- Page 1 SL2380 Owner’sKit Installer’s guide Blind control device Battery module www.pellini.net...
- Page 2 The solar panel SL1084B160 (option) is used to recharge the battery module SL2380 on a continuous basis. Wiring and installation must be fitted by skilled staff only. Pellini SpA accepts no liability for damage caused by improper installation. INSTALLATION ON THE WINDOW FRAME See p.
- Page 3 ...
- Page 4 ...
- Page 5 7 mm MOTOR CONNECTION THROUGH INSULATED CRIMP WIRE CONNECTORS 0.325 mm² It is possible to use other types of connection (e.g. screw block 0.325 mm² terminals, insulated crimps, insulated heat shrinkable wire con- nectors, etc), provided that they ensure a stable contact and wire insulation.
-
Page 6: Recharging The Batteries
Switching on The battery module is fitted with a plastic strip that isolates the batteries in the OFF posi- tion. To switch the battery module ON, remove the plastic strip. Correct function is indicated by the LED, which lights up for about 3 seconds. - Page 7 When the power adaptor is connected, the LED will indicate the following conditions: • LED flashing: batteries missing, defective or not of a compatible type. Immediately unplug the adapter • LED pulsating: charging underway • LED steadily lit: charging completed After charging, detach the cable and fit the module back onto its base plate.
- Page 8 Deleting a channel 1. Detach the battery module from the support 2. Call up the channel to be deleted on the remote control display by pressing the +/- buttons 3. Keep the button on the battery module pressed until the LED starts flashing quickly after lighting up 4.
- Page 9 paragraph below) the LED will light up briefly, go off and then light up again for 3 seconds. Logic inVeRSion The battery module incorporates a digital accelerometer which automatically detects the position of the module on the frame and adapts the functions of the touch-sensitive area. The normal operating mode requires the battery module to be mounted on the frame / glass on the same side as the motor, with the rounded parte toward the outside of the frame.
-
Page 10: Maintenance
Maintenance The product requires no maintenance, except for replacement of the rechargeable batteries as necessary. Any repairs must be made by a technician authorized by Pellini SpA. In the event of prolonged inaction, remove the batteries. cLeaning Clean the product using a clean, dry, soft cloth that does not le- ave any residues. -
Page 11: Disposal Of Batteries
4. Insert the new batteries, paying attention to the direction of insertion indicated on the bottom of the battery com- partment. To avoid the risk of damaging the module, do not touch the exposed electronic parts. 5. Before inserting the last battery, be careful not to rest your hand or any other object on the sensitive area since as soon as all the batteries have been inserted the mo- dule will become ‘live’... -
Page 12: Safety Information
PRoPeR USe The battery module is supplied for the purpose of operating Pellini “F Touch” blinds with an internal motor (or external motor on other systems). Any use for other than the intended purpose is to be considered improper use. - Page 13 SE THEM TO EXPLODE! If any liquids penetrate into the device or in the event of damage of any other kind, immediately take out the batteries and return the device to the manufacturer for inspection. In the event of prolonged inaction of the device, remove the batteries technical data Battery module SL2380...
-
Page 14: Drilling Templates
DRILLING TEMPLATES Round hole 18.5 Ø2 Ø8... - Page 15 Milled hole 20.5 Ø2...
- Page 16 ® Pellini S.p.A. Via Fusari, 19 26845 Codogno • Lo • Italia T. +39 0377 466411 F . +39 0377 436001 info@pellini.net - www.pellini.net...
