OmniTurn GT-75 User Manual

Hide thumbs Also See for GT-75:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operator's Maintenance Manual

Safety Warnings

Read and heed all "DANGER " and "CAUTION" labels on the machine.
MOVING PARTS CAN CAUSE INJURIES! Keep hands and clothing
clear of spindle and tooling plate at all times.
!
DO NOT OPERATE WITH DOOR or SPLASH SHIELD OPEN!
DO NOT OPEN DOOR DURING OPERATION!
DO NOT operate machine without guards, doors and covers in place.
DO NOT operated while under the influence of alcohol or drugs,
including prescription drugs.
DO NOT wear loose clothing while operating machine.
DO NOT wear jewelry (necklaces, bracelets, watches, rings) while
operating machine.
Keep long hair tied up and out of the way.
Wear eye and face protection.
Report any malfunction to your supervisor.
1.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GT-75 and is the answer not in the manual?

Questions and answers

Related Manuals for OmniTurn GT-75

Summary of Contents for OmniTurn GT-75

  • Page 1: Safety Warnings

    Safety Warnings Read and heed all “DANGER “ and “CAUTION” labels on the machine. MOVING PARTS CAN CAUSE INJURIES! Keep hands and clothing clear of spindle and tooling plate at all times. DO NOT OPERATE WITH DOOR or SPLASH SHIELD OPEN! DO NOT OPEN DOOR DURING OPERATION! DO NOT operate machine without guards, doors and covers in place.

  • Page 2: Coolant Pump

    Cycle Start. If door is opened while program is running, all motion will stop and Main OmniTurn Menu will appear. Secure door, select Jog Mode then send slide Home (H,Z,X) before re-starting program. If door is opened during threading cycle, all motion will stop as above, but...

  • Page 3: Spindle Motor

    Palm Box E-Stop. If these are opened before pressing Cycle Start, program will Filter not start: Main OmniTurn Menu will appear. Secure hatch or splash guard, select Automatic Mode then press Cycle Start. If guard or hatch is opened while program is running, all motion will stop and Main OmniTurn Menu will appear.
  • Page 4 OmniTurn Front Panel: Knobs & Switches Omni Turn CONTROL SERVOS EMERGENCY STOP SPINDLE OVERRIDE AUTO CYCLE MOTION SPINDLE START STOP Caps Scroll Lock Lock Lock PrtSc Scroll Pause Lock SysRq Lock Break Spindle & Backspace 100% Home PgUp Caps "...
  • Page 5 OmniTurn Front Panel: Keyboard Omni Turn CONTROL SERVOS EMERGENCY STOP SPINDLE OVERRIDE AUTO CYCLE MOTION SPINDLE START STOP Caps Scroll Lock Lock Lock PrtSc Scroll Pause Lock SysRq Lock Break & Spindle Backspace 100% Home PgUp Caps " Parts Enter...
  • Page 6 OmniTurn Rear Panel Serial Number Label Servo overloads. Press to reset. RS-232 Port For transfering files. Also used with C-Axis option. OMNITURN CNC Attachments CNC Control Main Fuse X Axis Z Axis Servo Error due to Overload If the breaker has not tripped, the servo-amp may have.
  • Page 7 Start - Up: Apply Power After the OmniTum has been installed and all of the cables are connected set 220vac disconnect ON. The 220vac disconnect is located on the Spindle Drive Cabinet at left-hand side of the GT-75 or GT-Jr, as illustrated below.
  • Page 8 Ctrl Fn Ins Del OmniTurn front panel Keyboard Press the blue “Servos On” pushbutton. It should illuminate and you should hear a slight hum as the axes motors engage. This part of the screen is the prompt area, and different information will be presented here according to the current mode or page.
  • Page 9 Spindle Ctrl Fn Ins Del OmniTurn front panel Keyboard Establish “Home” After the servos are turned on, the control automatically goes to the JOG mode. This is done so that machine “HOME” can be established. The control will not allow you to leave the JOG mode until the homing procedure has been completed.
