Summary of Contents for Milre ML-6100

  • Page 1 DIGITAL DOOR LOCK SYSTEM DIGITAL DOO 6100 Notice...
  • Page 2: Product Features

    Product features Volume control by 8 levels Volume can be controlled at 8 different levels. Battery level indicator and alarm for battery replacement time Easy to check battery status with 3 step level indicator and alarming battery replacement time with sound & lamp. High reliance mechanical mortise lock type It has high reliability mechanical mortise lock type with installing the locking device on door body inside.
  • Page 3 DIGITAL DOOR LOCK SYSTEM Trespass alarm function When the door is opened by force with hammer or other devices, door lock function is suspended with alarm sound. Prevent mischief and hacking With 5 times of abnormal try with wrong secret code, function of door lock is suspended with alarm sound.
  • Page 4: Safety Precautions

    Safety precautions...
  • Page 5: Table Of Contents

    Product features Before using Safety precautions Contents Product composition and components Name and function of each part How to replace battery How to apply external power in the emergency How to use touch-pad and random security How to regiser/change secret mode How to register/change card key Basic function How to open from outdoor (secret code, card, mute function)
  • Page 6: Product Composition And Components

    Product composition and components...
  • Page 7: Name And Function Of Each Part

    Name and function of each part Front ass'y Battery replacement indicator Card key touch plate When the battery is low, red lamp Touch the registered card key is flickering. Please change batteries to open the door. to new one. Lock/Unlock lamp Indicate lock/unlock status.
  • Page 8 Name and function of each part Back ass'y Battery cover Push up to open the battery cover [10 key] button Battery - Registration/delete of code, card 8 pcs (1.5V, "AA" size, LR6 Alkaline) [R/C] button - Registration/delete of code, card LED indicator Low voltage indicator (Locking status)
  • Page 9: How To Replace Battery

    How to replace battery Please all batteries to new ones when the lamp flickers to red color with warning sound. If battery lamp in RED is Separate battery cover by Replace all 8 batteries to flickering with sound. pushing to arrow direction new one in same position as pressing arrow mark as like above picture.
  • Page 10: How To Apply External Power In The Emergency

    How to apply external power in the emergency 1. How to apply external power in the emergency When the battery is entirely exhausted and door lock is not activated, please contact 9V (6LF22) battery to emergency power terminal. Once the door lock is activated, open the door by secret code and replace the batteries in back ass'y.
  • Page 11: How To Use Touch-Pad And Random Security

    How to use touch-pad and random security coding function Random security coding function - Press any number randomly without limitation and then enter your secret code at final. With this function, you can open the door without revealing your secret code to others.
  • Page 12 Delete of individual secret code or card key is not available. To register multiple secret code, press new secret code successively and press [ ]. Max. 20 card keys can be registered. For high security, please use cards which are supplied by Milre Systek.
  • Page 13: How To Open From Outdoor (Secret Code, Card, Mute Function)

    How to open from outdoor Secret code / card / Mute function 1. Open the door using secret code Touch the front pad Press secret code Press [ ] and door (Ex : 1234) is unlocked 2. Open the door using card key 1) Touch the registered card key to card contact point.
  • Page 14: How To Lock The Door From Outdoor

    How to lock the door from outdoor 1. Lock the door at auto-locking mode When the door is closed, it is locked automatically with beeping sound. ※ If the door is not closed correctly, warning sound can be caused. Please check and confirm the door closing status. 2.
  • Page 15: How To Open From Indoor

    How to open from indoor PANIC RELEASE TYPE Just pulling down the handle, door lock is opened at anytime. What's "PANIC RELEASE"? Door can be opened with simple action of pulling down the handle. Even the door lock is out of order, people can escape easily in the emergency such as fire etc.
  • Page 16: How To Set Double Locking Function

    How to set double locking function In [Double lock] mode, function of door lock is suspended and can't open the door from outside. [Double lock] mode installed (RED) [Double lock] mode released (GREEN) Unlocking system from front body Normal operation is suspended.
  • Page 17: Auto-Locking System

