Instruction Manual
15" Industrial PC & Surveillance Monitor
Features
- High Resolution 15" Digital TFT LCD Monitor
- Free Input Voltage (DC 12V ~ 30V)
- NTSC/PAL Compatibility
- 4 Camera input : 4-pin mini DIN or 4 BNC Connector
- 5 Triggers function
- 1 A/V input : 2-RCA
- RGB input
- DVI input
- 1 A/V Output : 2-RCA (DVR)
- Single / Split / Triple / Quad Display modes
- Built-in OSD function
- Built-in Speaker
Model : MXN1500SQ
- Manual Backlight Dimmer control
- Button backlight with illuminated knob
* Design And Specifications Are Subject To Change Without Notice.
Advertisement
Related Manuals for MXN MXN1500SQ
Summary of Contents for MXN MXN1500SQ
- Page 1 - Single / Split / Triple / Quad Display modes - Built-in OSD function - Built-in Speaker Model : MXN1500SQ - Manual Backlight Dimmer control - Button backlight with illuminated knob * Design And Specifications Are Subject To Change Without Notice.
- Page 2 Instruction Manual ◈ Operation Power ON/OFF 1. POWER - Stand by mode : Power button is illuminated. - Power ON mode : All buttons are illuminated. Switch OSD menu 2. MENU - CAMERA / VIDEO [ PICTURE – OSD – QUAD SETUP ] - PC/DVI [ PC ] * At OSD menu : enter and exit menu...
-
Page 3: Display Mode
Instruction Manual ◈ Display mode < SPLIT MODE > < TRIPLE MODE > < QUAD MODE > CAM1 CAM1 CAM2 CAM1 CAM2 CAM3 CAM4 CAM2 CAM3 CAM3 CAM4 CAM1 CAM3 CAM4 CAM2 CAM1 CAM4 CAM2 CAM4 CAM2 CAM3 CAM3 ◈ Connections PC Monitor PC AUDIO IN(L) PC AUDIO IN(R) -
Page 4: Specifications
Instruction Manual ◈ Dimensions 137.25mm 15mm 30mm 349.5mm 124.75mm VESA 75x75 VESA 100x100 45mm Note. The length of screw (M4) should be within A+10mm. (A: Bracket thickness) 16.5mm 16.5mm 316.5mm ◈ Specifications Screen Size 15 inch / 38 cm Aspect Ratio Resolution Digital TFT LCD 1024 x 768 Viewing Angle...
