  • Page 1 GPS_DESIGNER Personal Navigator User manual and Reference guide HN-2000 Page 1/ 35 PDF created with pdfFactory Pro trial version www.pdffactory.com...
  • Page 2 Introduction Warnings WARNINGS Some certain knowledge is required to be well known by the user for proper and safe use of GPS_DESIGNER GPS handheld receiver. Please read this User’s Manual first before operation. This product can help the user to find out his way and orient him in travelling, BUT it can not totally replace the user’s own personal judgement.
  • Page 3 Introduction Welcome to GPS_DESIGNER Application Conditions: GPS_DESIGNER is designed for outdoors navigation in the temperature range of -20°C~ 70°C. So please use GPS_DESIGNER at an open place with a clear sky in the suitable environment since the surrounding environment will surely affect the satellite signals reception and device work efficiency.
  • Page 4 Reference GPS_DESIGNER Unit • Unit Features • Battery installation & Keypad • Start up the unit • Operation Structure • Main pages Internal GPS Antenna Waterproof LCD Display housing (with back-light) POWER keypad UP / DOWN / RIGHT / LEFT/ ENTER Battery keypads Compartment...
  • Page 5 Reference Battery Installation & Keypad Battery Installation 1. Turn battery cover screw counterclockwise until the battery cover can be removed. 2. Insert two new AA(or rechargeable) 1.5 V batteries as shown in the left picture, be sure to check the polarity, and replace the battery cover. 3.
  • Page 6 Reference Start up the unit To start up the GPS_DESIGNER, you should take the unit outside and find an open area where the built-in antenna has a clear view of the sky. Turning the GPS_DESIGNER on 1. Press POWER key until you hear a sound of “B” and the Welcome page appears. 2.
  • Page 7 Reference Operation Structure The GPS_DESIGNER operation is organized into four main pages: the Satellite Page, the Navigation page ,the Position Page , and the Map Page. Normally, every time you turn on the GPS_DESIGNER, you’d better switch into Satellite page and check satellites status first then start operation.
  • Page 8 Reference Main Pages The Satellite page Batteries display • This page informs you mainly on the satellites Orientation status distribution and satellite signal strength. Normally, the unit needs at least three satellites in connection for data Main menu Select status processing.
  • Page 9 Reference Main Pages The Navigation page This page makes very essential direction when you are under navigation. It orients you to your destination, tells you how far away you are from your destination, and your actual movement speed, and the route or track name you are using for navigation.
  • Page 10 Reference Main Pages DOWN AND ENTER The Position page This page shows the current location of the main information and time information. Then can use up/down button to select the district or the provision of data definition Gaussian parameters. Under the definition of data by Enter key areas, the system automatically selected latitude and longitude, according to Enter key pop-up pages can choose or plane coordinates of latitude, longitude coordinates.
  • Page 11 Reference Main Pages ENTER ENTER ENTER The Map page This page shows the map information. Use left / right can set the map scale, the use of the menu pages in the map information can be used up / down button to select Ramble, Show Data, Measure DIS.
  • Page 12 Reference Mark After the elections, Press Enter keys to enter the "Save WPT" screen by switching on a screen button to return. Each column for the anti-selected color, background color, Press Enter key to enter edit, edit success, bond set by the state to set aside editor, if editors want to jump out when the bond directly by switching from edit, edit Enter...
  • Page 13 Reference Waypoint List Editing a Waypoint: 1.Press ENTER key in Waypoint List page and see a sub-menu 2.Press UP/ DOWN keys to highlight Edit item 3.Press ENTER key again and enter Waypoint Edit page 4.Now follow the step4, 5 & 6 as described to build a Waypoint Deleting a Waypoint: 1.

  • Page 14: Editing Waypoints

    Reference Editing Waypoints Navigate a Waypoints: If you want to use a waypoint for navigation, you must make it active first. 1. Press ENTER key in Waypoint List page and see a sub-menu(as destination) 2. Highlight Active item by pressing UP/ DOWN keys 3.
  • Page 15 Reference Creating a Route Creating a route 1.Press UP / DOWN keys to highlight R_LIST item in MENU page and press ENTER key 2.Coming to Routes List page, Press ENTER key 3Press UP/ DOWN keys to highlight Create item and press ENTER key 4.
