UH400A/UH400TM

Compatibility Mode Indicators

At power up, all three LEDS will blink together red, then
green, followed by the -20 and -10 dB LEVEL LEDs
blinking together to indicate the operating mode.
The –20 and –10 LEDs will blink:
• Once for 100 Series mode
• Twice for 200 Series mode
• Three times for mode 3
(Contact Factory for Details)
• Four times for 400 Series mode
(Native Hybrid mode)
• Five times for IFB Series mode
• Six times for mode 6
(Contact Factory for Details)
-20 dB LEVEL
-10 dB LEVEL
 LECTROSONICS, INC.
