- Page 1 USER GUIDE...
- Page 2 Before using the device, read carefully the operation instructions presented in this manual. It aims at familiarizing you with the technical features of your KONNECT 201 in order to make operation easier. NOTE : All information presented in this manual and on the box were current at the time of printing. However, as we are per- manently enhancing our products through software updates, this manual and the box might not present all the functions of your actual product.
- Page 3 KONNECT 201...
-
Page 4: Table Of Contents
CONTENTS P. 1 2 P. 6 4 - PHONEBOOK 1 - INTRODUCTION P.12 Setting Features Buttons & Device parts P. 1 3 5 - SETTING P. 8 2 - MESSAGING P.13 SIM setting Writting message P.13 Network setup P.14 Security setup Message setting P.14 Call setting... - Page 5 P. 1 6 6 - MULTIMEDIA P. 2 0 P.16 Camera 9 - LEGAL INFORMATION Audio Player P.16 Video Player P.16 Image viewer P.17 FM Radio P.18 P. 1 8 7 - FILE MANAGER P. 1 8 8 - SERVICE P.18...
-
Page 6: Introduction
INTRODUCTION FEATURES Screen 1.77’’ TFT Resolution 128 x 160 px Processor Spreadtrum 6531 Network GSM 850/900/1800/1900 Mhz Bluetooth Camera 0.08Mpx Battery 1000 mAh Speaker Connectors 3.5 mm line out/ Micro USB Micro SD slot Up to 16GB Dimensions 47.5 x 109.9 x 14.3 mm Weight 68 g... -
Page 7: Buttons & Device Parts
BUTTONS & DEVICE PARTS Torch LED Camera Speaker Power ON/OFF Torch function press long « 0 » Line out USB plug 3,5 mm (charge & PC conection) -
Page 8: Messaging
MESSAGING You can receive and send message，and can also use broadcast message. Message make it possible for you to exchange message With other wireless phone users. Select Message to perform operation. 2.1 WRITTING MESSAGE You can write a new text message send to others, and also can insert template in the message. Select the Option after editing a text message Send send the message only... -
Page 9: Message Setting
2.2 MESSAGE SETTING You can setup your MMS through the menu by your need as following: Server Profile Start or edit the service, when you fail to send the MMS，please change online-pattern of the server to WAP. Send Include life, send return, read return, priority etc. Retrieve Include main network, roaming network, Send return, allow to sending reports etc. -
Page 10: Sms Setting
2.3 SMS SETTING You can setup the message from the menu, as following: SIM Setting Offer you four profiles and you can edit their names, set SC Address and Valid Period etc. Common Setting Set delivery report on or off Memory Status Check the capacity of message storage Preferred Storage... - Page 11 3.1 SIM 1 & 2CALL HISTORY You phone keeps lists of incoming and outgoing calls, even for calls that didn’t connect . T he most recent calls are listed first. TIP : The phone keeps the only latest call of the same number . T o view detail information or performs other operation: Find the lists of Dialed Calls, Received Calls, Missed Calls .Press ok key to view the detail information: times etc.
-
Page 12: Phonebook
PHONEBOOK Select contacts to open phone book. It is consisting of phone storage and SIM card storage Phone Storage With a name, default number, family number, company name, email address, company number, fax number, birthday date, etc. Stockage sur la SIM The capacity depends your SIM card type and there is only a name and one business number in each item . -
Page 13: Setting
SETTING You can set your favorite wallpaper, ring or some other function. 5.1 SIM SETTING Enter this menu; you can set the mode to be Dual SIM, only SIM1, only SIM2, flight mode. 5.2 NETWORK SETUP When dual SIM mode is activated, you can perform network setup for SIM1 and SIM2 separately. Enter Network Settings, select Network Setup and then you can perform following operations: Network New search, Select Network... -
Page 14: Security Setup
5.3 SECURITY SETUP Enter Security Settings, select Security Setup and then you can perform foIIowing operation: SIM Lock Set a password for your SlM card-open/close Phone Lock Set a password for phone lock. (default 1234) Keypad Lock auto keypad lock on or off and a time after which the keypad is Locked Change Password Change the Pin Password, Pin2 Password and Phone Lock Password Note : For Pin Password, please contact your service provider. - Page 15 Call Waiting Setup the call waiting function Call Divert Setup the call diverts function Call Limit Setup the call limit function Line switch Switch your current line and there are 2lines available Call time reminder Set the call time reminder on or off and its type and period Call time Display Set if call time shows during calls or not Auto Redial...
-
Page 16: Multimedia
MULTIMEDIA Your phone offers multimedia applications and you can select Media from main menu to open it. 6.1 CAMERA Your phone has a hi-Mega pixeI camera that you can take photos whenever and wherever you like. After taking photos, store them in the phone memory or memory card (if any). Camera Setting Press left soft key to open Option in viewfinder display and make detail setting. -
Page 17: Image Viewer
playing, press the 4-way navigation key up-’and down to adjust the speed, press the left or right key to contrib. playing rate, press « 0 » to full screen, press « # »to control volume. 6.4 IMAGE VIEWER You can perform the following operations: View View photos Forward... -
Page 18: Fm Radio
6.5 FM RADIO Choose Radio menu to turn the radio function. Note : While tuning the radio in, you can dial or hear the call normally. When on the phone, the volume of the radio will become silence automatically FILE MANAGER Tap from the main menu to open it and you can find the storage devices and the capacity of total space and free space. - Page 19 Notice : GPRS service needs the support of network. You can enjoy it in the coverage areas of GPRS network. Homepage Access the Home page. Home page is your preset website of WAP lf you do not set the Home Page, your phone will access the default website.
-
Page 20: Legal Information
LEGAL INFORMATION EUROPEAN UNION DIRECTIVES CONFORMANCE STATEMENT Hereby, Danew declares that this product is in compliance with: The essential requirements and other relevant provisions of Directive 1999/5/EC 2200... - Page 21 SUPPORT & WARRANTY* For firmware updates, please visit our website www.danew.com and the Support and Drivers & Manuals section. Visit the website www.danew.com the Product registration section. For customer service requests, you should first contact the technical support in order to get the Return Merchan- dise Authorization RMA number.
- Page 22 YOUR MOBILE DEVICE MEETS FCC AND IC LIMITS FOR EXPOSURE TO RADIO WAVES. Your mobile device is a radio transmitter and receiver. It is designed not to exceed the limits for exposure to radio waves (radio frequency electromagnetic fields) adopted by the Federal Communications Commission (FCC) and Industry Canada (IC).
- Page 23 Highest SAR values for this device Head SAR 0,117 W/kg Body SAR 0,313 W/kg During use, the actual SAR values for your device are usually well below the values stated. This is because, for purposes of system efficiency and to minimize interference on the network, the operating power of your mobile device is automatically decreased when full power is not needed for the call.
- Page 24 All features, functionality and other product specifications, as well as the information contained in this guide, are based upon the latest available information and believed to be accurate at the time of printing. Danew reserves the right to change or modify any information or specifications without notice or obligation.