    Auto-locking system When the door is closed, it will be locked automatically. (Please refer to next page for setting method.) Biririk ♪~Bikbik Auto-relocking system If the door is not opened within 7 seconds after input secret code, it will be relocked automatically to protect user's property. ♪~Biririk Biririk After...
  • Page 18: How To Set Auto/Manual Locking System

    How to set auto/manual locking system - In Auto-locking mode, door will be locked automatically after closing. - In Manual-locking mode, door will be locked with pressing manual lock button after closing. Touch the front pad Input secret code Touch the card key Press [ ] button (Ex : 1234)
  • Page 19: How To Control Volume Level

    How to control volume level Sound volume can be controlled by 8 levels. (Mute to maximum level) Touch the front pad Input secret code Touch the card key Press [ ] button (Ex : 1234) Press [ ] button [Volume down] [Volume up] Press 1 to make maximum level and press 0 to make mute in one time.
  • Page 20: Warning Function Against Mischief Or Hacking

    Warning function against mischief or hacking If wrong secret code or unregistered card is applied over 5 times, alarm system is activated with warning sound and all the function of door lock is suspended for one minute. ♪Biyoong~ Biyoong~ Applying wrong secret code over 5 times Applying...
  • Page 21 (Master code shall be different from user code.) ① ① ② ② Remove battery ① & ②, Press open button to Pressing [10Key] button, insert batteries one by one. make it discharge entirely. Input new master code Press [ ] button Input new master code Press [ ] button...
  • Page 22 ① ① ② ② Remove battery ① & ②, Press open button to Pressing [10Key] button, insert batteries one by one. make it discharge entirely. Input master code Press [ ] button Press [ ] button Press [ ] button (Ex : 5678) and completed.
  • Page 23 Touch the front pad Press [ ] button Input master code Press [ ] button for 3 seconds (Ex : 5678) Press [ ] button Input new master code Press [ ] button Input new master code (Ex : 3456) (Ex : 3456) (Max.
  • Page 24: How To Suspend / Release User's Code And Card

