Page 1: Operating Instructions
4-693-530-11 (1) Video Projector Operating Instructions Before operating the unit, please read this manual, supplied Quick Reference Manual, and Safety Regulations thoroughly and retain it for future reference. VPL-VZ1000 © 2017 Sony Corporation... -
Page 2: Table Of Contents
Table of Contents Operating the Control Window ......... 30 Location of Controls Switching the Page ..........30 Setting the Access Limitation ......30 Main Unit ..............3 Confirming the Information Regarding the Control Panel/Connecters/Projection Window ... 4 Unit ..............30 Remote Control ............ -
Page 3: Location Of Controls
Location of Controls Main Unit a Ventilation holes (exhaust) f Side covers (page 10) b Top cover (page 10) g Feet (adjustable) (page 8) c Remote control detector (page 6) h Air filter (Ventilation holes (intake)) (page 35) d LED indicator (page 6) / WARNING1 indicator i Ventilation holes (intake) (page 31) e WARNING2 indicator (page 31) -
Page 4: Control Panel/Connecters/Projection Window
Control Panel/Connecters/Projection Window a ?/1 (On/Standby) button (page 6) l AC IN socket b INPUT button (page 12) m HDMI 3/HDMI 4 connectors (page 9) c MENU button (page 15) n Projection window (lens) Projects a video from this window. d M/m/</,/ ENTER button (page 15) Note e LENS button (page 6) -
Page 5: Remote Control
a LIGHT button Remote Control Illuminates the buttons on the remote control. b Infrared transmitter c ?/1 (On/Standby) button (page 6) d INPUT button (page 12) e CALIBRATED PRESET buttons (page 14) f PATTERN button (page 6) g RESET button (page 16) h M/m/</, / (enter) buttons (page 15) i MENU button (page 15) -
Page 6: Connections And Preparations
Connections and Preparations Installing the Unit Adjusting the Projection Image The installation distance between the unit and a projection surface varies depending on the projection size. Install this unit so that it fits the desired projection size. For details on When adjusting the lens, each time you press the PATTERN button the distance between the unit and the projection surface of the remote control or the LENS button on the unit, the lens... - Page 7 Check if the upper side and lower side of the picture Image distortion Feet adjustment are parallel. If not, install the unit in a position parallel to the projection surface (a=b). Image distortion Installation state to the projection surface (Top view) Side view a >...
- Page 8 To adjust the horizontal position Adjusting the height of the feet When pressing the </, button, the picture You can adjust the height and tilt of the unit using the three projected on the screen moves right or left by a feet at the bottom of the unit, and prevent backlash of the maximum of 3% of the screen width from the center unit using the two feet.
-
Page 9: Connecting To Video Equipment Or A Computer
Connecting to Video Equipment or a Computer When making connections, be sure to do the following: • Turn off all equipment before making any connections. • Use the proper cables for each connection. • Insert the cable plugs properly; poor connection at the plugs may cause a malfunction or poor picture quality. When pulling out a cable, be sure to pull it out from the plug, not the cable itself. -
Page 10: Attaching The Top Cover
Attaching the Top Cover Attaching the Side Covers Place the top cover on the top of the unit, and align the left After attaching the top cover, place the side covers by hooking the holes of the side covers to the tabs on the side and right position. - Page 11 Attach a safety rivet to the unit. Rivet (supplied) Attach the side covers. Note When installing the unit on a ceiling, do not attach the top cover.
-
Page 12: Projecting The Picture And Adjusting The Screen
Projecting the Picture and Adjusting the Screen Projecting the Picture Watching 3D Video Images Turn on both the unit and the equipment connected to the unit. You can enjoy powerful 3D video images, such as from 3D games and 3D Blu-ray Discs, using the optional Active 3D Press INPUT to display the input palette on the Glasses (TDG-BT500A). -
Page 13: Using The 3D Glasses
Using the 3D Glasses Selecting the Aspect Ratio Turn on the 3D glasses, and register them on the unit. For details on how to register the 3D glasses, refer to the operating instructions supplied with the 3D Each time you press the ASPECT button, the “Aspect” glasses. -
Page 14: Selecting The Picture Viewing Mode
Original image (for 16:9 Recommended setting and Selecting the Picture display) resultant images Normal Viewing Mode With the CALIBRATED PRESET buttons, you can select the picture viewing mode that best suits the type of video 1.78:1 (16:9) source or room conditions. You can save and use different preset modes for 2D/3D respectively. -
Page 15: Using The Menus
Using the Menus Note The menu displays used for the explanation may be different from the actual menu display. Pop-up menu Operation through the Setting items Menus The unit is equipped with an on-screen menu for making various adjustments and settings. If you select an item name followed by an arrow (B), the next menu window with setting items appears. - Page 16 When changing the setting Press M/m to change the setting. Press to return to the original screen. You can return to the original screen using < depending on the selected item. To clear the menu Press MENU. To reset the picture that has been adjusted Select “Reset”...
