EVC-IP-SO2MAI

USER MANUAL

www.eurovideo-cctv.com

Table of Contents

Need help?

Do you have a question about the EVC-IP-SO2MAI and is the answer not in the manual?

Questions and answers

Summary of Contents for Euro Video EVC-IP-SO2MAI

Page 1 EVC-IP-SO2MAI USER MANUAL www.eurovideo-cctv.com...
Page 2 Attention FCC Warning HD IP camera fully complies with Article 15 of FCC rules about Class A Digital Devices after thorough test. To some extent, those rules ensure its normal operation without external interference. The device is electromagnetic. Please do read the manual carefully before use, or it might cause interference to radio communications.
Page 3: Product Description
harmful voltage. Please operate the device in strict accordance to the manual. Indicate that user should install and operate the device strictly according to the manual. Warning: To avoid moisture lead or fire, please do not put the device in wet open places! Content Content ................
Page 4: Table Of Contents
4.1 Login .............. １６ 4.2 Browser ............１８ 4.2.1 Video Browsing ........１８ 4.2.2 PTZ control ......... １９ 4.2.3 PTZ functions ........２０ 4.2.4 Common shortcuts ......２１ 4.3 Setting ............２２ 4.3.1System ............ ２２ 4.3.2 Network ..........２６ 4.3.4 Management software ......３２ 4.3.5 IP Cameras ..........
Page 5: Chapter 1 System Overview
Chapter 1 System Overview 1 P od t De iptio The manual mainly introduces the setting and operation of HD IP cameras. HD IP camera combines CMOS sensor and the latest network encoding technology, provides the users with a full live video capture system of high definition, high SN ratio and low illumination.
Page 6  CMOS Image sensor  Automatic IR-CUT filter, Color/Black & White auto switch  H.264 / MJPEG dual encoding, tri-streaming  Support high frame output  Support two-way audio, G.711 encoding format  Support Motion Detection  Support 2-CH alarm input, 1-CH relay output (optional) ...
Page 7 parameters according to different models. Provide comprehensive network monitoring and transmission mechanism.  IP Camera connects 10M/100M network port through RJ45. It supports full TCP/IP protocols (TCP/IP, HTTP, ICMP, UDP, SMTP, RTP, RTSP, SNMP), adjusts its bit flow rate and frame rate, so as to adapt itself to strict monitoring system requirement.
Page 8 RAM 2GB or above Network Port: 100M Ethernet port Operating System: Windows 7 ,Windows 2000/2003, Windows XP Web browser: Microsoft Internet explorer version 8.0 or higher P od t Sp Image Processor: CMOS Low Illumination: Color Mode: 0.05-1 Lux @F1.2 (30IRE, AGC ON) B/W Mode: 0.005-0.1 Lux @F1.2 (30IRE, AGC ON) S/N Ratio: 70.1dB/83.5dB/90dB/110dB (...
Page 9 Audio Compression: G.711 1-CH, line level, impedance: 1kΩ Audio input: 1-CH, line level, impedance: 600Ω Audio output: Motion detection: Support Password protection: Support Network: 1 of RJ45 10/100M adaptive to POE Network Protocol: TCP/IP, HTTP, ICMP, PPPoE, DHCP, UDP, SMTP, RTP, RTSP, SNMP, ARP Alarm input: 2-way, semaphore Alarm output:...
Page 10 If the IP Camera supports PoE for power supply, please refer to the  precise parameters of the power switches to connect the devices. And, further test the maximum longest cables of the power, so as to avoid inadequate output power affecting the normal work of the IP Camera or damaging the switchboard.
Page 11 Chapter 2 IP Cam installation interface n No Please do not drop or strongly strike the device; Please do not directly expose the device to the sunshine or bright light. Otherwise, it shortens its life. Please avoid installing the device in the following environment: temperature over 50℃...
Page 12 Chapter 3 IE browser setting Browsing live video, User is supposed to adjust the monitor or the IE browser for other video picture and set some relevant data according to the interface prompt. Please pay attention to the following points: Internet Explorer 8.0 or higher version supports the device;...
Page 13 Picture 3-1 3. Choose internet icon, click “Customs level”. Then the follow pops up: Picture 3-2 １２...
Page 14 4. Change option “Download unsigned ActiveX controls” into “Enable” or “Prompt”. User can optionally change “Running ActiveX controls and plugins” into “Start” to avoid the prompt of running. Please take the tips as follows when installing the software of the IP camera: (1) Download controls First, please login to the system with IPC's default ID and password as a superuser (please refer to 4.1 login).