    How to suspend / release user's code and card Touch the front pad Input secret code Touch the card key Press [ ] button (Ex : 1234) Press [ ] button [Hold] mode [Release] mode...
  • Page 25 In case of master card is registered already Touch the front pad Press [ ] button Input registered Press [ ] button master card for 3 seconds Press [ ] button Input new master code Press [ ] button Input new master code (Ex : 3456) (Ex : 3456) In case master code is registered already.
  • Page 26 Touch the front pad Press [ ] button Input master card Input master code for 3 seconds (Ex : 3456) ※ If master card was not registered, there will be error sound. Press [ ] button Press [ ] button Press [ To delete master card, please proceed folloing steps.
  • Page 27 産品的特點 産品的特點 非法侵入警報功能 關門並産品處于上鎖狀態下,經3秒後將啓動非法進入警報功能。 如果門處於異常開鎖狀態,將發出2分鐘的警報。...
  • Page 28 安全注意事項 安全注意事項 請勿擅自折卸或任意改造本産品 分折或改造會對産品造成損傷,因改造發生的損傷會對您的財産造成損失, 産品的精密檢查及修理要交有認可的售後服務單位處理或聯系我公司顧客服務中心。 在産品上産生有害氣體泄漏及噴發煙霧時 請及時取下電池,要不然會對産品造成巨大的損傷。 産品不能接觸水或類似液體的東西 如果外部有水氣或液體時請用柔軟的抹布擦拭幹淨, 發現內部有進水或其他物質進入時請及時卸下電池。 定期(約6月)擦拭清理電池蓋部位 如果發現電池有液體泄漏,請用幹抹布擦拭幹淨並更換新電池, 泄漏的液體對人體有害,請及時用香皂洗手。 禁止使用酒精,鈊拿水等酸性物質擦拭本産品 使用此類物質會對本産品的外觀造成損傷或火災的隱患。 電池不要祼漏在有火源或發熱的地方 電池不能放置在發熱的地方或帶有火源的地方,也不能放入水中, 如果造成電池的損傷會導致腐蝕液體泄漏,請不要把已損傷的電池放入本産品。 電池電極部位不要寫鑰匙鏈或金屬物接觸 這可能會因發熱而導至暴躁,造成對本産品的損傷。 請勿在[鎖舌]凸起狀態下關門 將損傷産品並導致故障。 鍵版上不能有強烈的衝擊 會對此部位造成損傷或發生故障的隱患。 不能使用已用過的或種類不同的電池 會影響電池的使用壽命及發生漏液和發熱現象。...
  • Page 29 更換電池 室外體上端的電池標志下面的燈閃爍並電池更換警告音時,請立即更換全部電池並換成新電池。 電池更換警報提示音響起 把室內機上的電池蓋 請把8節電池按圖所示 沿著箭頭方向拉開 的方向全部更換 鹼性電池 須知事項 電池壽命按照每日使用10次爲准,可使用1年。 根據電池的生産商,生産日期,使用環境及使用次的不同,使用期限也有所不同。 在設置靜音狀態時不會發出電池更換警報提示音。 (指示燈或電池更換燈發光閃爍) 如果不同的或者使用過的電池混用的話電池壽命會變短期,無法開門。 充電式電池,不適宜使用在本産品上。 電池可能發生漏液會對本産品生産損傷,即使還沒有看到更換電池的時間也要定期(約6個月) 檢查確認,如有反生漏液線上,請把所有電池全部更換。 如果電池反過來插入的話會發生漏液和破裂。...
