HE10.1 Assembly Instructions
HE10.1 Mark II Instructions
1.
INTRODUCTION................................................................................................................................................ 2
2.
PARTS ..................................................................................................................................................................... 2
3.
NEEDED TOOLS................................................................................................................................................. 2
4.
CROSSOVER SCHEMATICS ......................................................................................................................... 3
4.1.
TWEETER CROSSOVER............................................................................................................................3
4.2.
WOOFER CROSSOVER..............................................................................................................................3
5.
CROSSOVER ASSEMBLY............................................................................................................................... 4
5.1.
5.2.
5.3.
5.4.
5.5.
5.6.
5.7.
5.8.
TEST, TEST, TEST........................................................................................................................................6
5.9.
5.10.
5.11.
5.12.
!..........................................................................................................................................................6
6.
SYSTEM TROUBLESHOOTING.................................................................................................................. 7
7.
CABINET PLANS................................................................................................................................................ 8
7.1.
.........................................................................................................................................................8
7.1.1.
Panel cuts............................................................................................................................................... 8
7.1.2.
Hole/baffle cuts ..................................................................................................................................... 8
7.2.
........................................................................................................................................................9
HE10.1 Assembly Instructions
Copyright © 2001-2004 Adire Audio®. All Rights Reserved. This design is for private, non-retail/non-
commercial use only. Any use of this design for profit, in any way shape or form, without the express
written consent of Adire Audio is strictly prohibited.
Adire Audio
2006 196
th
Suite 102
Lynnwood, WA 98036
425 778 9663
techsupport@Adireaudio.com
http://www.adireaudio.com

TABLE OF CONTENTS

......................................................................................................4
.......................................................................................................................5
........................................................................................................................................5
......................................................................................................................................5
..........................................................................................................................................5
......................................................................................................................5
...........................................................................................................................6
....................................................................................................................................6
...........................................................................................................................................6
.........................................................................................................................6
Street SW
1
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HE10.1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Adire Audio HE10.1

  • Page 1: Table Of Contents

    RAWINGS HE10.1 Assembly Instructions Copyright © 2001-2004 Adire Audio®. All Rights Reserved. This design is for private, non-retail/non- commercial use only. Any use of this design for profit, in any way shape or form, without the express written consent of Adire Audio is strictly prohibited.

  • Page 2: Introduction

    HE10.1 Assembly Instructions 1. Introduction Welcome to Adire Audio’s HE10.1 Mark II loudspeaker system. The HE10.1 Mark II is a high- performance high efficiency coaxial driver system, designed for use where high efficiency is required, such as PA monitors and use with low-power amplifiers (specifically SET amplifiers). It features a 10” paper cone driver with a coaxially mounted compression driver loaded into a 90°...

  • Page 3: Crossover Schematics

    R2021 (20 Ohms) – all other resistors are series resistance. HE10.1 Assembly Instructions Copyright © 2001-2004 Adire Audio®. All Rights Reserved. This design is for private, non-retail/non- commercial use only. Any use of this design for profit, in any way shape or form, without the express...

  • Page 4: Crossover Assembly

    “Intro to Electronics” books at Radio Shack, or other electronics/hobbyist stores. HE10.1 Assembly Instructions Copyright © 2001-2004 Adire Audio®. All Rights Reserved. This design is for private, non-retail/non- commercial use only. Any use of this design for profit, in any way shape or form, without the express...

  • Page 5: Strip Inductor Insulation

    HE10.1 Assembly Instructions Copyright © 2001-2004 Adire Audio®. All Rights Reserved. This design is for private, non-retail/non- commercial use only. Any use of this design for profit, in any way shape or form, without the express written consent of Adire Audio is strictly prohibited.

  • Page 6: Build Connection Wires

    We trust this step is self-explanatory… J HE10.1 Assembly Instructions Copyright © 2001-2004 Adire Audio®. All Rights Reserved. This design is for private, non-retail/non- commercial use only. Any use of this design for profit, in any way shape or form, without the express...

  • Page 7: System Troubleshooting

    HE10.1 Assembly Instructions Copyright © 2001-2004 Adire Audio®. All Rights Reserved. This design is for private, non-retail/non- commercial use only. Any use of this design for profit, in any way shape or form, without the express written consent of Adire Audio is strictly prohibited.

  • Page 8: Cabinet Plans

    7. Cabinet Plans The vented Cabinet HE10.1 is a net 29 liters, stuffed with 12 ounces of polyfill. It is tuned to 60 Hz with a 4” OD by 4.5”L vent. This alignment is designed to provide bass extension to 65 Hz anechoic and will yield typical in-room extension into the 50 Hz range.

  • Page 9: Drawings

    9.25 in HE10.1 Assembly Instructions Copyright © 2001-2004 Adire Audio®. All Rights Reserved. This design is for private, non-retail/non- commercial use only. Any use of this design for profit, in any way shape or form, without the express written consent of Adire Audio is strictly prohibited.