-
Page 17: Picture Menu
Database: Select “Normal” or “Mastered in 4K.” “Mastered in 4K” provides image quality suitable for Blu-ray Disc™ “Mastered in 4K” releasing from Sony Pictures Home Entertainment. Resolution: When you increase the setting value, the texture and detail of the picture become sharper. - Page 18 Setting items Description Motionflow [MOTIONFLOW] Smooth High: Provides smoother picture movement; especially effective for film-based content. Smooth Low: Provides smoother picture movement for standard use. True Cinema: Images, such as a movie created in 24 frames per second, are reproduced at the original framerate.
- Page 19 Setting items Description Smooth Gradation Smooths the gradation of the flat parts of images. High/Middle/Low: You can adjust the smooth gradation effect. Off: The smooth gradation function is not applied. Film Mode According to the film source you have selected, make a setting for playback. Auto: Suitable for reproducing the original picture movement.
- Page 20 Setting items Description Color Space Converts the color space. [COLOR SPACE] BT.709: An ITU-R BT.709 color space, which is used for high-definition television broadcast or Blu-ray Disc. The color space is equivalent to sRGB. BT.2020: The color space suited for watching images with BT.2020, such as HDR content. Color Space 1: The color space suited for watching TV programs and video images, such as sport, concerts, etc.
-
Page 21: Advanced Picture Menu
Advanced Picture Menu You can adjust the gaps in color that have occurred after a long period of use. Setting items Description Auto Calibration Pre Check: Checks the color difference against the factory default settings, before calibration starts. Adjust: Performs Auto Calibration. Before/After: Toggles the factory default settings and the setting after the calibration at a certain frequency. -
Page 22: Screen Menu
Screen Menu You can set the picture size, aspect mode, etc. Note These items may not be available, depending on the type of input signal. For details, see “Input Signals and Adjustment/Setting Items” (page 39). Item names in brackets represent those printed on the remote control. Setting items Description Aspect... -
Page 23: Setup Menu
Notes • When “All Off” is selected, warning message for high temperature is not displayed. • Note that Sony is not liable for failure of the unit or any accident caused by selecting “All Off.” Language Selects the language used in the menu and on-screen displays. -
Page 24: Function Menu
Function Menu The Function menu is used for changing the settings of the various functions of the unit. Setting items Description 3D Settings You can change the settings of the 3D function. 2D-3D Display Sel. For Switching the video images to “2D” or “3D.” Auto: Displays 3D video images when HDMI signals with 3D information* are input. -
Page 25: Items Locked By Settings Lock
Setting items Description HDMI Signal Format Switches the video signal formats for 4K. Standard Format: Displays a picture in the standard HDMI format. Normally use this setting. Enhanced Format: Use this setting when the HDMI format with a wider band frequency is used. Tips •... -
Page 26: Installation Menu
Installation Menu The Installation menu is used for changing the installation settings. Setting items Description Image Flip Flips the picture on the screen horizontally and/or vertically. Use this item for installation for the rear projection or ceiling installation. HV: Flips the picture horizontally and vertically. H: Flips the picture horizontally. - Page 27 Setting items Description Reset: Returns to the factory settings. Preset: The optimized data has been preset. Note Depending on the adjustments made above, colors may become uneven or the resolution may change. Flange Back Correction Adjust the focus by pressing the M/,/ m/< buttons. Tips •...
-
Page 28: Information Menu
Information Menu The Information menu displays the model name, serial number, input signal type, and software version. Items Description Model Name Displays the model name Serial No. Displays the serial number. Signal type Displays the resolution of the video which you are watching. When input signals with 3D information are input, the type of input signals and the 3D format are displayed. -
Page 29: Network Features
(SDAP [Advertisement], SDCP [PJ Talk], When connecting by the IPv6 address DDDP [AMX], Crestron RoomView, Control4, ADCP http://[xxxx:xxxx:- xxxx] (Sony Advanced Display Control Protocol)). You can confirm the IP address of the unit under Notes “Network Setting” on the Installation menu. -
Page 30: Operating The Control Window
The default password “Projector” cannot be set as a new Operating the Control password. Window Note If you forget your password, consult with qualified Sony personnel. Switching the Page Confirming the Information Regarding the Unit Click one of the Page Switching buttons to display the desired setting page. -
Page 31: Error Handling
The unit detects a drop impact. (Flashes in red) If there is abnormality on the unit, consult with qualified Sony personnel. If there are no abnormalities on the unit, disconnect the AC power cord and check that the LED indicator turns off, then connect the AC power cord and turn the unit Twice The internal temperature is unusually high. -
Page 32: Message Lists
Message Lists Warning messages Symptom Cause and Remedy High temp.! Light off in 1 min. Turn off the power. Check to ensure that nothing is blocking the ventilation holes and the air filter is not clogged. (page 3, 35) Frequency is out of range! Input a signal that is within the acceptable frequency range of the unit. -
Page 33: Troubleshooting
Troubleshooting If the unit appears to be operating erratically, try to diagnose and correct the problem using the following instructions. If the problem persists, consult with qualified Sony personnel. Power Symptom Cause and Remedy The power is not turned on. - Page 34 3D video images Symptom Cause and Remedy The video image does not seem like Check if the 3D glasses are turned on. (page 13) 3D video images. Make sure that the battery in the 3D glasses is sufficiently charged. Set “2D-3D Display Sel.” to “Auto” or “3D.” (page 24) Check if the input signals are compatible 3D signals.
