- Page 1 JellyFish® filter Technical manual Issue 2 Filter...
-
Page 2: Table Of Contents
Treatment efficiency Inlet and outlet pipes System options Design information Configurations and design capacities Bypass design Shallow or low cover installations Submerged (tidal/tailwater) installations Series JellyFish® filter System installation Inspection and maintenance Replacement parts Humes Water Solutions Appendices Contact information... -
Page 3: Jellyfish® Filter
• Above-ground land use is maintained Designed as a polishing device for constrained sites, the The system is assembled within a fully-trafficable, JellyFish® filter is available in a range of sizes to cater for precast concrete structure for underground both at-source and end-of-pipe solutions. -
Page 4: System Components
• Filter cartridges are designated as either high-flow or draindown cartridges, depending on their location in the cartridge deck. High-flow cartridges placed within The JellyFish® filter is comprised of several structural and the backwash pool are automatically backwashed after functional components: each storm event. - Page 5 The separator skirt is attached to the underside of the The JellyFish® filter and components are depicted in cartridge deck. Figure 1 below. • As an option, the inlet pipe can be located below the deck for drainage networks with deep invert levels.
-
Page 6: Membrane Filtration Cartridge
In addition, the filtration membrane has been treated driving head. to allow biofilm to grow but not clog the pores of the membrane. The flow rating of a particular JellyFish® filter Extensive independent field testing, including testing cartridge is based on the membrane filtration surface... -
Page 7: System Operation
Gravitational forces remove coarse sediment (generally >50 microns), particulate-bound pollutants (nutrients, toxic metals, hydrocarbons), free oil and floatable As a tertiary treatment system, the JellyFish® filter trash and debris (that may bypass upstream primary is designed to be an “offline” structure, as part of a treatment devices). -
Page 8: Self-Cleaning Functions
Filter ripening accounts for under gravity both during inflow events and inter-event the ability of the JellyFish® filter to remove particles dry periods. As fine particles form into larger masses finer than the nominal pore size (20 microns) rating on the membrane surface, adhesion to the membrane of the membranes. -
Page 9: System Performance
System performance Inlet and outlet pipes An above-deck inlet pipe configuration is standard The JellyFish® filter has been designed to provide tertiary for the JellyFish® filter and an optional below-deck level treatment and should be combined with a Gross inlet configuration is available on request. Specific site... -
Page 10: System Options
System options The JellyFish® filter can be customised to suit your project requirements. As each treatment train is unique and units are designed to match surface levels, please contact Humes Water Solutions for assistance, however, Table 2 below can be used as a guide. -
Page 11: Design Information
JellyFish® filter outlet pipe. A minimum of 455 mm is required to drive the flow through the JellyFish® filter at the rates shown in Table 2. Recommended design flows of 5 L/s for high flow cartridges and 2.5 L/s for draindown cartridges are to... -
Page 12: Bypass Design
The pressure relief pipe height and diameter can be varied to accommodate the design peak flow rate and The JellyFish® filter should be designed with an offline system driving head requirements. For these systems, the configuration for most catchments. All stormwater filter... -
Page 13: Shallow Or Low Cover Installations
System installation The recommended minimum depth to outlet invert level The JellyFish® filter can be installed by a civil or plumbing is 1,040 mm. For sites that require less depth of cover, contractor in much the same way as a manhole or other the JellyFish®... -
Page 14: Humes Water Solutions
Industry Association. • 2008 Fieldforce Environmental Product of the Year Award from the Master Plumbers and Mechanical Services Association As a part of the Humes business, Humes Water Solutions of Australia. has access to a national infrastructure, a dedicated • 2006 CivEnEx - Most Innovative Product. -
Page 15: Appendices
Appendices JellyFish® filter standard drawings JellyFish® filter design/quotation request JellyFish® filter inspection and maintenance log JellyFish® filter... - Page 21 Pipe material: Outlet invert level: Latitude/longitude: Load class (circle one option): D / G Inlet configuration (circle one option): Above deck / below deck JellyFish® model required (circle model number) Desired JellyFish® filter outlet orientation 90° Offline system JF1000-1-1 JF1800-3-1 JF2400-6-2...
- Page 22 Holcim (Australia) Pty Ltd ABN 87 099 732 297 18 Little Cribb st Milton QLD 4064 Australia Phone (07) 3364 2800 (07) 3364 2835 JellyFish® filter inspection and maintenance log www.humes.com.au Owner: Location: GPS coordinates: JellyFish® filter model number: Land use: Commercial:...
-
Page 23: Contact Information
Contact information National sales 1300 361 601 humeswatersolutions.com.au info@humeswatersolutions.com.au Head Office New South Wales Tasmania 18 Little Cribb St Grafton Launceston Milton 4064 QLD Ph: (02) 6644 7666 Ph: (03) 6335 6300 Ph: (07) 3364 2800 Fax: (02) 6644 7313 Fax: (03) 6335 6330 Fax: (07) 3364 2963 Newcastle... - Page 24 We accept no responsibility for any loss or damage resulting from any person acting on this information. Humes is a registered business name of Holcim (Australia) Pty Ltd. The JellyFish filter is manufactured, marketed, and sold by Humes Water Solutions under licence from Imbrium Systems Inc, Canada.
