EVENING LIGHT PAN5x5x30 User Manual

Panel
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
1
PANEL
PAN5x5x30 PAN4x4x30

USER MANUAL

For safety, please read this user manual carefully before initial use.
Event Lighting reserves the right to revise the manual at any time. Information and specifications within this manual are subject to
change without notice. Event Lighting assumes no liability or responsibility for any errors or omissions. Please consult Event Lighting
for any clarification or information regarding this item.
www.event-lighting.com.au
V1.3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PAN5x5x30 and is the answer not in the manual?

Questions and answers

Summary of Contents for EVENING LIGHT PAN5x5x30

  • Page 1: User Manual

    PANEL PAN5x5x30 PAN4x4x30 USER MANUAL For safety, please read this user manual carefully before initial use. Event Lighting reserves the right to revise the manual at any time. Information and specifications within this manual are subject to change without notice. Event Lighting assumes no liability or responsibility for any errors or omissions. Please consult Event Lighting for any clarification or information regarding this item.

  • Page 2: Table Of Contents

    CONTENTS Safety Instructions Power Input & Power Linking Product Installation Fuse replacement Product appearance Lux Chart Dimensions Control Board Operation DMX Addressing DMX Modes Dimmer Speed Setting Sound Mode Setting Static Colors User Mode Automatic Mode DMX Values Technical Specifications Warranty...

  • Page 3: Safety Instructions

    Safety Instructions WARNING • Do not open this device, there is no user-serviceable parts inside. Risk of electric shock. • Do not look at the light source when the device is on. • CAUTION: This unit's housing may be hot during and after operation. •...

  • Page 4: Product Appearance, Lux Chart, Dimensions

    PRODUCT APPEARANCE, LUX CHART, DIMENSIONS...

  • Page 5: Control Board Operation

    CONTROL BOARD OPERATION Press the Menu until one of the following displayed: Display Function To set DMX 1.DMX Address address To set DMX channel modes: 2.DMX Channel 5x5 Model CH 03, CH 05, CH 09,CH 75, CH80 4x4 Model CH 03, CH 05, CH 09, CH 48, CH53 3.Dimmer Curve To set dimmer speeds: 01, 02, 03, 04 4.Sound Mode...

  • Page 6: User Mode

    User Mode This mode allows the user set intensity of R, G, B separately to get endless color mixing from the control board without DMX controller to set the device to run strobe desired. Entered user mode "Manual color", use <UP> and <DOWN> to select the “R / G / B" for Colors intensity or "S" for strobe. Use <UP>...

  • Page 7: Dmx Values

    DMX VALUES 3 Channels Mode: ALL CHANNEL VALUE FUNCTION 000-255 Red: 0% ~ 100% 000-255 Green: 0% ~ 100% 000-255 Blue: 0% ~ 100% 5 Channels Mode: ALL CHANNEL VALUE FUNCTION 000-255 Red: 0% ~ 100% 000-255 Green: 0% ~ 100% 000-255 Blue: 0% ~ 100% 000-255...
  • Page 8 220-224 White Color Temperature 5 225-229 White Color Temperature 6 230-234 White Color Temperature 7 235-239 White Color Temperature 8 240-244 White Color Temperature 9 245-249 White Color Temperature 10 250-255 White Color Temperature 11 COOL 000-009 No function 010-032 Auto Program PR 01 R G B colors switching 033-056...
  • Page 9 53 Channels Mode: 4x4 CHANNEL VALUE FUNCTION LED 1 (1-3) , LED 2 (4-6), LED 3 (7-9) 1,4,7,10,13,16,19,22,25,28, 000-255 Red 0% ~ 100% 31,34,37,40,43,46, LED 4 (10-12), LED 5 (13-15) , LED 6 (16-18) LED 7 (19-21) , LED 8 (22-24), LED 9 (25-27) 2,5,8,11,14,17,20,23,26,29, 000-255 Green 0% ~ 100%...
  • Page 10 75 Channels Mode: 5x5 CHANNEL VALUE FUNCTION LED 1 (1-3) , LED 2 (4-6), LED 3 (7-9) 1,4,7,10,13,16,19,22,25,28, 31,34,37,40,43,46,49,52,55, 000-255 Red 0% ~ 100% LED 4 (10-12), LED 5 (13-15) , LED 6 (16-18) LED 7 (19-21) , LED 8 (22-24), LED 9 (25-27) 58,61,64,67,70,73 2,5,8,11,14,17,20,23,26,29, LED 10 (28-30) , LED 11 (31-33), LED 12 (34-36)

  • Page 11: Warranty

    Speed/Sensitivity of Auto / 0000-255 (Slow ~ Fast) Sound Programs 000-009 Default dimmer speed 010-048 Linear dimmer 049-088 Non-linear dimmer 1 089-128 Non-linear dimmer 2 129-168 Non-linear dimmer 3 169-208 WW/CW Mode ON 209-255 WW/CW Mode OFF When CH 80 @ 169-208, WW/CW ON, CH 1 ~ CH 50 function as following: LED 1 (1,2), LED 2 (3,4), LED 3 (5,6), 1,3,5,7,9,11,13,15, LED 4 (7,8), LED 5 (9,10), LED 6 (11,12),...

This manual is also suitable for:

Pan4x4x30