-
Page 35: Maintenance
If dust is For details on a new air filter, consult with qualified Sony persistent, wipe with a soft cloth slightly moistened with personnel. -
Page 36: Others
USB memory to the USB terminal of the unit, then perform the update. To update the software of the unit, your PC must be able to connect to the Internet. Download the update files from the following Sony website: http://www.pro.sony.eu/ The website also explains how to install the update. -
Page 37: Specifications
• The values for mass and dimensions are approximate. • Not all optional accessories are available in all countries and area. Please check with your local Sony Authorized Dealer. • Information on accessories in this manual is current as of January 2017. -
Page 38: Preset Signals
Preset Signals The following table shows the signals and video formats which you can project using this unit. When a signal other than the preset signals shown below is input, the picture may not be displayed properly. Preset memory Preset signal (resolution) fH (kHz) fV (Hz) Sync... -
Page 39: Input Signals And Adjustment/Setting Items
Preset memory Preset signal (resolution) fH (kHz) fV (Hz) Sync 3840 × 2160/30p 3840 × 2160/30p (3840 × 2160) 67.433 29.970 – 4096 × 2160/24p 4096 × 2160/24p (4096 × 2160) 54.000 24.000 – Preset memory numbers for each input signal Digital signal Signal Preset memory number... -
Page 40: Compatible 3D Signals
Input signal Item Component signal Video GBR signal Computer signal Color Space : Can be adjusted/set –: Cannot be adjusted/set Screen menu Input signal Item Component signal Video GBR signal Computer signal Aspect* (excluding preset memory (excluding preset memory – numbers 76 to 79 and 96) numbers 78, 79 and 96) : Can be adjusted/set... -
Page 41: 3D Signals And Adjustment/Setting Items
3D Signals and Adjustment/Setting Items Some items on the menus may not be available to adjust/set, depending on the 3D signals. The items that cannot be adjusted are not displayed on the menu. The following tables indicate those items. 3D signals Item 720/60p, 720/50p 1080/60i, 1080/50i... -
Page 42: Aspect Mode
Aspect Mode Selectable items vary depending on the type of input signal or 3D format. For details, see the tables below. Items that cannot be selected are not displayed in the menu. Acceptable signals 720 × 480 4096 × 2160 3840 ×... - Page 43 Picture menu Item Storage conditions Calib. Preset For each input connector and preset signal Reset For each input connector and Calib. Preset Reality Creation Laser Light Setting Contrast Enhancer Motionflow Contrast Brightness Color Color Temp. D93 - D55, Custom Gain R For each Color Temp.
-
Page 44: Installation Distance And Projection Image Size
Installation Distance and Projection Image Size L1: Distance from a projection surface to the rear of the unit L2: Distance from a projection surface to the front of the unit H: Distance from the installation surface to the bottom of the screen W: Horizontal width of the screen When projecting in 1.90:1 (Native Full Display 17:9) format... - Page 45 Formula 1 (calculates an installation distance from a Formula 3 (calculates a distance from the installation projection image size) surface to the bottom of a projection image) Unit: cm (inches) Unit: cm (inches) Projection image size Projection image size L1 = 0.2219 × W - 36.9398 (L1 = 0.2219 × W - 14.5432) H = 0.1213 ×...
-
Page 46: Dimensions
Dimensions Front Unit: mm (inches) With side covers 215.1 218.5 Unit: mm (inches) With top cover and side covers 925 (36 901.6 (35 Bottom Unit: mm (inches) 420.5 (165 420.5 (165 20 ( 41.8 (16 41.8 (16 41.8 (16 410.5 (161 410.5 (161... - Page 47 Sony Corporation...
