INSTRUCTION & REFERENCE MANUAL • Model no. ODY-1720NX
We hope you enjoy your purchase
of the StarBlade and that this
user manual helps you get
your drone off the ground
and light up the sky!
WHAT'S IN THE BOX
1
StarBlade Drone Unit
2
Radio Control Transmitter
3
USB Charging Cable
4
7.4V Rechargeable Lithium Battery
5
4x Replacement Propellers
6
Quick Start Guide*
7
Instruction Manual*
POWER LED
THROTTLE STICK
DIRECTION TRIM
POWER SWITCH
SPEED
(3 SETTINGS)
FOR AGES
5
* Not Shown
14 +
FORWARDS
/BACKWARDS
TRIM
DIRECTION
CONTROL STICK
SIDE TRIM
360º FLIP
(see page 4)
Advertisement
Table of Contents
Summary of Contents for STARBLADE ODY-1720NX
- Page 1 14 + INSTRUCTION & REFERENCE MANUAL • Model no. ODY-1720NX FOR AGES We hope you enjoy your purchase of the StarBlade and that this user manual helps you get your drone off the ground and light up the sky! WHAT’S IN THE BOX...
- Page 2 If the light is flashing when you attach the battery, then the battery is charged. Reattach the battery to the StarBlade drone by inserting the red connector to the drone connector. Secure the hook-latch fabric fastener around the battery to keep it in place.
- Page 3 Place your StarBlade on a flat, leveled surface. On the top of the drone body is the power switch, switch it to ON. The drone’s LEDs will begin to blink*.
- Page 4 You do not want to do this too quickly as to avoid breaking the drone. Ease the right throttle stick (Directional Stick) up and down to make the StarBlade go forward and backward. FLYING, DIRECTIONS, & TURNING Push the right directional...
- Page 5 PROPELLER ADJUSTMENTS Note: There are two types of propellers, clockwise and counterclockwise. In the rare case that a propeller needs to be replaced or exchanged for a new one, unscrew the screw from the side of the propeller gently to remove that propeller. Replace with a new identical propeller by placing it on the motor and tightening the screw.
- Page 6 TROUBLESHOOTING PROBLEM POSSIBLE SOLUTIONS Check to make sure the power switch is in the ON position. If set to OFF, move to the ON position. Transmitter won’t Check to make sure the batteries are installed correctly. Check to make sure they match the polarity markings. power on If the batteries are installed correctly, they may be exhausted.
- Page 7 FLYING SAFE • BE AWARE OF YOUR ENVIRONMENT and SURROUNDINGS Always fly with as little wind as possible. Flying in extreme heat or cold can also adversely affect your flying control and response of the vehicle. CAUTIONS & WARNINGS • Suitable for ages 14 and up. Adult supervision is always recommended. •...
- Page 8 20855 NE 16 Avenue No. C22 • Miami, FL 33179 United States For Customer Service please email: Care@OdysseyToys.com Please note the units model number and name in your email. Model no. ODY-1720NX StarBlade Enterprise Class Quad Drone Extra Parts Available! • Extra Batteries Visit Odyssey online to order:...