  • Page 10 Establish Home: Detail Press “2” (Medium Jog) or “3” (Fast Jog) on the Keyboard, and use the Jog Stick to move slide to within 0.200” from Zero in X and Z as illustrated below. The X axis should be on the plus side of zero, and the Z axis should be on the minus side.
  • Page 11 Establish Home: Screens POSITION FEED 10.0 IPM : X +0.15095 Z -0.15860 COMMAND PERCENT FEED: 100 : X-40 MAKE JOG SELECTION Manual Data Input Automatic Single Block 1. Slow 7. .1000 2. Medium 8. 1.0000 3. Fast 9. Est Home 4.
  • Page 12 The outside line is used to find a definite location. The encoder will ”see” this line once every revolution of the ball screw used to position the slide. The ball screw used on the OmniTurn moves the slide .2” / revolution. So if we position the slide within .2” of what we want to call HOME and then tell the control to slowly rotate the screw while looking for the single pulse we can establish this as an easily repeat- able location.
  • Page 13 The method for moving the slide is to use the ”Joy stick” actuator on the operators panel. Deflecting this actuator in the four directions available produces the following motions: X axis minus (away from you on attachment; up on GT-75 & Jr) Down X axis plus (toward you on attachment;...
  • Page 14 Ctrl Ins Del OmniTurn front panel Keyboard The speed or increment of the jog mode can be selected. This is done by pressing a number between 1 -8 on the keyboard. The jog speed or increment selected zzzwill change shade. To select a new speed just select a new number.

  • Page 15: Incremental Jog Mode

    Incremental Jog Mode Deflecting the joystick after selecting 4 -8 will move the slide the indicated increment in the direction de- flected. Each deflection produces one increment. Holding the joystick in the deflected position will not move the slide more than one increment. The cycle start light flashes to indicate recognition and then execution of the increment.
  • Page 16 To set a floating zero Depressing ”S” will cause the present position of the axis to become the zero point. This setting of zero does not effect the location of the Home. This is a local zero that is used in the manual mode if the operator cares to use it.
  • Page 17 To set Tool Offsets The ”T” selection is used to begin the Tool Offset procedure. This is covered in Section 3, ”TOOL OFFSETS”. POSITION FEED 10.0 IPM : X +0.00000 Z +0.00000 COMMAND PERCENT FEED: 100 OFFSET NUMBER: Manual Data Input Automatic Single Block 1.
  • Page 18 Hard Disk Features Backing Up Programs OmniTurn CNC Controls are shipped with a solid-state hard drive (C:) for system and programs, and one 3.5 floppy drive, (A:) for part program backup. The user is given an opportunity to backup his program files when machine is booted up. There is no convenient, automatic way to backup before shutting down, so we back-up at turn-on instead.
  • Page 19 The OmniTurn allows true “background editing” because programs copied to the Users Disk may be edited at a desk-top computer while the program is running on the OmniTurn. The newly edited program can be copied back to the hard drive from the Auto Mode screen with almost no interruption in the machining process.
  • Page 20 OmniTurn FILE COPY MENU Programs on Hard disk Programs on Floppy DEMO DEMO PROG1 PROG1 Exit PROG2 PROG2 PROG3 PROG3 Top prompt line area (see Notes on Use, below) /- - - - - - - - - - - - - - - - - - - - - - - - - -...
  • Page 21 Codes Honored by the OmniTurn control (Sort by Code) Code Usage Description Pages Rapid move ..............11,12 G01Fn Feed move ................ 12,13 G02XnZnInKnFn Arc -Clockwise ............6,15,17-24 G02XnZnRn Arc -Clockwise ............... 6,17-24 G03XnZnInKnFn Arc -Counter Clockwise ........... 6,17-24 G03XnZnRn Arc -Counter Clockwise ........... 6,17-24 G04Fn Dwell ................
  • Page 22 Codes Honored by the OmniTurn control (Sort by Code) Code Usage Description Pages M05 M05 Spindle off, stop ..............62,65,74 Coolant on ................16,62,65 Coolant off ..................62 Collet clamp ..................62 Collet unclamp ................. 62 Spindle Positioning (optional C-Axis only) ........62,74 User assigned on ................
