4200
Operation And Maintenance Manual
WARNING:
BEFORE OPERATING THIS TOOL, ALL OPERATORS SHOULD STUDY
THIS MANUAL, TO UNDERSTAND AND FOLLOW THE SAFETY
WARNINGS AND INSTRUCTIONS. IF YOU HAVE ANY QUESTIONS,
CONTACT WITH OUR REPRESENTATIVES OR DISTRIBUTOR.
1-800-245-3188
www.ductmate.com
ductmate@ductmate.com
Advertisement
Table of Contents
Summary of Contents for DUCTMATE REPEATER 4200
- Page 1 4200 Operation And Maintenance Manual WARNING: BEFORE OPERATING THIS TOOL, ALL OPERATORS SHOULD STUDY THIS MANUAL, TO UNDERSTAND AND FOLLOW THE SAFETY WARNINGS AND INSTRUCTIONS. IF YOU HAVE ANY QUESTIONS, CONTACT WITH OUR REPRESENTATIVES OR DISTRIBUTOR. 1-800-245-3188 www.ductmate.com ductmate@ductmate.com...
-
Page 2: Table Of Contents
Operations And Maintenance Manual 4200 Contents Tool Specifications ........................3 Nail Specifications........................3 External Tool Parts ........................3 Safety Instructions ........................4 Lubrication and Maintenance ....................5 Actuating Tool ..........................5 Operating the Tool ......................... 6-8 Troubleshooting Guide ......................8 Part Lists ..........................9-12 Warranty ...........................12... -
Page 3: Tool Specifications
T O O L S P E C I F I C A T I O N S Height 17½” (444.5 mm) Width 9” (228.6 mm) Length 13½” (342.9 mm) Weight 10.5 lbs (4.76 kgs) Recommended Operating Pressure 70-120 psi (4.9-8.3 bar) Air Consumption Loading Capacity up to 200 fasteners... -
Page 4: Safety Instructions
S A F E T Y I N S T R U C T I O N S WARNING: Read this manual and understand all instructions before operating the tool. If you have any questions, please contact with our authorized representatives. •... -
Page 5: Lubrication And Maintenance
L U B R I C A T I O N A N D M A I N T E N A N C E • Use Pneumatic tool oil or a non-detergent oil. Do not use detergent oil or additives as they will damage o-rings and rubber parts. -
Page 6: Operating The Tool
O P E R A T I N G T H E T O O L Read Safety Instruction section of this manual. Loading the tool: WARNING: Always connect air before loading the tool. Always wear safety goggles when operating the tool. Open the magazine. - Page 7 O P E R A T I N G T H E T O O L C o n t . Adjusting Depth: The depth that the fastener is driven can be adjusted using the depth adjustment next to the trigger of the tool. WARNING: To reduce risk of serious injury from accidental actuation when attempting to adjust depth, ALWAYS;...
-
Page 8: Troubleshooting Guide
O P E R A T I N G T H E T O O L C o n t . Operation in Cold Weather When operating tools at temperatures near and below freezing, the moisture in the air line may freeze and prevent tool operation: Reduce the air pressure to 80 psi (5.5 bar) or less. -
Page 9: Part Lists
P A R T L I S T R E P E A T E R 4 2 0 0... - Page 10 P A R T L I S T R E P E A T E R 4 2 0 0 C o n t . Item # Part # Description Item # Part # Description DST4200-1 Hex.Soc.Hd.Bolt DST4200-48 Adjusting Spring DST4200-2 Bushing DST4200-49...
- Page 11 P A R T L I S T R E P E A T E R 4 2 0 0 F R A M E...
-
Page 12: Warranty
Ductmate warrants that the Repeater 4200, when properly installed and maintained, will be free from defects in material and workmanship, and will comply with all written specifications made by Ductmate at the time of sale. Ductmate’s warranty shall run for a period of one year from the date of manufacture.
