Page 1: Servicing Instructions
Installation, operating and servicing instructions E-Tech 09 - 15 Single phase / Tri phase E-Tech 22 - 28 - 36 Tri phase EN • 1 664Y3400... -
Page 2: Table Of Contents
Electric connection / Models : 22 - 28 - 36 Sizing of supply wires Wiring diagrams / Models : 09 - 15 - 22 Wiring diagrams / Models : 28 - 36 Power wiring / Models : 09 - 15... -
Page 3: Warnings
WARNINGS WHO SHOULD READ THESE INSTRUCTIONS IMPORTANTS NOTES These instructions should be read by: These instructions are an integral part of the equipment to which - the specifying engineer they relate and must be handed to the user. - the installer - the user The product must be installed and serviced by qualified engineers - the service engineer... -
Page 4: Introduction
This wall hung electric boiler is available in 5 models: The boilers have been manufactured to comply with the following • Models 09 and 15 are supplied with 400 Volt triphase + N, standards BS EN60335-2-35: 1998, BS EN55014-2:1997 and convertible to 230 V single phase. - Page 5 INTRODUCTION Top cover Automatic air vent Brass pocket Heating elements Minimum thermostat (only with direct DHW kit) Heating body Hand side panel Cable gland Control panel Pressure safety valve Expansion vessel Rear panel Valve of expansion vessel Water pressure switch Expansion vessel connection Direct ESC kit connection (in option)
-
Page 6: Instructions
INSTRUCTIONS USER DATA • As with most boilers and heating appliances the casing and pipework can get hot during normal running so the boiler must not be All user controls are situated on the front panel of the boiler, there covered and the surrounding area must be kept clear. -
Page 7: Technical Characteristics
TECHNICAL CHARACTERISTICS Model 4.2 to 7.2 to 14.4 to 21.6 to 30 to Power 8.4 kW 14.4 kW 21.6 kW 28.8 kW 36 kW 1 x 230 V 1 x 230 V Nominal supply voltage 3 x 400 V + N 3 x 400 V + N 3 x 400 V + N 3 x 400 V + N... -
Page 8: Technical Characteristics
TECHNICAL CHARACTERISTICS Electrical data of model 09 STAGE 1 STAGE 2 TOTAL POWER TERMINALS Tri phase 8.4 kW (*) Terminals 1 and 2 shunted Terminal 3 L1 (A) Terminals 5 and 6 shunted Terminal 4 L2 (A) Relay K4 activated... -
Page 9: Electrical Data Of Model 15
TECHNICAL CHARACTERISTICS Electrical data of model 15 STAGE 1 STAGE 2 TOTAL POWER TERMINALS Tri phase 14.4 kW (*) Terminals 1 and 2 shunted Terminal 3 L1 (A) 10.4 10.4 20.8 Terminals 5 and 6 shunted Terminal 4 L2 (A) 20.8 20.8 Relay K4 activated... -
Page 10: Electrical Data Of Model 22
TECHNICAL CHARACTERISTICS Electrical data of model 22 STAGE 1 STAGE 2 TOTAL POWER TERMINALS Tri phase 21.6 kW (*) Terminals 3 and 4 shunted Terminal 2 L1 (A) 20.8 10.4 31.2 Terminals 5 and 6 shunted Terminal 3 L2 (A) 20.8 10.4 31.2... -
Page 11: Electrical Data Of Model 28
TECHNICAL CHARACTERISTICS Electrical data of model 28 STAGE 1 STAGE 2 TOTAL POWER TERMINALS Tri phase 28.8 kW (*) Terminals 3 and 4 shunted Terminal 2 L1 (A) 20.8 20.8 41.6 Terminals 5 and 6 shunted Terminal 3 L2 (A) 20.8 20.8 41.6... -
Page 12: Electrical Data Of Model 36
TECHNICAL CHARACTERISTICS Electrical data of model 36 STAGE 1 STAGE 2 TOTAL POWER TERMINALS Tri phase 36 kW (*) Terminals 3 and 4 shunted Terminal 2 L1 (A) Terminals 5 and 6 shunted Terminal 3 L2 (A) Relay K5 activated Terminal 5 L3 (A) Terminal 1... -
Page 13: Mounting
MOUNTING 332 mm 442 mm DIMENSIONS 185 mm 105 mm 370 mm WALL MOUNTING INSTALLATION ROOM The appliance must be positioned in such a way as to be easily accessible at all times. In addition, the following minimum distances around the appliance must be complied with. -
Page 14: Installation
INSTALLATION DISASSEMBLING Panel removal and access to hydraulic connections 1. Undo screws. 2. Tilt panel towards you and lift clear remove the top cover. 3. Loosen screws of the control panel. 4. Turn up the control panel. 5. Block the control panel with the screw. EN •... -
Page 15: Heating Connection
INSTALLATION HEATING CONNECTION Limiting the maximum adjustable temperature Factory setting Floor heating 30 - 85°C 30 - 50°C HEATING CONNECTION + DHW (Circulating pump + 3-way valve) Limiting the maximum adjustable temperature With DHW kit 60 - 85°C The 3 ways valve is normally open towards the tank circuit HEATING CONNECTION + DHW (2 Circulatings pumps) - Page 16 INSTALLATION HEATING CONNECTION + DHW : “Y” PLAN Limiting the maximum adjustable temperature 60 - 85°C HEATING CONNECTION + DHW : “S” PLAN Limiting the maximum adjustable temperature 60 - 85°C EN • 16 664Y3400...