Page 15 (2) Install and run controls Please click “Run” in the prompt box above, and the controls are to be installed to run. After that, you are able to view the video in real time. Picture 3-4 Real Video If the above is not successful, please follow the steps here: Directly download the plugin from website wwww hobcn.com, and click “Run”...
Page 16 successful, then please try the website downloading method. 2. If your computer system is Microsoft Windows 2003 and you’re unable to view the video after installing the controls, please start the computer’s hardware acceleration. Above all is the preparation work for the video browsing on IE. １５...
Page 17 Chapter 4 System Operation Guide The chapter mainly introduces general setting and operation for the IP Camera. When the system starts up for 110 seconds, please open the IE browser, input the IP camera address. The default IP is http://192.168.1.18 (Note: System default subnet mask is 255.255.255.0;...
Page 18 Picture 4-1-1 login dialog If it is the first time you run the software, please login as a super user. The system default user name is admin (password is admin); input the correct user name and password, and click “login”. During login, if you would like to reset the username and password, please click “Cancel”...
Page 19: Video Browsing
The IP Camera supports H.264/MJPEG dual encoding format. After login, you will enter the real time video interface in the format of H.264 compression. User can click “MJPEG” button, and enter the real time video in the format of MJPEG. Please refer to picture 4-3 Picture 4-1-3 MJPEG video In the browsing interface, you can set video browse, PTZ control, commonly...
Page 20: Ptz Control
interface. Here is the picture: Picture 4-2-1 Video Browsing Menu Set the video in the menu above: Video Type: H.264 main stream, H.264 deputy stream, MJPEG. Video Size: screen original size 1*, original size *1/2, adaptive. Play mode: real time, smooth. Image Color: standard, vivid Illumination: Standard, low light 4.2.2 PTZ control...
Page 21: Ptz Functions
Picture 4-2-2 PTZ control icon PTZ direction: adjust the PTZ’s eight directions. Horizontal speed: 1 — 8 optional Vertical speed: 1 — 8 optional 4.2.3 PTZ functions PTZ functions: PTZ wipers, defogging, preset positions, horizontal scanning, pattern scanning, routine patrol. ２０...
Page 22: Common Shortcuts
Picture 4-2-3 PTZ functions setting PTZ wipers: ON-OFF call Defogging: ON-OFF-AUTO save Preset Positions: 1-254 call Horizontal scanning: 1--4 shot Pattern scanning: 1--4 shot Routine patrol: 1 shot 4.2.4 Common shortcuts Common shortcuts: photograph, record, audio input, audio output, Chinese-English conversion.
Page 23: Setting
Frequently set common functions of the IP cameras. The storage path of photographing and recording complies with the one from setting (please refer to 4.3.5 path storage). The snapshots are stored in the name of IP address and time of the device. For example, the file name is 20121006_221325_125_01_192.168.1.100.jpg, which means the device’s IP address is 192.168.1.100 and snapshot’s time is at 22:13:25:125 on Oct 6...
Page 24 System info: The initial interface of system setting is the display interface of system info. User can learn more about the setting info, like basic info, network parameter alarm setting, NTP setting, H.264 video parameter setting, MJPEG video parameter setting. Picture 4-2-5 IPC system info Basic Info: The IPC’s version number, time zone, product series, serial number.
Page 25 Picture 4-2-6 time setting Time zone setting: select your time zone from the drop down list, click “setting” it’s done. 26pcs time zones optional setting, range “GMT-12:00~GMT~GMT+13:00”. Of all, GMT+08:00 is China Beijing time. The default setting is GMT standard time. If your local time is daylight saving time, please click “automatically adjust clock for daylight saving changes”...
Page 26 button to synchronize. NTP Synchronization: whether to start NTP service. Select to start NTP service, otherwise do not select. If NTP service starts, you can input NTP server address in the IP field, and click “setting” button. After NTP is activated, the system corrects the time with NTP automatically.