  • Page 23 Codes Honored by the OmniTurn control (Sort by Description) Code Usage Description Pages Absolute mode selection ....... 5,6,10,12,17,19-21,56,59 CAnnn.nn Absolute spindle angle (optional: C—Axis only) ....... 74 G02XnZnInKnFn Arc -Clockwise ..............6,1517-24 G02XnZnRn Arc -Clockwise ..............6,17-24 G03XnZnInKnFn Arc -Counter Clockwise ............6,17-24 G03XnZnRn Arc -Counter Clockwise ............
  • Page 24 Codes Honored by the OmniTurn control (Sort by Description) Code Usage Description Pages Left hand Tool Nose Radius Compensation ......16,37-43 Loop finish ................. 73 Loop start ................... 72 G77Sn Maximum spindle speed for constant surface feet ......6,60 Metric mode ................6,44 G76Sn Minimum spindle speed for constant surface feet ......
  • Page 25 Nomenclature AXIS: X AND Z The slide has two axis’s of travel. X: Towards and away from you. Travel away from you is (-) minus. Towards you is plus (+). Z: The slide that travels along the axis of the spindle. Going towards the spindle is (-) minus. Away from the spindle is (+) plus.
  • Page 26 Model commands: These are commands that remain active until canceled: • G90, G91 -G94, G95 -G70,G71 -G76, G77, G96,G97 -G72, G73 All ”M” codes, G35, G36 (GT-75 only)-G10 One shot commands: These act only on the statement they are programmed in: •...
  • Page 27 Programming Format Feedrate: • This command specifies the speed at which the tool will travel. Once a Feedrate has been established, it remains until it is changed. Feedrates are specified as either Inches per minute (IPM) or Inches per revolution (IPR). X.1Z-.4F7 This line of code has a feedrate of 7 IPM when in G94 (F300 max) X1Z-.4F.005 This line of code has a Feedrate of .005 IPR when in G95...
  • Page 28 -CAM system off line. Transfer a file via floppy or RS-232. Once they are on the OmniTurn program disk they can be run like any other existing program. Please refer to the section in DOS notes on the format.
  • Page 29 Tool call statements The “tool call statement” is done in two lines: XnZn The T command must have a tool number in the range of I through 32. When this command is executed the slide will not move. The display showing the absolute location will change to show the distance the tool being used is from the absolute zero of the part.
  • Page 30 Linear moves X n Z n XnZn Linear one and two axis moves are accomplished by giving the axis and the value to move. The result of a command will depend on which mode is active: G90 or G91, and G73 (radius) or G72 (diameter). X moves default to RADIUS mode (G73), not diameters.
  • Page 31 Linear moves X n Z n XnZn A note about feedrate modes: The feedrate commands are modal. Once they are set they stay in effect until they are changed. So once you set the mode you do not have to change it again until you change the mode. Once the feedrate mode is selected you can change the feedrate by adding the new feedrate to the line of code where you need it.
  • Page 32 Linear moves X n Z n XnZn Using G00 for rapid travels The rapid travel mode can be established by using the G00 command. This will set the mode to IPM at a feedrate specified in the first line of the program. If you do not set the feedrate in the first line of the pro- gram it will use the last rapid move it did in either the manual mode (100”/min) or from the last program that was run.
  • Page 33 Linear moves X n Z n XnZn In the example below we will be finish turning a sample part with a left hand tool. The part dimensions are given in diameters. When the part is programmed these will have to be converted to radius moves. Z zero is set at the face of the part, X zero is set at the center.
  • Page 34 Linear moves X n Z n XnZn G00 X.5 Rapid feedrate, Pull the tool away in X Withdraw the tool in Z End of program command The same example written in diameter mode (G72) G90 G72 G94 F300 Establish Abs. positioning, Feed IPM @ 300”/minute, Radius mode T1 (turn tool) Call Tool #1 offset X0 Z1...
  • Page 35 Running programs using C or R When you use the automatic corner radius or chamfer commands the OmniTurn creates a number of moves to generate what you want. If you look at the command line while you run a program you will notice lines of code that you did write.
