LT Security CMR6570DW User Manual

Day/night high-definition bullet camera

Advertisement

Quick Links

Day/Night High-definition

Bullet Camera

User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CMR6570DW and is the answer not in the manual?

Questions and answers

Summary of Contents for LT Security CMR6570DW

  • Page 1: Bullet Camera

    Day/Night High-definition Bullet Camera User Manual...
  • Page 2 Day/Night High-definition Bullet Camera·User Manual Thank you for purchasing our product. If there are any questions, or requests, please do not hesitate to contact the dealer. This manual may contain several technical incorrect places or printing errors, and the content is subject to change without notice. The updates will be added to the new version of this manual.
  • Page 3: Regulatory Information

    Day/Night High-definition Bullet Camera·User Manual Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 4 Day/Night High-definition Bullet Camera·User Manual 2002/96/EC (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points.
  • Page 5: Safety Warnings And Cautions

    Day/Night High-definition Bullet Camera·User Manual Safety Warnings and Cautions Please pay attention to the following warnings and cautions: Hazardous Voltage may be present: Special measures and precautions must be taken when using this device. Some potentials (voltages) on the device may present a hazard to the user. This device should only be used by Employees from our company with knowledge and training in working with these types of devices that contain live circuits.
  • Page 6 Day/Night High-definition Bullet Camera·User Manual System Grounding (Earthing): To avoid shock, ensure that all AC wiring is not exposed and that the earth grounding is maintained. Ensure that any equipment to which this device will be attached is also connected to properly wired grounded receptacles and are approved medical devices.
  • Page 7 Day/Night High-definition Bullet Camera·User Manual Dispose of used batteries according to the vendor’s instructions and in accordance with local environmental regulations. Perchlorate Material: Special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate. This notice is required by California Code of Regulations, Title 22, Division 4.5, Chapter 33: Best Management Practices for Perchlorate Materials.
  • Page 8 Day/Night High-definition Bullet Camera·User Manual required to take measures to eliminate the interference or discontinue the use of this equipment. Lead Content: Please recycle this device in a responsible manner. Refer to local environmental regulations for proper recycling; do not dispose of device in unsorted municipal waste.
  • Page 9: Safety Instruction

    Day/Night High-definition Bullet Camera·User Manual Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions” Warnings: Serious injury or death may occur if any of the warnings are neglected.
  • Page 10 Day/Night High-definition Bullet Camera·User Manual responsibility for problems caused by unauthorized repair or maintenance.) To reduce the risk of fire or electrical shock, do not expose this  product to rain or moisture. This installation should be made by a qualified service person ...
  • Page 11 Day/Night High-definition Bullet Camera·User Manual The sensor may be burned out by a laser beam, so when any  laser equipment is being used, make sure that the surface of the sensor will not be exposed to the laser beam. Do not place the camera in extremely hot or cold temperatures ...
  • Page 12: Table Of Contents

    Day/Night High-definition Bullet Camera·User Manual Table of Contents 1 Introduction ..............1 1.1 Product Features ..........1 1.2 Function Summary ..........2 1.3 Overview .............5 2 Installation ..............6 2.1 Mounting .............6 2.1.1 Wall Mounting ..........6 2.1.2 Wall Mounting With a Junction Box ....8 2.1.3 Wall Mounting With a Gang Box ....
  • Page 13: Introduction

    Day/Night High-definition Bullet Camera·User Manual 1 Introduction 1.1 Product Features This camera adopts high performance CCD and advanced print circuit board design technology. It possesses of high resolution, low distortion, and low noise features, etc. It is extremely suitable for supervisory system and image process system. Adopt high performance SONY CCD, and supply high definition ...
  • Page 14: Function Summary

