Summary of Contents for GHP Group GFB100
Page 1
Fireplace System Blower MODEL #: GFB100 Compatible Fireplace Systems: VFF-PH(20D)(20DB)(20D-C)(CPD-2T) VFF-PH(26D)(26D-T)(IMD-2H) VFF-PH(32DR)(32DR-H)(FSDR-2C) IMPORTANT INSTRUCTIONS PLEASE READ THIS MANUAL BEFORE INSTALLING AND USING APPLIANCE WARNING: IF THE INFORMATION IN THIS MANUAL IS NOT FOL- LOWED EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.
SAFETY INFORMATION SAVE THESE INSTRUCTIONS WARNING: This appliance is equipped with a three-prong (grounding) plug for your protection against shock hazard and must be plugged directly into a properly grounded three-prong receptacle. Read all instructions before using this appliance. If possible always unplug this appliance when not in use. Do not operate any heater with a damaged cord or plug or after the appli- ance malfunctions, has been dropped or damaged in any manner.
PACKAGE CONTENTS Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and diagram under. If any part is missing or dam- aged, do not attempt to assemble, install or operate the product. Contact our Technical Service Department at 1-814-643-1775.
ASSEMBLY INSTRUCTIONS WARNING: This appliance is equipped with a three-prong (grounding) plug for your protection against shock hazard and must be plugged directly into a properly grounded three-prong receptacle. Firebox must be disconnected from gas supply and removed from mantel before installing fan accessory.
Page 6
ASSEMBLY INSTRUCTIONS Important: Insert the wires marked with AUTO, OFF and MAN into line slot on the right corner. Keep wires close to the bottom. Insert two wires’ female plugs marked with T1 and T2 (black and yellow) into two male ports on Temperature Sensor.
Page 7
ASSEMBLY INSTRUCTIONS Insert the blower link (male plug) into the power link (female port). Important: Bind wires with cable ties (G), and attach cable ties (G) in holes on back of Outer Casing. Attach one in hole near the top and one in hole near the bottom.
ASSEMBLY INSTRUCTIONS Push Rocker Switch (E) into Control Panel and secure. Green Ground Check that all wires are secure Wire and reattach Blower Access Panel to Outer Casing. Capture the Screw Access Panel Green Ground wire between the Access Plate and Outer Casing Outer with the upper right screw.
OPERATING INSTRUCTIONS Using Rocker Switch, turn blower on and check for operation. Turn on Rocker Switch to the desired position. In the MAN position it will remain constantly on. AUTO position will be controlled by the Temperature Sensor. To stop the opera- tion turn Rocker Switch to the OFF position.
MAINTENANCE OF MOTORS WARNING: Make sure all power to the appliance is turned OFF before proceeding. Always disconnect the appliance from the main power supply and allow it to cool before any servicing operation. The motor used on the flame blower is pre- lubricated for extended bearing life and requires no further lubrication.
Page 11
This limited warranty is extended to the original retail purchaser of this heater and warrants against any years years...
Page 12
GHP Group, Inc. 6440 W Howard St Niles, IL 60714-3302 Tel: (877) 447-4768 www.ghpgroupinc.com GHP Group, Inc. 6440 W Howard St Niles, IL 60714-3302...
