- Page 2 W3400V Four-port ADSL 2+ Wireless Router Quick Installation Guide VER: 1.1...
-
Page 3: Pc Network Configuration
1 Hardware Installation Step 1 See the following figure. Connect the Line port of the DSL Router with a telephone cable. Step 2 Connect the LAN port of the DSL Router to the network card of the PC via Ethernet cable. - Page 4 The following displays the TCP/IP Properties dialog box as it appears on Windows TCP/IP configuration instructions for Windows XP are as follows. Step 1 Choose Start > Control Panel > Network Connections from desktop. Step 2 Right-click the Ethernet connection icon and choose Properties.
-
Page 5: Logging In To The Router
2.2 Logging In to the Router When you log in to DSL Router for the first time, the login wizard appears. Step 1 Open a Web browser on your computer. Step 2 Enter http://192.168.1.1 (default IP address of the DSL router) in address bar. - Page 6 2.4 WAN Connection Configuration 2.4.1 Bridge Mode of Factory Default Configuration If the router is in the factory default mode, the following page appears when logging in to the DSL router as common user. In this condition, the router is in bridge mode, you can contact 100 for further assistance and support, or creat Internet connection as 4 section.
- Page 7 2.4.2 PPP Mode If the router is in the PPPoE or PPPoA mode, the following page appears when logging in to the DSL router as common user. In this page, you can configure Quick Setup. Choose Quick Setup, the following page appears. Enter Streamyx ID and Streamyx Password provided by your ISP.
- Page 8 After proper configurations, click Save/Reboot to take the configurations into effect. 3 Internet Connection 3.1 DSL Router Connection You can connect to the DSL router by Ethernet cable or WLAN. Use an Ethernet cable to connect an LAN port of your DSL router and network card of your computer.
