EMB-N2800 Quick Guide
Customer
Product
Name
Description
EMB-N2800 (Intel Cedarview N2800 1.86GHz CPU)
Mini-ITX Board used Intel Cedar Trail Platform (Revison 2.1)
SynCus Tech Co., Ltd
Taekwang B/D 3F, 191-1, Anyang 7-Dong, Manan-
gu,Anyang-si, Gyeonggi-do, Korea
Tel:031-443-8493
http://www.syncus.co.kr
FAX:031-442-0261

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EMB-N2800 and is the answer not in the manual?

Questions and answers

Summary of Contents for SynCus EMB-N2800

  • Page 1 EMB-N2800 Quick Guide Customer Product EMB-N2800 (Intel Cedarview N2800 1.86GHz CPU) Name Description Mini-ITX Board used Intel Cedar Trail Platform (Revison 2.1) SynCus Tech Co., Ltd Taekwang B/D 3F, 191-1, Anyang 7-Dong, Manan- gu,Anyang-si, Gyeonggi-do, Korea Tel:031-443-8493 FAX:031-442-0261 http://www.syncus.co.kr...

  • Page 2: Table Of Contents

    - Contents - 1. Specification ………………………………………………………………………………………………………...4 2. Listing of Jumpers, Connectors …………………………………………………………………………..5 2.1 Top Side …………………………………………………………………………………………………………..5 2.2 Bottom Side …………………………………………………………………………………………………….6 2.3 Quick Listing of Jumpers ………………………………………………………………………………….6 2.4 Quick Listing of Connectors ……………………………………………………………………………..7 3. Installation & Description of Jumpers and Connectors ..……………………………………8 3.1 Jumper Installation …………………………………………………………………………………………..8 3.1.1 J1A : DDR3 SODIMM SOCKET1 ………………………………………………………………8...
  • Page 3 3.2.10 CN10 : Internal 3P SATA Power Connector ……………………………………………….13 3.2.11 CN11 : 3G USIM Socket (Factory Option) …………………………………………………13 3.2.12 CN12 : Mini PCIe Connector ……………………………………………………………………..14 3.2.13 CN14 : Internal LCD Brightness Up/Down Connector ………………………………15 3.2.14 CN16 : SD Memory Connector ………………………………………………………………….15 3.2.15 CN17 : PS/2 Keyboard and Mouse Connector ………………………………………….15 3.2.16 CN18 : Serial 9P D-SUB Connector ……………………………………………………………15 3.2.17 CN19 : Power Input Connector ………………………………………………………………….16...

  • Page 4: Specification

    1. Specification 구 분 항 목 Descriptions-HDD Intel Cedarview 1.6GHz/1.86/2.133GHz, Processor L2 Cache – 512KB 8-Way Main Chipset Intel NM10 (Tiger Point) Memory Main Memory 2x DDR3 SODIMM Socket upto 2GB(N2600)/4GB(N2800,D2550) Main Super I/O W83627HF I/O Chipset Multi I/O FD81261D WinXP, Window7, Linux BIOS Boot device...

  • Page 5: Top Side

    2. Listing of Jumpers and Connectors 2.1 Top Side (Revision 2.1)

  • Page 6: Bottom Side

    2.2 Bottom Side (Revision 2.1)

  • Page 7: Cn10 : Internal 3P Sata Power Connector

    2.3 Quick Listing of Jumpers J1A : DDR3 SODIMM 204P SOCKET1 J1C : DDR3 SODIMM 204P SOCKET0 J3 : LCD Core Power Selection Header – 1x3P (+3.3V/+5V) J6 : Internal USB Header – 2x5P J11 : CMOS Clear Header - 1x3P J12 : Power/Reset SW and HDD LED Header –...

  • Page 8: Jumper Installation

    CN19 : Power Input Connector CN20 : CPU/System FAN Connector CN21 : Triple Audio Jack Connector 3. Installation and Descrption of Jumper and Connector 3.1 Jumper Installation 3.1.1 J1A, J1C : DDR3 Memory Socket -. J1C : SODIMM0 –Primary install a memory -.

  • Page 9: J12 : Power/Reset Sw And Hdd Led Header

    3.1.5 J12 : Power/Reset SW and HDD LED Header – 2x5P Signal Signal Pin No. HDD LED PWR LED PWR BTN RESET BTN 3.1.6 J13 : Internal Front Audio Header – 2x5P Signal Signal Pin No. Mic2_L FP Detect Mic2_R Mic2_JD HPOUT_R HP_JD...

  • Page 10: J16 : Internal Data I/O Header

    3.1.9 J16 : Internal Data I/O Header – 2x5P Signal Signal Pin No. DIO0 DIO4 DIO1 DIO5 DIO2 DIO6 DIO3 DIO7 3.1.10 J17 : RS422/485 Selection Header – 1x3P (COM5, J20) Pin No. Description Remark 422 Mode 485 Mode Default 3.1.11 J18 : RS422/485 Selection Header –...

  • Page 11: J22 : Internal Cir Header (Factory Option)

    3.1.14 J4 : DVI/HDMI Diplay Port Selection Header (PCB Rev. : 2.1) Pin1-2 : HDMI Port Selection Pin2-3 : DVI Port Selection 3.1.15 J22 : Internal CIR Header (Factory Option) – 2x5P Signal Signal Pin No. CIRRX IRRX +5VA IRRX...