  • Page 30 外部應急電源使用辦法 1.外部應急電源使用辦法 如果已用完電池並無法再用內部電池鎖定時,將四方形的9V電池解除到緊急電源瑞口, 然後使用密碼或感應卡進行開鎖。 ...? 無反應 ..按上圖打蓋子拉下板蓋 用9V電池接觸緊急瑞口後, 使用密碼或感應卡進行開鎖 2.使用鑰匙的辦法 按上圖打蓋子拉下板蓋 鑰匙插入鑰匙孔, 把手往下轉動就開門 維持解鎖定狀態不放 須知事項 外部緊急電源接瑞子是無方向性的。 外部緊急電源,請僅在內部電池用完並無法運作時使用。 鑰匙一定要放在屋外安全處或者隨身攜帶以防萬一。 解鎖開門後,記得將鑰匙拔出好好保管。 鑰匙丟失時要聯系到經銷商,在更換鑰匙鎖芯。 (要更換鑰匙鎖芯費用是顧客全部承擔。)
  • Page 31 觸控面板及虛位密碼功能使用 本産品是觸控方式的。接觸觸控面板就提示數字燈後用手指按密碼開鎖。 與他人同行入戶時,先任意按下幾個數字(虛位密碼),然後輸入正確密碼開鎖。 採用這種無限虛位密碼功能系統,更進一步強化了保護密碼的功能。 接觸觸控面板 數字燈發光 先任意按下幾個數字(例:1389) 輸入密碼(例:1234) 按[*]鍵後往下轉動就開門 須知事項 使用虛位密碼功能是要最後使用已經設定進去的密碼才可以開鎖。 觸控式數位板要用手掌或手指頭去點。 帶手套的情況下去使用出現無動作或異常狀況。 輸入是動作太快或按兩個鍵一起的時候不會讀數字。 如果在數位板上有異物的話會發生無動作或錯誤動作,所以保持乾淨。 清潔數位板時請使用柔軟,不濕的棉布。 設定與變更密碼 打開電池蓋, 輸入使用者密碼 按[ ]鍵, 按[10KEY] (EX : 1234) (吡喱吡喱)音 即可完成。 須知事項 原廠密碼設置爲‘①②③④’。 密碼可以設定8組密碼,可設置爲4~12位數 連續設定一個以上密碼時,輸入新使用者密碼再按[ ]鍵的順序連續按鍵即可. 如果8個使用者密碼未全部設定而要完成設定時,請按[ ]鍵. 設定新使用者密碼後以前設定的密碼將被自動刪除. 請開著門後進行設定或變更使用者密碼. 請記住變更的使用者密碼如果把密碼丟失時,則無法開鎖. 密碼,感應卡設定與刪除時,都可以使用[10key]鍵與[R/C]鍵...
  • Page 32 設定與刪除感應卡 1. 設定感應卡 打開電池蓋 按[10Key] 將每張感應卡連續 接觸在室外機的 感應卡感應區即 可依次設定 2. 全部刪除感應卡 打開電池蓋後短按 按[0]鍵 按[#]鍵, 確認刪除 [10KEY]鍵(吡) (吡喱喱喱~) 須知事項 如果設定新的感應卡,則以前設定的感應卡將全部被刪除。 如果20張感應卡未全部設定而要完成設定時,請按[ ]鍵。 請使用本公司提供的專用感應卡。 如果把已設定感應卡丟失,則無法開鎖,只能破壞産品。...
  • Page 33 從外部開鎖 密碼 / 感應卡 / 靜音功能 1.用密碼開鎖 觸控觸控面板 輸入密碼(例:1234) 按[ ]鍵後開鎖 2.用感應卡開鎖 1) 把感應卡接觸在室外機的 感應區即可開鎖 2) 拉下室外機的把手時, 即可開門 3.靜音功能開鎖(無操作音開鎖) 1. 密碼 接觸長壓觸控面板 輸入密碼 按[ ]鍵後開鎖 1秒以上後數字閃爍2次 (例:1234) 2. 感應卡 接觸長壓觸控面板 把感應卡接觸在室外機的 1秒以上後數字閃爍2次 感應區即可開鎖 須知事項 如果用密碼或感應卡開鎖並轉動把手後仍不開門,則會發出鎖定錯誤的警報音。...
  • Page 34 從外部鎖定 1.自動上鎖設置狀態下上鎖 ~吡吡)音並同時即可自動上鎖。 關門及發出( ~吡吡 ※ 關門時,請將把手保持平穩。 否則會發出鎖定錯誤的警報音 2.手動上鎖設置狀態下上鎖 ~吡吡 關門後觸摸數位版 按[0]鍵即可上鎖 ※在手動上鎖設置狀態下關門後也不會自動上鎖 須知事項 上鎖後必須轉動把手確認是否上鎖好。...
