Summary of Contents for Globalsources HDSW0007M1
- Page 1 User Manual HDMI Splitter 2x4 Model NO:HDSW0007M1...
- Page 2 Introduction Dear customer Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Our series of converters, switchers, extenders, matrixes and splitters are designed to make your A/V device use more convenient, more comfortable, more productive and more cost-efficient.
- Page 3 INTRODUCITON Feature： Two HDMI input signal split to four HDMI sink devices Support 4K full HD signal input and output Support analog stereo audio and digital audio(SPDIF/Toslink) output Digital audio port of Toslink can support 192Khz Sampling Rate(LPCM2.0 Audio Format), also can support LPCM 2.0, Dolby-AC3, DTS audio output.
- Page 4 Physical Connect Port: Picture 1.0 Front Panel Showing A：Power “ON/OFF” Button B： Standby Status LED, when light goes bright, the device goes to Standby State. C： HDMI Input Channel Switch Button D： ARC On/Off Button E： Video EDID Mode Switch Button F：...
- Page 5 B：HDMI Input Port C：HDMI Output Port D：Analog L/R Audio Output Port E：Digital Audio Toslink Output Port Remote Button Function Showing ON: Power On button, when device is standby, it will go to normal working status if you press the button and also the Standby Led Status Light will go off. OFF: Standby Button, when device is working normally, it will go to Standby status if you press the button and also the Standby Led Status Light will go bright;...
- Page 6 When use ARC, pls confirm you have turned on the TV CEC and used the HDMI 1.4V Cable. If no audio out, then pls restart your equipment. Audio： 2CH： EDID 2.0 Button. After press the 2.0 button, the 2.0CH LED light will go bright, and the device will change to support only LPCM 2.0 Audio Format;...
- Page 7 Connection and Operation: To use one HDMI Cable to connect the HD Source with the HDMI Input port of device. To use HDMI Cable to connect the HDMI Output port of device with the Display. To use optical cable to connect the Toslink output port with the AV Receiver. To use the analog av cable to connect the LR port of the device with the active speakers.
- Page 8 Spec: HDSW0007M1 HDMI Resolution……24/50/60fs/1080P/1080i/720p/576p/576i/480P/480i,24/30/2160P Deep Color …………24/30/36bit/1080P/1080i/720p/576p/576i/480P/480i,24bit//2160P HDMI In/Out Supported Audio Format………………………………………………………… DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD Digital Audio Output Supported Audio Format………………..…..LPCM2.0/Dolby AC3/DTS Digital Audio Output Sampling Rate..………….32KHz, 44.1KHz, 48KHz, 88.2KHz, 96KHz, 176.4KHz, 192KHz Digital Audio Output Max Bandwidth ………………………………….………………25MHz Analog Audio Max Output Voltage…………………………..…………………… 2V P_P Analog Audio Max Output Frequency Range…………………..………...……50Hz~18KHZ...
- Page 9 Notes: Pls use the machine as the instruction listed to keep the long use lifetime of the machine. 1. The machine should be placed at the spot far from the Damp, High-Temperature, Dusty, Erosive, and oxidative environment. 2. All parts will be free from the strong shake, hit, fall. 3.
- Page 10 3、Check the system connection quality. 4、Check if the line is all good quality. 5、Check the cable quality. 1、To try again to connect the cable to be free from the Obscure Picture unsuccessful connection. 2、HDMI Cable Quality 1、Please confirm the setting position of audio mode No sound switch 1、Pls check if the film that stops the current has been...
