Wireless ADSL 2 + ROUTER
WA41R
User's Manual
March 2010

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the wa41r and is the answer not in the manual?

Questions and answers

Related Manuals for PRO-NETS wa41r

Summary of Contents for PRO-NETS wa41r

  • Page 1 Wireless ADSL 2 + ROUTER WA41R User’s Manual March 2010...
  • Page 2 FCC Warning This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 3 0984 E=10.49221 V/m is the maximum E-Field strength when safety distance between the EUT and human body is maintained at least 20cm, which is below 61V/m as required in Annex III table 2 of EC Council Recommendation (1999/519/EC). This proves that the unit complies with the EN 62311 for RF exposure requirement.

  • Page 4: Table Of Contents

    All brand and product names mentioned in this manual are trademarks and/or registered trademarks of their respective holders. Contents 1. Introduction ................4 1.1 Introduction to Wireless LAN ADSL2+ router ......4 1.2 Product Features ..............4 2. Hardware Installation ............7 2.1 System Requirements ..............
  • Page 5 4.4.5 WPS ................35 4.4.6 MBSSID ............... 35 4.5 WAN ..................36 4.5.1 Channel Configuration ..........36 4.5.2 ATM Settings ............... 37 4.5.3 ADSL Settings .............. 39 4.6 Service.................. 40 4.6.1 DHCP ................40 4.6.2 DNS ................42 4.6.3 Firewall ............... 44 4.6.3.1 IP/Port Filtering ..........

  • Page 6: Introduction

    This gateway are with full-featured ADSL router that provides high-speed Internet access, 1-port Ethernet switch direct connections to individual PCs or local area network with 10/100 Base-T Ethernet and a 150Mbps IEEE802.11n wireless connectivity. WA41R uses advanced ADSL chipset solution with complete set of industry standard features for high-speed Internet access.
  • Page 7 ITU-T G.992.4 (ADSL2 G.lite.bis) ITU-T G.992.5 (ADSL2+; Annex A, B, L & M) Reach Extended ADSL (RE ADSL) Multi-connection protocol support Support up to 8 PVCs ATM forum uni 3.1/4.0 PVC Multi Protocol over AAL5 (RFC1483 / 2684) VC and LLC Multiplexing PPP over Ethernet (RFC 2516) PPP over ATM (RFC 2364) Traffic shaping (ATM QoS) UBR, CBR, VBR, VBR-rt, VBR-nrt...
  • Page 8 Supports Quality of Service (QoS), 802.11e, WMM MAC Address Filtering Security PPP over PAP (Password Authentication Protocol; RFC1334) PPP over CHAP (Challenge Authentication Protocol; RFC1994) DOS Protection Stateful Packet Inspection (SPI) Built-in NAT Firewall IP-based Packet filtering Password Protected System Management Web-Based Management Web-Based GUI configuration / Management CLI (Command Line Interface) via serial interface or Telnet over Ethernet...

  • Page 9: Hardware Installation

    register for this service with a Dynamic DNS client. DHCP Support DHCP (Dynamic Host Configuration Protocol) allows individual clients to obtain TCP/IP configuration at start-up from a centralized DHCP server. The ADSL router has built-in DHCP server capability enabled by default. It can assign IP addresses, an IP default gateway and DNS servers to DHCP clients.

  • Page 10: Back Panel

    Descriptions of LED status ON/OFF Click On/Off button to enable Wireless ADSL Router. Button Blinking: The WPS function is establishing. Slow Blinking: WLAN is successfully connected. WLAN Blinking: The data is being sent or received. Light up: LAN connection with end user is established. Blinking: Router is transferring data between the router and end user.
  • Page 11 Connect with USB cable to PC. Connect with power adapter...

  • Page 12: Connect Related Devices

    2.5 Connect Related Devices 1) Connect Router to LINE Plug the provided RJ-11 phone cable into LINE port on the back panel of the router and insert the other end into splitter or wall phone jack. 2) Connect Router to LAN Plug RJ-45 Ethernet Cable into LAN port on the back panel of the router and insert the other end of the Ethernet cable on your PC’s Ethernet port or switch / hub.

  • Page 13: Connecting Wireless Lan Adsl2+ Router Via Ethernet

    3. Connecting Wireless LAN ADSL2+ Router via Ethernet You can connect Wireless LAN ADSL2+ router with PC through either Ethernet cable. You can change the settings via WEB browser. 3.1 Setup ADSL2+ router via Ethernet Cable If there is an available LAN card present on your PC, you just simply connect ADSL router and PC through the Ethernet cable.
  • Page 14 Right click Local Area Connection (your local network hooked up with ADSL Step 2: router) and select Properties: Select Internet Protocol (TCP/IP) then click Properties: Step 3:...
  • Page 15 Configure IP Automatically: Select Obtain an IP address automatically and Obtain DNS server address Step 4: automatically then click OK to complete IP configuring process. Configure IP Manually:...
  • Page 16 Select Use the following IP address and Use the following DNS server Step 4: addresses. IP address: Fill in IP address 192.168.1.x (x is a number between 2 to 254). Subnet mask: Default value is 255.255.255.0. Default gateway: Default value is 192.168.1.1. Preferred DNS server: Fill in preferred DNS server IP address.
  • Page 17 Right-click Local Area Connection (local network your ADSL hooked up with) Step 3: and select Properties: Select Internet Protocol (TCP/IP) then click Properties: Step 4:...
  • Page 18 Configure IP address Automatically: Select Obtain an IP address automatically and Obtain DNS server address Step 5: automatically. Click OK to finish the configuration. Configure IP Address Manually:...

  • Page 19: Ping

    Select Use the following IP address and Use the following DNS server Step 5: addresses. IP address: Fill in IP address 192.168.1.x (x is a number between 2 to 254). Subnet mask: Default value is 255.255.255.0. Default gateway: Default value is 192.168.1.1. Preferred DNS server: Fill in preferred DNS server IP address.
  • Page 20 If the communication link between your computer and router is not setup correctly, after you type ping 192.168.1.1 under DOS prompt following messages will appear: Pinging 192.168.1.1 with 32 bytes of data: Request timed out. Request timed out. Request timed out. This failure might be caused by cable issue or something wrong in configuration procedure.

  • Page 21: Adsl

    Select “Manage Network connections”. Step 3: Right-click Local Area Connection (local network your ADSL hooked up with) Step 4: and select Properties:...