  • Page 35 從內部開鎖 “採用緊急解救方式” 從內部轉動把手即可開鎖 * 請將把手轉動最低位置。 緊急解救方式是什麽? 是指僅用室內機把手即可開門的方式。 * 請注意如果轉動把手後不開門, 産品將處於開鎖狀態,會發出上鎖錯誤的警報音 從內部開鎖 1.在內部上鎖 2.在手動上鎖設置狀態下上鎖 [自動上鎖]設置狀態關門即發出 關門後將按[手動上鎖]鍵發出 (~吡~吡~吡喱喱)音,同時即可自動上鎖。 (~吡喱喱)音,同時即可上鎖。 關門後將按 [手動上鎖]鍵 關門時 ♪~ 吡喱喱 ♪ 吡~吡~ 吡喱喱 關門後指示 關門後指示 燈會閃爍 燈會閃爍。 須知事項 關門時方舌在彈出來的狀態下不得關門,這時轉動把手讓方舌縮回去後再關門。 ※ 關門時,請將把手保持平穩。否則會發生上鎖錯誤的警報音。...
  • Page 36 雙重上鎖功能 [雙重上鎖]設置後在外部不能開鎖進入。(將停止産品的正常運作) ※在關門的狀態下請設置這個功能。 [雙重上鎖]設置狀態(紅色) [雙重上鎖]解除狀態(綠色) (停止運作) (正常運作) 須知事項 如果開門狀態下設置[雙重上鎖]後關門時,[雙重上鎖]設置將無效, 可以在外部用密碼或感應卡開門。 即使是[雙重上鎖],在室內只要轉動手把就可以開門。 (在室內轉動手把,[雙重上鎖]將被自動解除。) 設置[雙重上鎖]狀態下,非法入侵警報功能正常啓動。 設置爲靜音後,[雙重上鎖]提示音是靜音狀態,只閃爍燈光。...
  • Page 37 自動上鎖功能 是指關門後門鎖將會自動上鎖的功能。 ♪~ 吡喱喱 吡吡 自動反鎖功能 用密碼,感應卡與指紋開鎖了後7秒內不開門時將自動上鎖爲了保護顧客的財産。 ♪~ 吡喱喱 吡喱喱 7秒後 没有上鎖的情况下 自動反鎖 須知事項 自動上鎖功能不能接觸,與自動/手動上鎖功能設置無關。...
  • Page 38 [自動/手動]上鎖功能 - 上鎖方式設置爲[自動上鎖],在關門時,會自動上鎖。 - 上鎖方式爲[手動上鎖]。即使關門也不會上鎖。 或 輸入密碼 接觸感應卡 觸控觸控面板 按[#]鍵 (例:1234) 按[#]鍵 按數字5爲[自動上鎖] 按數字6爲[手動上鎖] 須知事項 如果設置爲[手動上鎖]時,必須以設定過的密碼,感應卡, 指紋或室內機把重新關一次門,才會保持開鎖狀態。...
  • Page 39 大小音量設定 小大音量可設定靜音到最大音量分8階音量。 或 輸入密碼 接觸感應卡 觸控觸控面板 按[#]鍵 (例:1234) 按[#]鍵 按數字2爲[音量減少] 按數字3爲[音量增加] ※如果要把操作音直接調到最大,請按1號。 如果要把操作音直接調到最小,請按0號。 須知事項 如果操作音設置爲靜音,按下數字鍵時,按數字燈將會閃爍表示。...
  • Page 40 防騷擾及防密碼破解警報功能 連續輸錯5次密碼或連續接觸未設定的感應卡5次時, 將啓動防騷擾及防密碼破解警報功能並發出警報音,同時將停止1分鍾的功能運作。 嘀嗡~ 嘀嗡~ ♪ 連續輸錯密碼 5次 連續接觸 未設定的感應卡 5次 發出警報音, 同時將停止1分鐘的功能運作 非法侵入警報功能 關門並産品處于上鎖狀態下,經3秒後將啓動非法進入警報功能。 如果門處於異常開鎖狀態,將發出2分鐘的警報。 警報音解除辦法 嘀嗡~ 嘀嗡~ 1.接觸感應卡 2.認證密碼 或 接觸感應卡 輸入密碼 按[ ]鍵, (例 1234) 解除警報音 須知事項 防騷擾及防密碼破解功能啓動後至自動解除,需要等1分鐘. 産品功能處于停止狀態下,按[10key]或[R/C]或[手動上鎖]鍵,可以接觸停止狀態. 非法侵入警報音將發出2分鐘. 發出非法進入警報音時,如用密碼或感應卡解除警報音,則即可恢複正常運作狀...
