The water purifier
USER MANUALS
which do not get in the way
Please read the manuals, before you
use our product.
○Thank you for the purchasing our product.
○Please read this manual before using our
product.
JOY SPACE
○ After reading this manual, please keep it
The written guarantee attached
safe.
(No. 00000103)
Advertisement
Summary of Contents for AQUALEAD JOY SPACE
- Page 1 Please read the manuals, before you use our product. ○Thank you for the purchasing our product. ○Please read this manual before using our product. JOY SPACE ○ After reading this manual, please keep it The written guarantee attached safe. (No. 00000103)
-
Page 2: Specification
CONTENTS ● The name of the parts ● The capacity of JOY SPACE ● When you remove the ring screw ● attaching the tap and switching cock ● Operation of the switching cock ● Exchanging the filter ● About the other parts ●... - Page 3 The capacity of JOY SPACE MEASURING CONCENTRATION OF RESIDUAL FREE CHLORINE MEASURING CONCENTRATION Test condition OF RESIDUAL FREE CHLORINE =120,000ℓ ２. ０ ±0.2mg/ℓ The concentration of chlorine 4ℓ/min flow rate 20±3℃ temperature of water (Based on JIS S 3201) ０ 40,000 60,000 80,000 100,000 120,000 The amount of water （ℓ）...
- Page 4 attaching the tap and switching cock Round water tap 16㎜ 17． 5㎜ 19㎜ Foam water water tap（For External thread） Foam water water tap TOTO, INAX, MYM etc GROHE, MOEN, YANMAR etc External thread External thread Foam water water tap（For Internal thread） KVK etc GROHE, MOEN etc Internal...
- Page 5 ADAPTERS for round water tap 16mm 17.5mm 19mm see P6－ ADAPTERS for External thread W22× 山 20 ADAPTERS for External thread M22×1.0 see P6－ ADAPTERS for Internal thread W23× 山 20 ADAPTERS for Internal thread M24×1.0 see P6－ ADAPTERS of 4 screws see P6－...
- Page 6 Attention!! Please put on gloves. ！ Measure the diameter Move the ring screw of the tap with the backward. measuring paper. 16mm Pick up the appropriate adapter. Round water tap Take off the foam Put off the ring screw from water fitting.
- Page 7 Cutting No adjustable TAP Attach the adapter. Move and clamp the ring screw to the tip of the S pipe. ●The diameter of the round tap ① more than 24mm or 10mm without foam water fitting. ② ●A tap with shower Clamp the ring screw to the tip of the S pipe.
- Page 8 The operation of the switching cock There are 3 positions (raw water, raw water shower, purified water) by the lever. Switching lever raw water raw water shower raw water straight raw water shower 浄水 原水 原水 Display switching device NOTICE! purified water ！...
- Page 9 Regarding Consumable parts Switching cock, hoses and screw rings are the consumable parts. If they get dirt or broken, you can pursuit from our website. switching cock ￥5,800（without tax） 2 hose (1.5m) ￥4,800（without tax） ring screw, adapters, and packing ￥4,000（without tax） Aqua lead Co.
- Page 10 Please do not use it in the Please do not connect main ！ ！ stop type water heater presence of naked flames. system. That causes the heater broken. Do not break down, Please avoid detergent, bleaching ！ ！ agent, thinner, benzine, alcohol repair or remodel.
- Page 11 Warranty We guarantee the below statement for free repairing. 1. The term of warranty begins from the day you purchase. （For one year） 2. We grantee the less than 0.4ppm of Chlorine leftover after 2ppm water run through the our product.
-
Page 12: Warranty
JOY SPACE Warranty Thank you very much for your purchasing "JOYSPACE". We will serve you the one year guarantee from the day your purchasing. serial number The guarantee period （one year） from； ※Switching cock, hose and ring screw are not covered by warranty.