Page 27: Network
and provide the latest software downloading, helping upgrade the IP Camera. User can upgrade the system as the following steps: Click “Browsing” icon, and select IFU upgrade file and upload it. Please restart the device after upgrading. Restore factory setting: The device’s network system provides online resetting functions, through which all system settings can be restored to factory default.
Page 28 Picture 4-3-1 network setting Network: setting of the device’s network parameter. Picture 4-3-2 Network setting DHCP: Dynamic Host Configuration Protocol, one of TCP/IP, mainly allocating dynamic IP address for network clients. Select “on”, the camera’s IP address and the subnet mask cannot be modified, but automatically allocated by the host. Select “off”, you’re supposed to set the network data by yourself and make sure the IP address and gateway address on the same segment.
Page 29 select “on”. FTP: FTP (File Transfer Protocol) is application layer protocol, based on transport layer for client’s service. FTP is in charge of transferring files. The IP camera supports FTP photo uploading function on alarming. On FTP interface, set the server address, username and password, activate FTP alarm at alarm setting, the FTP photo uploading can be realized.
Page 30 Picture 4-3-4 SMTP setting Server IP: set up mail server IP.  Sender: set up the email address of the sender.  Authentication: Turn on or off the authentication function via mail server  verification. User name: Sender’s name. User can set by itself. ...
Page 31 Picture 4-3-6 802.1X setting QoS: Quality of Service, a kind of network secure mechanism, a technology of solving network delay and congestion. Picture 4-3-7 QoS setting IGMP: It is a multi-cast protocol of internet family, helping IP Host report their membership to the adjacent reuters.
Page 32 SIP: Session Initiation Protocol is an application layer signal control protocol, creating, modifying and releasing one or multi participants. Picture 4-3-9 STP server DDNS: The user’s dynamic IP address is mapped to a fixed domain name resolution service. When connecting network each time, the client’s procedure would pass the host’s IP address to the server’s procedure which provides DNS service and ３１...
Page 33: Management Software
realize domain name resolution. That is, DDNS captures the changing IP address and corresponds the domain name, which is how other clients communicate. Picture 4-3-10 DDNS setting PORT: an interface, passing data between the computer and other devices (eg. Printer, mouse, keyboard, monitors), among network, or other computers in connection.
Page 34: Ip Cameras
Software initial user name is admin, while password is 123456. After login, you can find “search” button on the top of the interface, and click to search all IP cameras in the LAN area. Among all the camera lists found out, tick the ones you want to manage and click “save”...
Page 35 function. Picture 4-3-13 basic setting Power Frequency: 50HZ domestic use; 60HZ abroad use. Horizon Mirror: image horizontal mirror display. Vertical Mirror: image vertical mirror display. BLC: divided into different zones and each zone expose separately. BLC offers ideal exposure in front of strong back light. There is low, medium and high level optional.
Page 36 3D Noise debase: compare the images before and after setting, process and find out the noise positions and use AGC. 3D noise debase function would reduce the weak image signal interference. Expose set: expose mode, Color to Black, Scene select, AGC setting. Picture 4-3-14 Expose Setting Expose set: program mode, for normal video mode;...
Page 37 dims the image. Auto Iris: Auto Iris is the use of the signal feedback to drive the aperture. Adjust the motor quickly and flexibly to expand or shrink the aperture, which actually adjusts the aperture automatically. Bigger aperture at darkness and smaller one at brightness. Color to Black/white: Auto switch, control Color to B/W according to the camera video capture lighting;...
Page 38 white trim lines would appear next to both black lines and you will get distorted glare image. Brightness: unit projected area of brightness intensity would bring the overall brightness of the image. Over higher brightness would cause the insufficient permeability. Contrast: It is critical to the image effect.