  • Page 12: Connector Description

    3.2 Connector Description 3.2.1 CN1 : HDMI Connector (Factory Option) – Mini HDMI Type C Connector TMDS2+ TMDS2- TMDS1+ TMDS1- TMDS0+ TMDS0- Signal TCLK+ TCLK- PU to Signal 3.2.2 CN2 : Internal LVDS Connector – 2x20P Boxed Type Signal +V3.3 SPC1 +V3.3 EDATA7+...

  • Page 13: Cn4 : Dvi-D+Vga Connector

    3.2.4 CN4 : DVI-D+VGA Connector DVI Pin Mapping CRT Pin Mapping TMDS_D2+ TMDS_D2- GREEN TMDS_D0- BLUE DDC CLK TMDS_D0+ DDC_DATA DDC DATA HSYNC RESERVED TMDS_D1- VSYNC TMDS_D1+ DDC_CLK TMDS_CLK+ TMDS_CLK- 3.2.5 CN5, CN6 : USB+RJ45 Modular Jack Connector USB Pin Mapping U1(U5) U2(U6) U3(U7)

  • Page 14: Cn11 : 3G Usim Socket (Factory Option)

    3.2.6 CN7, CN8 : SATA HDD Connector Signal TX0+ TX0- RX0- RX0+ 3.2.7 CN9, CN10 : Internal 3P SATA Power Connector Signal +12V 3.2.8 CN11 : 3G USIM Socket (Factory Option) Signal USIM_VCC RST# DATA PU to USIM_VCC 3.2.9 CN12 : MiniPCIe Connector...

  • Page 15: Cn14 : Internal Lcd Brightness Up/Down Connector

    3.2.10 CN14 : Internal LCD Brightness Up/Down Connector (Factory Option) Signal BLDN BLUP...

  • Page 16: Cn16 : Sd Memory Connector

    3.2.11 CN16 : SD Memory Connector – Standard Type A (Bottom Side) Signal CD_N 3.2.12 CN17 : PS/2 Keyboard and Mouse Mini DIN Connector Signal KDAT KCLK MDAT MCLK 3.2.13 CN18 : Serial 9P D-SUB Connector Signal Signal Signal DCD1 RTS1 CTS2 RXD1...

  • Page 17: Cn19 : Power Input Connector

    3.2.14 CN19 : Power Input Connector Signal DCIN DCIN 3.2.15 CN20 : CPU/System FAN Connector Signal +12V 3.2.16 CN21 : Triple Audio Jack Connector Signal Signal Signal MIC_L LOUT_L LIN_L M_JD LOUT_JD LIN_JD MIC_R LOUT_R LIN_R...

  • Page 18: Methods Of The Lcd Panel Set

    3.3 Methods of the LCD Panel set 3.3.1 SW1 Set on the PCB 1) 1280*1024 : Default - Off-On-On-Off 2) 1024*768 : On-Off-On-On 3) Other LCDs : You can ask us for your LCD Panels 3.3.2 Set the BIOS Setup on the Screen 1) Enter “Setup screen”...
  • Page 19 3.4 I/O Address Map in Main Board...

  • Page 20: Irq List

    3.5 IRQ LIST in Main Board...

  • Page 21: Memory Map

    3.6 Memory Map in Main Board...

  • Page 22: Layout

    4. Layout S-ATA Power Mini HDMI Power SW/LED Front Audio Internal USB SO-DIMM DDR3 PCI Express Slot Internal USB S-ATA CPU Fan CMOS Clear PCI Slot Mini PCI Express 12V DC In Rear Audio COM3/4 LCD Inverter COM5 LVDS 5. Mechanical Drawing Mouse COM1 LAN1...

  • Page 23: Revision History

    6. Revision History - TBD...

  • Page 24: Dual Display Configuration

    7. Dual Display Configuration 표준형 사양 LVDS Single LVDS+VGA DVI+VGA LVDS VGA+LVDS Single DVI+LVDS VGA+DVI LVDS+DVI Single HDMI 지원형 사양 (Factory Option) HDMI Single DVI+VGA HDMI+VGA VGA+DVI Single Not support HDMI VGA+HDMI Not support Single 8. Package & Accessory 12V DC Power Cable (250mm) Rear I/O Shield Bracket S-ATA 3P Power Cable (330mm) LVDS Cable...
  • Page 25 후면 SD 카드 슬롯...

  • Page 26: Bios Setup

    9. BIOS Setup AT <-> ATX 전환 (자동 Power On) Chipset – Restore AC Power Loss Power On / Power Off LVDS/HDMI 설정 Host Bridge – Active LFP No LVDS / LVDS / EFP (HDMI) Default Boot Display 설정 Host Bridge – IGFX – Boot Type VBIOS Default / CRT / LFP / EFP / CRT + LFP / CRT + EFP / LFP + EFP...
  • Page 27 S-ATA Mode 설정 South Bridge – Configure SATA as IDE(WinXP) / AHCI (Win7) Graphic Memory 설정 Host Bridge – Fixed Graphics Memory Size 128MB / 256MB...