    Day/Night High-definition Bullet Camera·User Manual Support Privacy mask with 8 optional colors and 8 configurable  areas Advanced design technology with high reliability  Advanced 3-axis design allows this bullet camera to be  adjusted 0-355° horizontally and 0-180° vertically to meet different mounting requirements Adopt advanced double-plate design to guarantee the heat ...
  • Page 15 Day/Night High-definition Bullet Camera·User Manual Figure 1-1 Privacy Mask DAY/NIGHT Auto Switch: The cameras deliver color images during the day. And as light diminishes at night, the cameras switch to night mode and deliver black and white images with high quality.
  • Page 16 Day/Night High-definition Bullet Camera·User Manual Internal synchronization is realized by the synchronous signal which is generated by the inside crystal oscillator. White Balance: White balance can remove the unrealistic color casts. White balance is the white rendition function of the camera to adjust the color temperature according to the environment automatically.
  • Page 17: Overview

    Day/Night High-definition Bullet Camera·User Manual 1.3 Overview Figure 1-3 Overview Table 1-1 Descriptions Serial NO. Description Sun shield Front cover Main body Bracket Junction box...
  • Page 18: Installation

    Day/Night High-definition Bullet Camera·User Manual 2 Installation Before you start: Please make sure that the device in the package is in good condition and all the assembly parts are included. Note: Please ensure that the wall is strong enough to withstand three times the weight of the camera.
  • Page 19 Day/Night High-definition Bullet Camera·User Manual Figure 2-1 Drilling Holes in the Wall 3. Route the cables of the camera. 4. Secure the camera to the wall with expansion bolts. Refer to the Figure 2-2.
  • Page 20: Wall Mounting With A Junction Box

    Day/Night High-definition Bullet Camera·User Manual Figure 2-2 Secure the Camera 2.1.2 Wall Mounting With a Junction Box Steps: 1. Attach the drill template (supplied) to the wall where the camera is to be mounted. 2. Drill holes in the wall according to the number two holes of the drill template.
  • Page 21 Day/Night High-definition Bullet Camera·User Manual Figure 2-3 Drilling Holes in the Wall 3. Secure the junction box to the wall with expansion bolts. 4. Route the cables of the camera.  If there is a hole in the wall, route the cables from the camera through the holes on the bottom of the junction box and into the wall.
  • Page 22: Wall Mounting With A Gang Box

    Day/Night High-definition Bullet Camera·User Manual 5. Hook the camera to the junction box with the safety rope. Refer to the Figure 2-4. 6. Secure the camera to the junction box with screws. Figure 2-4 Mounting with a Junction Box 2.1.3 Wall Mounting With a Gang Box Steps: 1.
  • Page 23 Day/Night High-definition Bullet Camera·User Manual Gang Box Wall Camera Attachment Figure 2-5 Secure the Camera Attachment 2. Route the cables of the camera. 3. Secure the camera to the camera attachment with screws. Refer to the Figure 2-6.
  • Page 24 Day/Night High-definition Bullet Camera·User Manual Figure 2-6 Secure the Camera...
  • Page 25: Power Connection

    Day/Night High-definition Bullet Camera·User Manual 2.2 Power Connection Power Video Figure 2-7 Camera connection Please make sure that the power adapter can match with the camera which usually should be supplied with 12 V DC or 24 V AC (Refer to the camera specifications for more detailed information). 2.3 Pan Tilt Rotation Adjusting Purpose: 3-axis (pan/tilt/rotation) adjusting allows adjustment for optimum...
  • Page 26 Day/Night High-definition Bullet Camera·User Manual Steps: 1. Loosen the lock screw-1. 2. Adjust the panning position of the camera. The adjusting range is from 0 degrees to 360 degrees. 3. Tighten the lock screw-1. Tilt Adjustment Steps: 1. Loosen the lock screw-2. 2.
  • Page 27: Zoom And Focus Adjusting

    Day/Night High-definition Bullet Camera·User Manual Figure 2-8 3-axis Adjusting 2.4 Zoom and Focus Adjusting Purpose: There is a place under the bottom of the camera. You can adjust the zoom value and the focus value in this place. Steps: 1. Loosen the screw at the bottom of the camera. 2.
  • Page 28 Day/Night High-definition Bullet Camera·User Manual 8. Tighten the screw firmly to secure the lid for avoiding water leakage. Figure 2-9 Zoom and Focus Adjustment...
