Summary of Contents for iWatRoad R5

  • Page 2 ENGLISH User Manual...

  • Page 3: Table Of Contents

    Cont e nt s Welcome to Stylemotion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 About this Manual .

  • Page 4: Welcome To Stylemotion

    Wel c ome t o St y l e mot i o n Congratulations! You can now enjoy your iWatRoad R5, but before jumping onto Stylemotion, we recommend that you carefully read this manual . In it you will find all the necessary steps to safely enjoy the iWatRoad R5 .

  • Page 5: About This Manual

    The development of its design, motor and circuit have all been undertaken by iWatRoad, and we can guarantee that every part of R5 is a we- ll-made art by iWatRoad . The R5 is small, it has a slim structure, it’s lightweight and it’s very easy to get started . The rich APP functions will make your riding experience feel all around smart .

  • Page 6: Schematic

    Schemat i c Right handle Accelerator Multi-function button Left handle Electronic brake Handle bar Battery detach button Clamp Battery indicator Light Battery indicator control button Charging Port & USB port Battery Handle block button Folding lock Deck Front fender Rear fender Front wheel Rear wheel Auxiliary wheel...

  • Page 7: Set Up

    Step 2: Please, make sure that the axle completely snaps into slot B, then flip the the axle has separated from slot A comple- folding lock up to assure that you’ll ride safely . tely, raise the body of the R5 .
  • Page 8 Step 3: Open the “Clamp” and adjust the height appropriately, Step 4: Place the handlebars as shown in the image . then lock it again .

  • Page 9: Removing And Inserting The Battery

    Removi n g and i n sert i n g t h e Bat t e ry 1. Press de “Push” button inwards, 2. Lift out the battery . 3. Remove the battery . 4. While re-inserting, align the ba- never downwards .

  • Page 10: Folding And Transport

    Fol d i n g and Transport Step 1: Before folding, straighten the handlebars and while pushing the handle block, lock the body into place . Warning! Before riding, push the button to allow the handle bar to turn . Step 2: While holding the handlebars, turn over the folding lock using your foot .

  • Page 11: Gears

    The R5 can shift between 3 gears . 1st GEAR being the slowest, 3rd GEAR being the fastest . When the R5 shuts down, the LED light will turn off . Once started and in 1st GEAR, the light will appear green . Once in 2nd GEAR, the light will appear blue .

  • Page 12: Accelerating And Braking

    BRAKE ACCELERATOR Brake: The R5 uses an electronic brake . The harder you press the brake crank, the harder you’ll brake . The brake and accelerator cannot be used simultaneously . Cruise-control: Riding during 6s at a constant speed will make the scooter go into cruise-control . You can stop accelerating and the scooter will carry on at the current speed .

  • Page 13: Learn To Ride

    Learn t o Ri d e ≥ 4m ≥ 4m Step 1: To start, press and hold down the button for 2 seconds . The Step 2: When riding for the first time, ride on a flat, open surfa- default setting is 1st GEAR, Green . To switch gears, press the key . ce .

  • Page 14: Safety Precautions

    ≤ Please, slow down or walk when nearing a road in bad Using the R5 in freezing weather or in the rain is not recommen- condition . ded . If it must be used, make sure to maintain your speed under 10km/h .

  • Page 15: Do Not Attempt Dangerous Actions

    Do not at t e mpt dangerous act i o ns Not suitable for children under 7 years old . No more than one person at a time . Never ride on roads used by vehicles, or where laws are violated . Do not perform stunts, such as riding one-handed .
  • Page 16 Do not shut the power off while riding Do not ride up or down steps . Do not ride in water that is deeper than 2cm . Do not ride on slippery surfaces .

  • Page 17: General Safety Information

    - Riding backwards is very dangerous . Do not attempt, as the device will not support it . Avoiding accidents: Please, read this manual carefully . Understand and accept the contents before using the iWatRoad . - Do not let others ride your device unless they have also read and understood this manual .

  • Page 18: Maintenance

    Mai n t e nance If the R5 is stained/dirty, you can use a damp cloth to wipe it over . If the stain is difficult to clean, use a small amount of soap and a clean too- thbrush, then wipe with a wet cloth .

  • Page 19: Warranty

    - Discrepancy between warranty card, proof of purchase or product . - The product has been disassembled, modified or repaired by anyone not authorized by iWatRoad . - Damages caused by accidents, abuse, misuse, such as mechanical failure, damage due to dropping, high levels of rust or humidity .

  • Page 20: Situations Which Void Warranty

    No warranty card, invoice or model name can be matched to the device . The device has been repaired by persons not approved by iWatRoad . The user damages the device, even by accident (physical damage, drops, etc . . .) Too much weight is applied or obstacles have been driven over (going down steps or dropping) .

  • Page 21: Specifications

    Speci f i c at i o ns Index Item R5 Smart Scooter Folded (mm) 843x425x260 Size Height (mm) 1100 Maximum Load (kg) Weight Net Weight (kg) 9 .6 Age (years) 7~99 Riding User height (cm) 120~200 Max . speed (km/h)

  • Page 22: Fcc Caution

    FCC Caut i o n § 15.19 Labelling requirements. This device complies with part 15 of the FCC Rules . Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interferences that may cause undesired operation . §...

  • Page 23: Contact Us

    Please contact your supplier directly for After-Sales service . Or ce, operation, warranty, safety or if you want to contact the you can contact iWatRoad by filling in the feedback form on manufacturer concerning product malfunctions then you can the website at http://www .iWatRoad .com/ .
  • Page 24 .iWatRoad .com...
