame by making sure the U shape faces the back (Fig.

  • Page 9: Arm Insert Replacement Instructions

    Maintenance It is recommended that the bolts and nuts of the legs of the fold out portion of the Tri-Fold Sofa be tightened on a monthly basis. Over time the bolts and nuts can loosen, which could cause damage to the middle cushion cover.
  • Page 10 its discovery. In the event of any accident, injury to person, damage to property, or other loss involving a Product, you MUSt notify us in writing within thirty (30) days of the incident or within ten (10) days of notification to you, whichever is earlier.
  • Page 11 Indemnity. You agree to indemnify and hold us, as well as our officers, agents, employees, and representatives, harmless from and against all claims, causes of action, liabilities, losses, damages, judgments, and proceedings, whether based in contract, quasi-contract, subrogation, tort, strict liability, or any other legal or equitable theory, including without limitation all expenses, costs, damages or injury to person or property, and attorney fees incident thereto, arising from or relating to your handling, storage, transportation, possession, processing, fabrication, resale, or any other activity involving the Products after delivery, or relating to any extension or attempt to extend,...
  • Page 12 LCI representative has been provided.  Any unauthorized use shall void any applicable warranty.  The information contained in this manual is subject to change without notice and at the sole discretion of LCI.  Revised editions are available for free download from www.lci1.com.