Page 39: Audio & Video
Picture 4-3-16 White Balance Setting White Balance: auto, cloudy, Day (D65), Day (50), Fluorescent Light, Filament Lamp, Sun Up, Manual. Reset: fix the camera data. Click “Reset” to return to factory default. Picture 4-3-17 reset 4.3.6 Audio & Video Audio & Video: setting of camera audio, video, OSD, privacy and path. ３８...
Page 40 Picture 4-3-18 Audio & Video Setting Stream type: Main Stream, Minor Stream, MJPEG. Resolution: 1920*1080, 1280*1024, 1280*960, 1280*720, 640*480. Frame: the number of IP Cam’s processing compressed frames. If the number of the frame is set bigger, the image would become more continuity, but it reduces the performance of CPU processing other events.
Page 41 sufficient. CBR — image transmission with fixed bandwidth. Bit rate: 512K, 1024K, 2048K, 3072K, 4096K, 5120K, 6144K. The bit rate is higher the footprint is bigger, while the image is better. 720P/2M 1080P/4M are commonly used. I/P rate: the contrast of I frame and P frame. The bigger the ratio is, the data is smaller.
Page 42 Text OSD: set the subject and position. Choose On or Off to display the text or not. Input the content in the form after the text, where 24 characters can be displayed. X and Y coordinate is based on the zero coordinate on the upper left corner of the image.
Page 43 Picture 4-3-20 Motion Detection 【Sensitivity】: Setting motion detection sensitivity. The sensitivity can be set from 1 to 100. The smaller the number is, the higher the sensitivity is. Recommendation: 15. 【Zone】: You can set 4 motion detection zones. Each of them can be drawn and set with a mouse.
Page 44 Picture 4-3-21 Privacy IP Cameras support privacy zone function. When a special zone is not allowed to be seen by the operator, you can use this function. Through MASK setting, the specific zone is covered and the operator cannot see the video of the zone. 【Zone】: You can set 4 privacy zones.
Page 45: Ptz Funciton
Picture 4-3-22 Path The default is C drive control folder. Click browse to re-select the storage path. For the type of the file, photos is jpg/bmp and video is avi/ifv. 4.3.7 PTZ Funciton PTZ function: preset, autopan, pattern scanning, home return. Picture 4-3-23 PTZ function ４４...
Page 46 Preset: When the PTZ patrols to an important spot and commands a preset, the PTZ would record the location and status to build up the link. When the command is shot, the camera fast patrols to the spot and the camera returns to that memory. The operator obtains the spot fast and easily.
Page 47 Picture 4-3-25 Autopan Pattern: Picture 4-3-26 Pattern prptpcal set: ４６...
Page 48: Alarm
Picture 4-3-27 prptpcal set 4.3.8 Alarm Alarm: grounded circuit and open circuit for I/O. Set net contact or local contact. Picture 4-3-28 Alarm The IP camera supports 2 channel alarm in. User can set grounded or open ４７...
Page 49: User
circuit for each I/O. Alarm out contact: transmission method of alarm signal. Local contact: local alarm out. Default local contact. Net contact: internet transmission. Note: The functions requires the synchronous use of digital video management software, eg. HVMS. Choosing net contact, user is supposed to set the alarm IP as HVMS-CMS IP.
Page 50: Log
Picture 4-3-30 add user Input user name and password. Picture 4-3-31 check new users added 4.3.10 log Log: recording of each operation Picture 4-3-32 System log ４９...
Page 51: Appendix 1Toroid Filter Installation Manual
Appendix 1Toroid filter installation manual To reduce the interference of the power, user can install toroid filter on the power cable. Installation method as follows: Step 1: open the filter, put the power line through the toroid. Step 2: Twine the power cable around the filter housing at least 3 loops without affecting the normal close of the filter.
Page 52 Appendix 2 Common Failure Here is the common failure and solution Issue Possible reason Solution Wrong connection of the power cable Please re-connect the power Power failure Repair or change a good one fuse damage on PCB Change fuse Immediate reboot after power off Reboot after power off for 10 seconds IP Cam does not For PoE power, the transmission cable...
