Summary of Contents for Lumacol s.r.o. GECON LITE PLUS
- Page 1 GECON LITE PLUS & GECON - 7 INSTALLATION INSTRUCTIONS Version 1, SW 15c...
-
Page 2: Table Of Contents
NOTICE The device complies with STN EN 55022, class A. It is intended to be connected to a control panel that complies with STN EN 60950. Handling the device in other ways than described in these instructions may lead to non-functionality. Do not modify or attempt to repair the device yourself. -
Page 3: Basic Information
Basic Information GECON is a GSM communicator used to transfer predefined information/events via the GSM network in the form of a voice message, text message and ringing. Examples of use GECON is a universal device; for example, it can be used for: •... -
Page 4: Wiring Diagram
Wiring Diagram... -
Page 5: Installation
Installation GECON is fastened to the desired location using the included stick-on holders or screws (not included). Never place GECON in a metal box of a control panel without bringing out an external antenna!!! (The built-in antenna would become non-functional.) Placing it in a metal box is only possible if you use an external antenna together with antenna reduction. -
Page 6: Device Setting
GECON LITE PLUS/GECON – 7 If you want to use GECON - 7 in the GECON LITE PLUS version, you do not need to read on, everything will work as in the original mode as it is GECON factory setting. -
Page 7: Phone Number Setting
GECON - 7 now has 4 inputs + 3 reversible outputs/outputs an option to record voice messages separately for each alarm input /seven in total/ Phone Number Setting GECON LITE PLUS G7=OFF Gecon7 G7=ON... -
Page 8: Additional Functions
The order of the A/T symbols after the sign (=) determines the sequence of set inputs. This means that the first letter defines the setting of the first input, the second of the second input, etc. GECON LITE PLUS G7=OFF... -
Page 9: Delay Of Inputs
Text Setting GECON LITE PLUS uses predefined texts for text messages that indicate what type of event has occurred. You can change these texts yourself. To see the current setting of texts, send a query command (TEXT) on the GECON LITE PLUS phone number. -
Page 10: Password Change
RE1 … RE4 RE1 … RE7 - recovery messages at inputs 1 ... 4 - recovery messages at inputs 1 ... 7 - SMS text report - SMS text report Example: abcd TEXT - information on the current setting of text messages Response from GECON will include the designation of building or event types and the respective current settings of test messages are written after the equal sign (=): - building name... -
Page 11: Periodic Test
GSMKEY Function If you want to use GECON as GSMKEY, a condition is to begin with a TKEY command which is 0 (zero) by default. Thus, it does not appear to the PHONE query and this function is not functional. It is necessary to have CLIP activated on the SIM card in this case. -
Page 12: Practical Example
- SMS report setting with a period of 14 days The following text message will be sent to T1: GECON LITE PLUS: report Practical Example All commands can be combined in one configuration text message and these rules must be followed: ... -
Page 13: Online Printing
Keywords can be set using SMS commands w1 .. w16. Each keyword must end with #. The maximum length of a single keyword is 15 characters. The keywords can also be set via a PC program in the ONLINE section. GECON LITE PLUS is not case sensitive. Commands for SMS setting: w1 .. - Page 14 ALARM for the alarm, FAIL for faults and power failures. Setting: abcd print=on w1=!ALARM# w2=ARM# w3=DISARM# w4=FAIL# t1=090xxxxxx vt1=5 Example of online message: 14:25 ALARM PIR-hall 14:26 DISARM Smith Examples of practical use: 1. Signalling the alarm with exact localization 2.
- Page 15 Programming via software only for G7=OFF Programming procedure: 1. Make sure that the SIM card has the PIN code protection disabled. 2. Insert the card into the SIM holder on GECON. 3. Connect GECON to power. 4. Wait for registration to the network after turning GECON on. It is indicated by short flashes. 5.
-
Page 16: Voice Messages
It works for G7=ON as well as G7=OFF. GECON - 7 (works also in the GECON Lite Plus version) has a new function of audio messages for each input separately. When activating the alarm input, it will automatically play the specific audio message which is separate for each alarm input. -
Page 17: Sms Programming Tables
SMS Programming Tables for Gecon7 H=ABCD H=FERO Text message password change Information on FW. v.15c version [may contain additional information] PHONE Setting query: phone numbers, call routing, gsmkey T1=0903xxxx T2=# ... Setting of phone numbers T1 ...T4 for G7=OFF T1...T8 for G7=ON, Tx=# to delete phone number VT1=123 VT2=45 Routing inputs to phone numbers Time [s] of GSMKEY relay switching, =0 –... - Page 18 Query for the current status of inputs, built-in relays and GSM signal strength G7=ON or G7=OFF Switching of Gecon7 or Gecon Lite Plus versions IN1=1 IN2=0 ... Current status of inputs (cannot be overwritten) R=OFF R=ON Setting of built-in relay: off/on/trouble...
-
Page 19: Factory Reset
Factory Reset This function will reset the device to factory settings. Reset should be performed before every installation to eliminate incorrect setting. It deletes the voice messages! Steps: 1. Disconnect GECON from power supply. 2. Use RES jumper. 3. Connect GECON power supply. 4.