-
Page 17: Electric Connection / Models : 09 - 15
INSTALLATION ELECTRIC CONNECTION / MODELS : 09 - 15 • This appliance must be permanently connected to fixed wiring and must be earthed. • The wiring must be carried out by a competent person and in accordance with the current IEE Wiring Regulations. -
Page 18: Electric Connection / Models : 22 - 28 - 36
INSTALLATION ELECTRIC CONNECTION / MODELS : 22 - 28 - 36 • This appliance must be permanently connected to fixed wiring and must be earthed. • The wiring must be carried out by a competent person and in accordance with the current IEE Wiring Regulations. •... - Page 19 INSTALLATION EN • 19 664Y3400...
- Page 20 INSTALLATION EN • 20 664Y3400...
- Page 21 INSTALLATION 21 22 21 22 21 22 21 22 21 22 21 22 21 22 21 22 EN • 21 664Y3400...
- Page 22 INSTALLATION 21 22 21 22 21 22 21 22 21 22 21 22 21 22 21 22 EN • 22 664Y3400...
- Page 23 INSTALLATION 23 24 23 24 23 24 23 24 23 24 23 24 23 24 23 24 EN • 23 664Y3400...
-
Page 24: Honeywell Sundial Wiring Diagrams
HONEYWELL SUNDIAL WIRING DIAGRAMS MOTOR MOTOR Honeywell Sundial Wiring Centre V4043H V4043H `S ` Plan HTG ZONE VALVE DHW ZONE VALVE T6306B ROOM STAT CYLINDER STAT Note: Earth wires not shown for clarity During installation the earth wires from each component connect to terminal 3 in the wiring centre CABLE COLOUR CODES bk- black... -
Page 25: Honeywell Sundial Wiring Centre 'Y' Plan
HONEYWELL SUNDIAL WIRING DIAGRAMS V4073A MID POSITION ZONE VALVE Honeywell Sundial Wiring Centre `Y ` Plan T6306B ROOM STAT CYLINDER STAT Note: Earth wires not shown for clarity During installation the earth wires from each component connect to terminal 3 in the wiring centre CABLE COLOUR CODES bk- black br- brown... -
Page 26: Commissioning And Maintenance
COMMISSIONING AND MAINTENANCE COMMISSIONING - WATER STARTING THE BOILER 1. The system must be thoroughly cleansed prior to connection 1. Switch on the internal or external timeclock (if fitted) of the boiler. The system water should be treated to prevent 2. -
Page 27: Removal The Heating Elements
REMOVAL THE HEATING ELEMENTS EN • 27 664Y3400... - Page 28 EN • 28 664Y3400...
- Page 29 664Y3400...
- Page 30 EN: Base for relay ES: Basa para relé 54428195 FR: Base pour relais IT: Base per relè NL: Relaisvoet DE: Relais-Sockel EN: Control circuit “Siemens” ES: Disyuntor “Siemens” 54766015 FR: Disjoncteur “Siemens” IT: Interruttore ON/OFF “Siemens” NL: ON/OFF-schakelaar “Siemens” DE: Siemens- Schutzschalter EN: Relay “Siemens”...
- Page 31 664Y3400...
- Page 32 EN: Control terminal block ES: Repleta de 28 bornes 54767015 FR: Bornier 28 pôles complet IT: Morsettiera 28 poli completa NL: Klemmenblok 28-polig, compleet DE: Klemmenleiste, 28-polig, komplett EN: Green switch ES: Interruptor verde 54766016 FR: Interrupteur vert IT: Interruttore verde NL: Schakelaar groen DE: Schalter grün EN: Yellow switch...
- Page 33 664Y3400...
- Page 34 EN: Heating element 2 x 1,4 kW ES: Elemento calefactor 2 x 1,4 kW 54428183 FR: Elément chauffant 2 x 1,4 kW IT: Resistenza elettrica 2 x 1,4 kW NL: Verwarmingselement 2 x 1,4 kW DE: Heizelement 2 x 1,4 kW EN: Heating element 2 x 2,4 kW ES: Elemento calefactor 2 x 2,4 kW 54428182...
- Page 35 24614143 24614144 24614145 664Y3400...
- Page 36 N° Side panel Latérale Zijkanten Lateral Pannello laterale Seitenteil Front panel Face avant Frontstuk Parte delantera Mantello anteriore Vorderteil Top cover Couvercle supérieur Bovenkap Tapa superior Mantello superiore Obere Abdeckung Rear panel Panneau arrière Achterpaneel Panel posterior Pannello posteriore Hintere Blende Control panel Tableau Paneel...