  • Page 41 設定管理者模式 (不能設定一樣的使用者密碼和管理者密碼) ① ① ② ② 把電池拿出來 按[手動上鎖]鍵 按著[10KEY]鍵,同時插入2個電池 輸入管理者密碼 按[ ]鍵 再輸入管理者密碼 按[#]鍵, (例:5678) (例:5678) (吡喱喱喱)音 即可完成。 (可以設定3張管理者感應卡) ① ① ② ② 按著[10KEY]鍵,同時插入2個電池 把電池拿出來 按[手動上鎖]鍵 ※ 如果3張管理者感應卡未全部設定而要完成設定時, 請按[ ]鍵。 接觸感應卡 (吡喱吡喱) 須知事項 請注意丟失因爲管理者密碼可以設定一般使用者的使用停止等。 管理者密碼可以設定1組密碼,雖然管理者密碼設定好了,但是使用者密碼可以保持。...
  • Page 42 解除管理者模式 ① ① ② ② 按著[10KEY]鍵,同時插入2個電池 把電池拿出來 按[手動上鎖]鍵 輸入管理者密碼 按[#]鍵 按[ ]鍵 按[#]鍵, (例:5678) (吡喱喱喱)音 即可完成。 ※ 如果解除管理者模式的話管理者密碼與管理者感應卡都被刪除。 ① ① ② ② 按著[10KEY]鍵,同時插入2個電池 把電池拿出來 按[手動上鎖]鍵 接觸管理者感應卡 按[#]鍵 按[ ]鍵 按[#]鍵, (吡喱喱喱)音 即可完成。 ※如果解除管理者模式的話管理者密碼與管理者感應卡都被刪除。...
  • Page 43 變更管理者密碼或管理者感應卡 接觸觸控面板 按[ ]鍵3秒 輸入管理者密碼 按[ ]鍵 (例:5678) 按[ ]鍵 再輸入新的 按[ ]鍵 輸入新的 管理者密碼 管理者密碼 (例:3456) (例:3456) 可以設定3張管理者感應卡 按[ ]鍵3秒 按[ ]鍵 接觸觸控面板 接觸管理者感應卡 ※如果3張管理者感應卡未全部設定而要完成設定時, 請按[ ]鍵。 接觸新的管理者感應卡...
  • Page 44 設定及解除使用在管理模式下[停止使用者密碼和使用者感應卡]功能 或 輸入密碼 接觸管理者感應卡 觸控觸控面板 按[#]鍵 (例:1234) 按[#]鍵 4爲設定 [停止使用] 7爲解除 [停止使用]...
  • Page 45 設定管理者密碼或管理者感應卡 已經設定好了管理者感應卡的時候要設定管理者密碼,可以進行如下。 接觸觸控面板 按[ ]鍵3秒 接觸已設定的 按[ ]鍵 管理者感應卡 輸入新的管理者密碼 再輸入新的管理者密碼 按[ ]鍵 按[ ]鍵 (例:3456) (例:3456) 可以設定3張管理者感應卡 已經設定好了管理者密碼的時候要設定管理者感應卡,可以進行如下。 接觸觸控面板 按[ ]鍵3秒 按[ ]鍵 輸入已設定的管理者密碼 (例:5678) ※ 管理者感應卡可以設定3張感應卡。 ※ 如果3張管理者感應卡未全部設定而要完成設定時,請按[ ]鍵。 接觸管理者感應卡...
  • Page 46 刪除管理者密碼或管理者感應卡 爲了刪除管理者密碼或管理者感應卡,管理者密碼與管理者感應卡都設定好,就可以刪除。 或 接觸觸控面板 按[ ]鍵3秒 接觸管理者密碼 輸入管理者密碼 (例:3456) ※ 如果沒有設定管理者感應卡 的話不能刪除管理者密碼, 同時發出失誤音。 哔-哔- 按[ ]鍵 按[ ]鍵 按[ ]鍵 或 接觸觸控面板 按[ ]鍵3秒 接觸管理者密碼 輸入管理者密碼 (例:3456) ※ 如果沒有設定管理者密碼 的話不能刪除管理者感應卡, 同時發出失誤音。 哔-哔- 按[ ]鍵 按[ ]鍵 按[ ]鍵...
  • Page 47 産品品質保證書 産品保證期爲自安裝日起一年。 (銷售單位填寫) 安裝日期 型 號 編號 (購買日期) 顧客姓名 地址 電 話 銷售單位 負責人 電話 請妥善保管産品質量保證書。 在售後服務時,必須出事産品質量保證書,後則按資費維修處理。 如無産品編號,視爲非正品,因此按自費維修處理。...
  • Page 48 Scans the Product QR code to View Detailed Device Information.