  • Page 36 Automatic corner radiusing (R) and chamfering(C) Example Note: The example program shown uses more codes than shown yet to this point in the book. M03, M08, G41, Dn and G40 are covered in other sections. .27" Ø .03 X 45° .5"...
  • Page 37 Arc statements G02 and G03 The arcs G02 and G03 are one shot commands. They are used one time and then turned off. G02 is used to generate a clockwise arc. G03 is used to generate a counterclockwise arc G02 Xn Zn In Kn G03 Xn Zn In Kn G02 Xn Zn Rn G03 Xn Zn Rn...
  • Page 38 Arc statements G02 and G03 Using R version: Before the arc statement is used the tool must be moved to the start location of the arc. Then the arc statement follows with the end of the arc location (X and Z) and the length of the connecting arc’s radius. START OF ARC: move tool to this SIZE OF RADIUS: to be used to fill location before the arc move...
  • Page 39 Arc statements G02 and G03 Description of arcs using I and K in G73 (radius mode) Center Values of I and K Values of Z and X when in Absolute G90 when in Absolute G90 Start G02 - Clockwise Arc Values of Z and X Values of I and K when in Incremental G91...
  • Page 40 Arc statements G02 and G03 G73 - Radius Mode Center Start Values of I and K Values of Z and X when in Absolute G90 when in Absolute G90 G03 - Counterclockwise Arc Values of Z and X Values of I and K when in Incremental G91 when in Incremental G91 G03 - Counterclockwise Arc...
  • Page 41 Arc statements G02 and G03 Diameter mode Arc moves in diameter programming have minor differences from radius programmed arcs. G02 and G03 arc moves in diameter mode (G72) and absolute (G90) Note: -Using arc statements in the diameter mode (G72) be sure you are in absolute (G90) -Position tool at start point before using arc move -This format follows the Fanuc format more-closely than previously G02XnZnInKn •...
  • Page 42 Arc statements G02 and G03 Arc statements using I and K in diameter mode (G72): Center Start G02 - Clockwise Arc End of arc (Xn Zn): This is the same. This is the location of the end of the arc. Values of Z and X when in Absolute G90 Arc center (In Kn): This is different.
  • Page 43 Arc statements G02 and G03 The following picture shows an example of an arc that is machined with G02 -CW using I & K .5Ø .15 radius For this example first we show the three important locations that must be defined to write the arc statement: Center of arc Start of arc End of arc...
  • Page 44 Arc statements G02 and G03 Start of arc Center of arc -.15 So the program lines could be: XOZO G02X.5Z-. 1SIOK-.15 For the next example we will show a G03: .2Ø .1 R .5Ø X0Z0 Z-.3 G03X.4Z-.4I.1K0 Z-.5 2.24...
  • Page 45 Dwell - G04 The dwell statement format is: G04Fn Note: • The 0 in the G04 must be the number 0, not the letter o. • The ”n” after the F is the number of seconds needed to dwell. • The shortest dwell is .1 seconds •...
  • Page 46 G10 Work shift Work shift is used to offset a program from the original starting point. Typical applications are: -Machining multiple parts off a single shootout of a bar. -Shifting a program away from the spindle the first time it is run G10XnZn G10 will shift the reference of the slide incrementally.
  • Page 47 G10 Work shift G96S150 G76S500 G95F .001 X.005 G94F300Z1 Example of shifting a program for bar work With the G10 work shift you can take a program and loop it with the shift so that you get multiple parts done on a single feedout. In the next example three parts will be made with one barfeed sequence: G90G72G94F300 M03S2000...
  • Page 48 G10 Work shift The first time through the program the bar is located with tool #3 Then a part is made with the first loop After the first part is made the program is shifted by the work offset, then the next part is made closer to the spindle 2.28...
  • Page 49 G33 Threading The format is: G33XnZnInKnAnCnPO The X axis location (as a radius) of the final pass of the cycle in G72 mode this is the final pass as a diameter. The Z axis location of the end of the thread The starting incremental amount of material to be removed after the first pass.
  • Page 50 G33 Threading Retraction position between passes: The tool will back away from the starting position plus 3 times the amount of I. Even as the tool gets deeper into the material it will always retract to the same point. Pullout position in Z when using P option: The tool will start to pull out at the location given in Z.
