Summary of Contents for Imetec KD-5031
- Page 1 Operating instructions page BLOOD PRESSURE MEASURING SYSTEM BLOOD PRESSURE MEASURING SYSTEM www.imetec.com Tenacta Group S.p.A. Via Piemonte 5/11 TYPE KD-5031 24052 Azzano S. Paolo (BG) ITALY Tel. +39.035.688.111 Fax +39.035.320.149...
- Page 2 ILLUSTRATIVE GUIDE TECHNICAL DATA 2013 2013...
- Page 3 PRESSURE MEASURING SYSTEm InSTrucTIonS For uSE Dear customer, IMETEC thanks you for having purchased this product. We are certain you will appreciate the quality and reliability of this appliance, designed and manufactured with customer satisfaction in mind. These instructions for use have been drawn up in accordance with European Standard EN 62079.
-
Page 4: Table Of Contents
INDEX SAFETY noTES Page 2 CONTRAINDICATIONS Page 5 Page 6 SYMBOLS Page 7 DEScrIPTIon oF THE APPLIAncE Page 7 INTENDED USE Page 8 FLucTuATIonS In BLooD PrESSurE HYPERTENSION IN ADULTS Page 8 USAGE RECOMMENDATIONS Page 9 Page 10 Installing the batteries Page 11 Date and time setting Page 11... - Page 5 • Do not let children play with the packaging! Keep the plastic bag out of the reach of children - risk of suffocation! • This appliance must only be used for the purpose it was designed for, that is as an automatic blood pressure monitor for home use.
- Page 6 • use only the supplied accessories. DO NOT share the appliance with persons who have infectious diseases, so as to prevent risk of infection. DO NOT use the appliance near strong electric fields such as mobile phones, microwaves, sources of X-rays, etc.
-
Page 7: Contraindications
CONTRAINDICATIONS ATTEnTIon: do not use the appliance in an area concerning cAT radiation, X-rays, magnetic resonance imaging (mrI) and in case of wounds or injuries to the arm. WArnInG: do not use the appliance on persons undergoing dialysis or taking anticoagulants, antiplatelet drugs or steroids for risk of internal haemorrhage, without having first consulted a doctor. -
Page 8: Symbols
SYMBOLS Keep away from humidity Read the instructions Warning Prohibited The device must be disposed of in accordance with the provisions of European standard 2002/96/EC Type BF applied part. The cuff is a type BF applied part Manufacturer Compliance with the Medical Directive 93/42/EC for medical devices Date of production European representative... -
Page 9: Description Of The Appliance
DEScrIPTIon oF THE APPLIAncE (Fig. A) LCD display 1.1 Date and time 1.2 Systolic blood pressure 1.3 Diastolic blood pressure 1.4 Heart beat frequency 1.5 Irregular heart beat indicator 1.6 Flat battery indicator 1.7 Memory position 1.8 Unstable or excessive cuff pressure indicator 1.9 Inflation error indicator Classification of the pressure values based on WHO indications... -
Page 10: Fluctuations In Blood Pressure
The signal on the LCD display disappears automatically after about 8 seconds. FLucTuATIonS IN BLOOD PRESSURE All physical activities, agitation, stress, eating, drinking, smoking, body posture and many more (including the blood pressure measurement itself), affect the pressure values. For these reasons, it is basically impossible to have identical values when several measurements are taken. -
Page 11: Usage Recommendations
For this reason, in the last few years, the medical class has raised public awareness on the importance of self-monitoring. The Imetec KD-5031 blood pressure monitor displays the classification of the pressure values based on the World Health Organisation indications. This classification is purely indicative... -
Page 12: Use
• Always take the measurement on the same arm, preferably the left. DO NOT talk or move while taking the measurement. DO NOT take the pressure reading immediately after meals, especially heavy meals. Wait at least one hour after meals. DO NOT smoke or drink alcohol before measuring blood pressure. -
Page 13: Installing The Batteries
1. InSTALLInG THE BATTErIES • Open the lid of the battery compartment (9) located behind the monitor. • Insert four 1.5 V AA batteries. Pay attention to the polarity. • Close the lid located behind the monitor (9) by inserting it in its slot and pressing lightly. -
Page 14: Connecting The Cuff To The Monitor
• Press the "START" (4) and "MEM" (5) buttons simultaneously. • The month (1.1) will start flashing first. • Set the month by pressing the ''MEM'' (5) button until the desired value is reached. To proceed more quickly, keep the "MEM"... -
Page 15: Cuff Application And Posture
4. cuFF APPLIcATIon AnD PoSTurE DurInG MEASUREMENT ATTEnTIon: DO NOT use the cuff on inflamed skin or with chronic or infectious skin diseases. • refer to the indications in the "SPEcIFIcATIonS" section to be sure the cuff size is appropriate. •... -
Page 16: Pressure Readings
5. PrESSurE rEADInGS • After having worn the cuff (6) and being in a comfortable and correct position for the reading, press the "START" (4) button. An acoustic signal is heard and the display (1) shows all the elements of the self-test performed a few moments before the measurement. - Page 17 • The blood pressure and the pulses are measured and shown on the display (1). • The measurement result is automatically saved in the memory. • After the measurement, the appliance switches off: • automatically after one minute of inactivity; •...