  • Page 16 Reference Creating a Route ENTER ENTER ENTER ESCAPE ESCAPE ENTER ENTER ENTER ENTER ENTER ENTER ENTER ENTER NOTE: When you are saving a route in route creation, if there is already a same named route existed in the memory, the unit will remind you to rename it. Page 16/ 35 PDF created with pdfFactory Pro trial version www.pdffactory.com...

  • Page 17: Editing A Route

    Reference Editing a Route Editing Route In the page of Route List, you can browse all the routes you saved in GPS_DESIGNER. If you want to change a route, you can edit it by changing waypoints design: 1. Press UP/ DOWN keys to highlight the route you will change in the page of Route List 2.
  • Page 18 Reference Editing a Route Once a route is activated, in the pop-up sub-menu, the five commands are used for route navigation. When you are using route navigation, you should switch to Tracking page to see your trace, and switch to Navigation page to find out your movement status, including LAT,LON, COG,SOG,ALT. In this way, you are enabled to find your way.
  • Page 19 Reference Recording a Track Recording a Track 1.Press UP/ DOWN key s in MENU page and highlight T-list item, press ENTER key and come into Track page 2.Press ENTER key and Track Edit window pops up 3.Press UP/ DOWN/ LEFT/ RIGHT keys to change letter and number to give the track a name 4.Press ENTER key to confirm your naming 5.Press ESCAPE key continuously till you return into the main page of Tracking NOTE: If you input a name which has already existed in track library, you will be informed by...
  • Page 20 Reference Editing a Track Return track 1. Press UP/ DOWN keys in Track page and highlight the track your want to use for navigation, press ENTER key and come out a sub-menu 2. Press UP/ DOWN keys to highlight Return item in the pop-up window 3.
  • Page 21 Reference Editing a Track ENTER ESCAPE ENTER ESCAPE ENTER ESCAPE ENTER ESCAPE ENTER Page 21/ 35 PDF created with pdfFactory Pro trial version www.pdffactory.com...
  • Page 22 Reference Proxinmity WPT The warning is installed in the course of navigation, flight arrival flights automatically suggested that the police role, the most installed 10 alarm may flights. Specific operations, detailed look at the following steps: 1. Immigration destinations need to add the routes to warn column item 2.
  • Page 23 Reference Setup Setup Highlight Setup item by UP/DOWN key and press ENTER key from Menu page, the Setup page appears. You can set 7 items for the system: Datum, Display, Time, Alarm, Unit and Other. There are four items you can set:mode,record Manner,Battery Type,Restore. Datum Refers to the theoretical mathematical model of the earth’s sea surface.
  • Page 24 Reference Setup NOTE: Whenever you start to use Anchor alarm, the unit will always default your current location as the Anchor. The prompt alarm will last until you go out of the alarm area or switch off the alarm. If you set Anchor alarm, it will always be effective no matter it is in the state of navigation or not, expect the alarm is turned off.
  • Page 25 Reference Measure ENTER ENTER ENTER ESCAPE ESCAPE ESCAPE ENTER ENTER ESCAPE ESCAPE ENTER ESCAPE ESCAPE ESCAPE ENTER ENTER ENTER Tools options use up/down key selected by determining bond pop Measure DIS and Measure Area of the two options, Press Enter keys to be able to enter for further operation.
  • Page 26 Reference Find ENTER ENTER ESCAPE ESCAPE UP/DOWN ESCAPE ESCAPE ENTER ENTER Find options, we can conduct Waypoint, Routes, Track the search. If handhelds in the preservation of the relevant data, then you can search through the complete operation if not preserved relevant data, it will give a warning to show there is no relevant data.
  • Page 27 Reference Hunt & Fish In the Hunt & Fish options, you can view the best Hunt & Fish with a better time slot. Press up / down key to choose measurement and measurement time. According to determine bond, the use of up / down / left / right to amend measurement time and measurement, after proper revision, the bond can be Enter by the return of canceled by the choice of switching bond jumped out.
  • Page 28 Reference Sun & Moon The Sun and provided some options in a certain place on a certain day of sunrise, sunset, moonrise, moonset, down on the time you travel convenience. The specific steps are as follows: Press up / down button to choose measurement and measurement time. 1.