  • Page 51 G33 Threading Threading example Example: A straight thread, Male, 20 pitch, Minor Ø = .424”, Major Ø = .494”, length of thread = .5”, and there is no undercut. .5" .424" .494" .05" For this part the X zero is at the center of the part. The Z zero is at the face of the part. .247"...
  • Page 52 G33 Threading Internal threading example 15/16" - 20 THREAD .4375" .2" .75" In the above example we will be cutting a 15/16-20 internal thread. (written in radius mode, G73): T8 (Internal threading tool) Call threading tool into position X.4375Z.2 Give a value to the tool call location X.4425 Move tool out to take a .005”...
  • Page 53 G33 Threading As an example we will go back and take a cleanup pass on the first external example. We will start the tool in Z at the same position as we did with the first cycle, .2”. The X starting location will be the same diameter.
  • Page 54 G33 Threading Threading, Multi Start Multi start threading can be done by using the regular G33 command. Each start has to be it’s own G33 command, ie. a three start thread would require three G33 commands. The differences between each of the commands would be: Value for K: This value would be multiplied by the number of starts.
  • Page 55 G33 Threading Threading, Tapered G33XnZnInKnAnP Tapered threading is done with the G33 command that includes an ”A”. This is the amount traveled in X over the distance traveled in Z. Value of A Remember that A is the amount over the total distance traveled, this has to include the .2” used to get up to speed.
  • Page 56 G33 Threading Extra Coarse Feeds (IPR) G35 -IPR feeds up to 1” G35F2 -IPR feed up to 2” Format: Start Mode -G35 or G35F2 must be on a line by itself. The following line must be a G92XnZn, where XnZn are the current working coordinates.
  • Page 57 TOOL NOSE RADIUS COMPENSATION G41,G42, G40 Tool nose radius compensation Notes on use: When radii or angles are programmed and you need a very accurate reproduction, you have to take into account the size of the tool nose radius. Otherwise there will not be enough material removed in the area of the radius or angle.
  • Page 58 TOOL NOSE RADIUS COMPENSATION G41,G42, G40 • Tool changes automatically turn off compensation • Tool nose radius compensation can be used in either Radius (G73) or Diameter (G72) modes • When the compensation is turned on or off the tool must be off the part by no less than the size of the radius being compensated.
  • Page 59 TOOL NOSE RADIUS COMPENSATION G41,G42, G40 In the following examples we use the same cutters, and the part geometry is the same. The only difference is the direction of the tool path: LEFT HANDED COMPENSATION RIGHT HANDED COMPENSATION Shifting the TNR compensation The direction of the correction will depend on the direction of the tool path and desired TNR compensa- tion.
  • Page 60 TOOL NOSE RADIUS COMPENSATION G41,G42, G40 (+) X (+)Z (+) X (-)Z Correction needed in secondary offsets: (-) X (+)Z (-) X (-)Z 2.40...
  • Page 61 TOOL NOSE RADIUS COMPENSATION G41,G42, G40 Setting the TNR value: The value used for the compensation of the tool nose radius is stored in the secondary offset table. To enter a value in the table press F9 -SECCMP from the automatic page. This will bring up the secondary offset table: X: +0.00000 Z: +0.00000 R: 0.00000...
  • Page 62 TOOL NOSE RADIUS COMPENSATION G41,G42, G40 Worked examples In the first example a turning tool is used in one direction. G90G94F300 M03S2000 T1 (LH turn tool with .015 tnr) X0Z 1 Z.05 G95F .003 Turn on left hand tool nose radius compensation X0Z0DI Use the radius value found in secondary offset #1 X.22...
  • Page 63 TOOL NOSE RADIUS COMPENSATION G41,G42, G40 Running a program that used Tool Nose Radius Compensation When you write a program with TNR compensation there is another program that is created automatically that has all of the moves that make up the compensated program. When you run the program you will see extra moves in your program that you did not write.
  • Page 64 G70 - G71 Inch - Metric Modes G70 (default) sets the control so that moves and feed rates are in “Inch” mode. It is not necessary to use the G70 command to set the control to Inch Mode at initial turn-on, but if you run an “inch-mode”...
