Summary of Contents for dgjiasong TL-WF01
- Page 1 TL-WF01 Wireless Video Door Phone User Manual...
- Page 2 (3). For iPhone , pls log in Apple App Store and download app (to be launched in July, 2015). (4). Install App. 2. Charge outdoor camera with original DC5V/1A power adapter; wait for 30 seconds to finish booting. (1). Simple sketch of TL-WF01 outdoor camera...
- Page 3 3. Match mobiles with outdoor unit (1). Keep WIFI signal available to phone; open app system and enter interface (see pic 1); (2). Click matching button (as pic 2); (3). Press Matching key on outdoor camera and matching will be automatic finished between phone and outdoor unit.
- Page 4 for outdoor camera to auto restart and connect WIFI router image4 image5 image6 image7 5. Unlock Password Each outdoor device has a sole default door release password, which can be changed; it becomes default password if camera restores to factory setting. See phone door release interface as image 8 and unlock password change interface as image 9.
- Page 5 pic8 pic9 6. Edit Outdoor Device Camera name, login password, deleting and other operations can be completed by Edit option. (1). Revise name (as pic 10); (2). Change login password (see pic 10); (3). Delete camera (see pic 11)
- Page 6 pic 10 pic11 7. Events Event list shows records of each call, door release, motion detection, tamper alarm and message of outdoor camera. Each event video files can be viewed and downloaded by phone users (as image 12). 8. Video recording Videos will be saved in Video file (see as image 13) after manual video operation on phones.
-
Page 7: Installation Steps
Installation Guild Outdoor camera should be installed 1.4-1.7 meter above floor and avoided direct sunshine. Installation Steps (1). Punch suitable holes on wall, put screw stopper and fix rain cover on the wall with screw; (2). Connect charge cord (hole diameter 16-30mm) as per wire connecting diagram. Pierce power cable out of wall hole in case of indoor charge;... - Page 8 Instruction Attention: (1). No sheltering or covering camera’s light sensitive sensor; (2). Protect camera from direct sunshine; (3). Ensure correct wiring otherwise device can’t work normally. Single Package Included: 1X User Manual 1X Quality certificate 1X Outdoor unit 1X power adapter (DC5V) 1 X install screws package...