-
Page 18: Recalling Memorised Readings
6. rEcALLInG mEmorISED rEADInGS • Press the "MEM" (5) button to view the results saved in the memory. The display (1) will show the assigned memory position (1.7) and related values with the date and time: systolic pressure (1.2), diastolic pressure (1.3), heart beat (1.4), and classification of the pressure values according to the WHO indications (2+3). -
Page 19: Cleaning And Maintenance
CLEANING AND MAINTENANCE cleaning the display (1): use a soft, dry cloth. Do not use abrasive or alcohol based detergents that can damage the surface. cleaning the cuff (6): it is recommended to clean the cuff after about 200 uses or if it becomes dirty. Remove the cuff (6) from the appliance and use cold water and a mild detergent to clean it. -
Page 20: Troubleshooting
Warning: in the event of a fault, contact the nearest authorised assistance centre. TROUBLESHOOTING This chapter describes the most common problems related to appliance use. If the problems cannot be solved with the information below, please contact the Authorised Assistance Centre. PROBLEM POSSIBLE CAUSE SOLUTION... - Page 21 PROBLEM: the display POSSIBLE CAUSE SOLUTION shows The "flat battery" symbol Flat batteries Change the batteries The internal pressure of the appliance is unstable ‘Er 0’ before the measurement Do not move is taken and repeat the Error in measuring the ‘Er 1’...
-
Page 22: Disposal
Dispose of the batteries at a specific collection centre. ASSISTANCE AND WARRANTY To request repairs or purchase spare parts, please contact IMETEC’s authorised customer service centre at the Toll-Free Number below or via the website. The appliance is covered by the manufacturer warranty. -
Page 23: Technical Data
TECHNICAL DATA Product name: automatic blood pressure measuring system Model: KD-5031 Classification: Internal energy, class BF, IPX0, No AP or APG applied part, Continuous operating mode Appliance dimensions: 165mm x 96mm x 65mm Cuff circumference dimensions: 22cm ~ 30cm Weight: about 300g (batteries excluded) -
Page 24: Standards Tab
ELECTROMAGNETIC COMPATIBILITY manufacturer guide and declaration – electromagnetic emissions The KD-5031 device can be used in the electromagnetic environment specified below. The customer or user of the KD- 5031 device must ensure it is used in such an environment. Table 1... - Page 25 CISPR 11 RF Class B Emissions The KD-5031 device is suitable for use Harmonic in all environments, including the home Emissions Not applicable and those directly connected to the IEC/EN 61000-3-2 distribution network that supplies power Flicker/voltage to domestic premises.
- Page 26 Table 3 For all mE APPLIAncES and mE SYSTEmS that are not LIFE supporting Immunity Test level Level of Guide to the Test IEC/EN Conform- Electromagnetic environment 60601 Portable and mobile appliances for RF communications must be used outside the recommended separation distance, calculated with the applicable equation, with respect to any part of the KD-...
- Page 27 The KD-5031 device is suitable for use in an electromagnetic environment where the radiated RF interferences are controlled. The customer or user of the KD-5031 device can help avoid electromagnetic interference by keeping a minimum distance between the mobile and portable RF transmitting appliance and the KD-5031 device as recommended below, in accordance with the maximum output power of the transmitter.
- Page 28 Maximum Separation distance according to the transmitter rated power frequency m of the trans- 150 kHz to 80 80 MHz to 800 800 MHz to 2.5 mitter d = 1.2√P d = 1.2√P d = 2.3√P 0.01 0.12 0.12 0.23 0.38 0.38 0.73...