  • Page 65 G74 - Box Roughing Cycle G74 is a box roughing cycle where a rectangular area of material is removed in many passes. G74XnZnlnUnFn X and Z is the corner of the box area to be cleared out In is the maximum amount to be roughed per pass, defined as the depth of cut per side Un amount of material to be left by the cycle for a finish pass in X only.
  • Page 66 G74 - Box Roughing Cycle continued The G74 cycle can be used for either internal or external removal. It can also be used from the front (x+) or back (x-) of the part. Start Start Internal example External example from the back Example behind a shoulder The G74 cycle can be used in radius (G73) or diameter (G72) mode.
  • Page 67 G74 - Box Roughing Cycle continued Worked example for G74 In the following example we will rough the 3/8” stem out from the solid 1” diameter bar. The G74 statement is written to leave .005” on X surface and .003” on the Z surface for a finish pass. The material to be left on the Z axis must be done with the end location value in the G74 code.
  • Page 68 G75 - Box Contour Roughing Cycle continued G75 is the start of a box contour cycle. This cycle serves to rough out an area rounded in part by a contour defined in the part program G75InUnFnPn Un is the amount to be left on the part for the a finish pass In is the maximum amount to be roughed per pass, defined as the depth of cut per side Fn is the feedrate Pn (optional) is a subroutine number...
  • Page 69 G75 - Box Contour Roughing Cycle continued The feedrate is IPM (G94) or IPR (G95), depending on the mode of the control when the cycle is started. The RF code must be on a line by itself. The return passes are at a fixed clearance distance (.02”) from the last cutting pass. The G75 cycle can be used for either internal or external removal, and from the back.
  • Page 70 G75 - Box Contour Roughing Cycle continued This is allowed. The A and B are in the same quadrant relative to the start point relative to the start point. Worked external examples for G75 .343Ø .375Ø .125 x 45" .0935R .593Ø...
  • Page 71 G75 - Box Contour Roughing Cycle continued Written in Diameter mode Written in Radius mode G90G94F300G72 G90G94F300G73 M03S2500 M03S2500 T 1(LH TURN TOOL) T 1(LH TURN TOOL) X0Z1 X0Z1 X.8Z.1 X.4Z.1 G95F .003 G95F .003 G751.05U.02F.003 G751.05U.02F.003 X0Z0 X0Z0 X.343C.125 X.1723C.125 Z-.5 Z-.5...
  • Page 72 G75 - Box Contour Roughing Cycle continued Worked internal example for G75 In this example there is a blank with a predrilled .4” hole. .40 Pre drilled hole .046R .750 .062C 1.00 .03C Notice the starting point is at the minor diameter of the finished bore, and the A and B points are at the starting and ending points of the finish contour.
  • Page 73 G78 - Rough Contour Cycle G78 is the start of a rough contour cycle. This cycle serves to rough a contour based on a section of pro- gram code describing a finish contour. G78UnFnPn Un is the amount to be left on the part for the a finish pass, (amount per side) Fn is the feedrate Pn (optional) is a subroutine number The box cycle starts at the current position, then makes a cutting pass parallel to the final contour, but away...
  • Page 74 G78 - Rough Contour Cycle continued Worked example for G78 The following code is a finish pass for the same example for G75. Please refer there for the part layout. In this example we are using a different tool to take the finish contour pass, T2. G90G94F300G73 M03S2500 T2(LH Finish TURN TOOL)
  • Page 75 G78 - Rough Contour Cycle continued Finish pass to depth with same tool G00Z1 X0Z0 X. 343C.125 Z-. 5 X.406 G02X.406Z-. 687R. 0935 X.375 X.75 2.55...
  • Page 76 G81 Drill Cycle G81 is a one shot command. It is used to feed to a drill a specific distance in Z and then rapid back to the starting point. The format is: G81 Zn Fn Starting point Starting point Feed In Feed In Rapid Out...
  • Page 77 G83 Peck Drill Cycle G83 is a one shot command. It is used to peck drill to a specific distance in Z and then rapid back to the starting point. The format is: G83 Zn Kn Fn Rn Ln Cn Starting point Starting point Feed...