  • Page 29 Reference Tools ENTER ENTER ESCAPE ESCAPE DOWN ENTER ESCAPE ENTER ESCAPE ENTER The tool options, you can use calculator and stopwatch. Page 29/ 35 PDF created with pdfFactory Pro trial version www.pdffactory.com...
  • Page 30 Reference Communication Communication page Highlight COMMU item by UP/DOWN key and press ENTER key from Menu page, the Setup page appears. It contains three items:Computer , Master ,Receive. It activates GPS_DESIGNER ‘s communication capability with a computer or a long-range equipment (for example , modem). Computer: With this function , GPS_DESIGNER can establish communication with a computer.
  • Page 31 Appendices Altitude: Distance above mean sea level. BRG: The compass direction from current position to next waypoint or the destination. COG: Course over ground. Your direction of movement relative to a ground position. Coordinate: A set of numbers that describes your location on or above the earth.
  • Page 32 Appendices Route: A route consists of start point, end point and in-between waypoints. A single route is a kind of simple route only having start point and end point, in another word it is a “Goto” route. Route can also be made up of several legs from one waypoint reaching up to 20 other different waypoints.
  • Page 33 Appendices 1. The screen is blank after you press the POWER keypad. • Wrong batteries installation or no enough power. Check to insure that the batteries are installed correctly and that the battery terminals are clean. Or replace the batteries. •...
  • Page 34 Appendices • Navigation Features Waypoints: Total: 1000 with name and symbol Routes: 30 Reversible routes Tracks: 10 tracks with name and symbol · Performance Receiver: Twelve parallel channel receiver continuously tracks and uses up to twelve Satellites Frequency: L1,1575.42MHz,C/A code Sensitivity: -140 dbm Acquisition Times:...
  • Page 35 Appendices & & Symbols In the GPS_DESIGNER, you can use 28 symbols to name your waypoints ( see them in the right part of the page). telephone kiosk Prompts incursion- borderline • Maximum 30 routes can be saved! crossroad house The GPS_DESIGNER can memorize maximum 30 routes, 10 fish pond rockfall...
  • Page 36 Appendices Adindan-Mean Adindan-Regional Mean Ala,Can,Conus North American 1983-Alaska,Canada,Conus Alaska North American 1927-Alaska Aleutian IsdE North American 1927-Alaska(Aleutian Islands E) Aleutian IsdW North American 1927-Alaska(Aleutian Islands W) Aleutian Isds North American 1983-Aleutian Islands Antarctica Camp Area Astro-Antarctica Arc-Mean Arc 1950-Regional Mean Argentina South American 1969-Argentina Argentina...
  • Page 37 Appendices Czechoslova42 S-42(Pulkovo 1942)-Czechoslovakia Czechoslova93 S-JTSK-Czechoslovakia(prior to Jan 1993) E.Canada North American 1927-East Canada E.Mississippi North American 1927-East of Mississippi Egypt 07 Old Egyptian 1907-Egypt Egypt 50 European 1950-Egypt England Ord. Survey G. Britain 1936-England Eur.C.Reg.M European 1979-Central Regional Mean Eur.E Reg.M European 1950-Eastern Regional Mean Eur.N.Reg.M...
  • Page 38 Appendices Japan Tokyo-Japan Kauai Old Hawaiin-Kauai Kazakhstan S-42(Pulkovo 1942)-Kazakhstan Latvia S-42(Pulkovo 1942)-Latvia Maderia Isds Porto Santo 1936-Maderia Islands Malta European 1950-Malta Marshall Wake-Eniwetok 1960-Marshall Islands Maui Old Hawaiin-Maui Mexico Gulf North American 1927-Gulf of Mexico Mexico North American 1927-Mexico Midway Isds Midway Astro 1961-Midway Islands Mindanao Luzon-Philippines(Mindanao)
  • Page 39 Appendices Russia Pulkovo 1942-Russia S.Africa Cap-South Africa S.America M56 Provisional S.American 1956-Regional Mean S.America M69 South American 1969-Regional Mean S.Chile Provisional S.American 1956-Chile(Southern) S.Georgia Isd ISTS 061 Astro 1968-South Georgia Islands S.Greenland Qornoq-Greenland(South) S.Korea K Korean Geodetic System-South Korea Salvage Isds Sevagem Grande-Salvage Islands Sardinia 40 Rome 1940-Italy(Sardinia)