  • Page 78 G83 Peck Drill Cycle Z = .5" Starting point To drill a part .5” deep at a feed of .003” per revolution, and .1” pecks. The program would be: G90 G94F300 Puts the control into absolute mode Calls tool #1 offset X0Z.01 Positions tool at x=0, Z=.01 Sets ipr mode...
  • Page 79 G90, G91 - G92 - G94, G95 G90 and G91 Absolute and Incremental mode selection G90 and G91 set the mode of operation of the control. These commands are used in the program. Once one of these commands are used it stays in that mode until it is changed. There should be one of these commands in the first line of your program.
  • Page 80 Constant Surface feet spindle speeds - G96, G97, G77, To use the following codes the OmniTurn must be equipped with a spindle control package. There are two types of spindle speed control modes that the OmniTurn control can use: Spindle speed in RPM -(G97). In this mode the S value will set the spindle speed in turns per minute, ”RPM”.
  • Page 81 Program commands - “M-Codes” ”M” codes are commands that control operations other than slide movements. These commands are Model. That is, once turned on they stay active until turned off. Some M codes control optional attachments that have to be wired into your lathe. The wiring schematics and example uses are included in the ”Options Documentation”...
  • Page 82 Spindle on, reverse (top going) Spindle off OmniTurn with no spindle encoder: The M03 and M04 will stop the program and instruct the operator ”WAITING FOR SPINDLE”. If the control has an encoder for threading it will know that the spindle is turning.
  • Page 83 These M-codes stop the program until an input ins “on” or “off”. This is useful for coordinating activity for an auto-loader primarily. The OmniTurn ‘waits’ (the program stops, like M00 or M01) until the input is in the correct state.
  • Page 84 Spindle Control Option Cycle Start The cycle start PB on the face of the OmniTurn control is deactivated when a spindle drive control is installed. In its place an Operator Station is supplied: COLLET E-STOP COLLET OPEN CLOSE PALM BOX This station has two palm buttons on the sides of the box -PB 1 and PB2.
  • Page 85 Spindle off automatically at the end of the program: M30 Spindle off by command in the program: Manual override: There is a switch on the face of the OmniTurn control that will turn the spindle off. Leaving the spindle on at the end of the program: If you are running a job automatically (bar work or automatic loaders) and want to leave the spindle running at the end of the program use M02 for end of program.
  • Page 86 Spindle Control Option continued Setting the spindle speed range (for attachments only, GT-75 is done by the factory): With the spindle drive it is possible to setup different maximum speeds to make available more HP at lower spindle speeds. The inverter drives that we use to vary the speed are constant torque at all RPMs. However the HP is lower at the lower RPMs.
  • Page 87 Secondary Offsets What are secondary offsets? Secondary offsets are corrections that you can put into your program that the operator can adjust when running the program without having to go into the program to edit it. Once the program has been written with the secondary offsets incorporated, these corrections are made by pressing F9 while in the Automatic mode and inputting the amounts.
  • Page 88 Secondary Offsets Using Secondary Offsets Secondary offsets are used with D commands. The format is the same as a T command. Add the D with a number, ie: ”D2” for #2 secondary offset, to the line of code to be corrected. This command will call up the value located in the secondary offset table and add it to the move.
  • Page 89 Secondary Offsets continued X. 125 X. 125 move to the diameter Z-.75 Z-.75D4 turn the diameter, corrected X.2D0 move to the major diameter, turn offset off If there is no problem with a taper on the part, the X and Z values of D4 are set to zero. If, however, there is a taper, say .001”...
  • Page 90 Secondary Offsets continued Secondary offset examples: A taper that has to be single point turned and then maintain the major diameter. A taper turn The actual taper that a tool cuts will depend on the toolnose radius. If this is not an easy tool to maintain then the taper will vary as the tool changes.
  • Page 91 Secondary Offsets continued Here is another example: Ø=.3" Ø=.4" Ø=.5" For this example, three diameters have to be turned with only one tool. Each of the diameters can have an individual offset. The coding for this is: X-.35Z0 Move to the face of the part at -.7 diameter X.25D1 Move to .5”...
  • Page 92 Looping Looping is used to perform repetitive moves without having to write long programs. The start of a loop is defined by LS and then the number of times you want to execute the loop. IE: LS35 will start a loop with 35 repetitions.
  • Page 93 Looping Looping with Work Shift (G10) It is easy to loop a portion of a program and have it shift over using work shift -G10. This enables you to do many parts with only one feed out of a bar. In the following example it will show how to drill one deep hole and then turn and part off 6 thin rings.
  • Page 94 Spindle Positioning Spindle positioning system specifications -Option on GT-75 only. Spindle power: Voltage: 200 -230V 3 phase or single phase (contact the factory for wiring) Resolution: .02 ° Max Speed: 3500 rpm Min Speed: .004 rpm Programmed by itself causes the spindle to position via the shortest route to 0°. After the command is executed the spindle is locked in position.
  • Page 95 Spindle Positioning Example showing positioning and cross drilling In the following example we show a drill mounted on the slide. The slide will be used to drill the holes. We will drill (4) holes 90° apart, the first hole is located at 27.5°...
  • Page 96 Spindle Positioning Two examples showing rotational milling, g95 & g94 .3" .2" 45° 0° Using g95 mode to cut the slot as a lead where z-length of slot is percentage of one revolution: g90g94f300g73 t2 ....(Live Mill from the side, below part) x.75z 1 z-.2 g35 ....
  • Page 97 What are tool offsets? When you turn on the OmniTurn it does not know where it is. However the position commands used in the program assumes that it does. In order to run a program the control needs to know where the slide is and where the tools are.
  • Page 98 Tool Offsets Tool #4 Tool #4 Z offset Tool #2 Tool #2 Tool #2 Z offset Tool #1 Tool #1 Tool #1 X offset X offset Starting position Starting position Tool #1 Tool #2 for Tool #2 for Tool #1 Tool #3 Tool #3 Illustration of tool offset for Tool #2...
  • Page 99 There are now two different ways to establish the location of the tool after a tool call (tool offset): G92 statement -original system software available on all OmniTurn’s Non G92 statement -This code is only available on system disks dated after 11/96.
  • Page 100 Tool Offsets If however you call a tool that has not been set, there may be a collision. For the following examples we will assume: • The material is approx. .5” diameter. • The part will be programmed so that all of the tools will start at the center of the part in X, and .1” away from the face in Z.
  • Page 101 Tool Offsets To Set Left Hand Turning Tools continued POSITION FEED 10.0 IPM : X +0.00000 Z +0.00000 COMMAND PERCENT FEED: 100 : X +0.00000 Z +0.00000 MAKE JOG SELECTION Automatic Single Block Manual Data Input 1. Slow 7. .1000 2.
  • Page 102 Tool Offsets To Set Left Hand Turning Tools -continued POSITION : X +0.00000 Z +0.00000 COMMAND : X +0.00000 Z +0.00000 PRESS X or Z TO STORE PRESENT X or Z AXIS OFFSET Automatic Single Block Manual Data Input 1. Slow 7.
  • Page 103 Tool Offsets To Set Left Hand Turning Tools -continued Measured Ø = .4923" Take some care but do not be overly careful since any error made here can be easily corrected with the tool offset correction later when you are making the first piece. After typing .4923 hit ”RETURN”. Now establish the Z offset, for tool #3 The setting of the Z offset is a little different.
  • Page 104 Tool Offfsets Using an unmachined part to set Z: If you are using a rough part that has material left on the face to be removed you can still use it. Before you put the part in the collet measure how much you have to make the part to size. Then touch off on the known face.
  • Page 105 Tool Offsets • The screen will show ”Z OFFSET ENTERED”. You are now done with the Z offset for tool #3. Press “ESC” to return to the Jog menu. Setting a Drill (Tool #1) • Start the same as with the left hand turning tool, be sure that the slide has been HOMED •...
  • Page 106 Tool Offsets An alternative method of setting drill: Position the tool as show below. Either side of the tool will do. Setting up a drill on the + side of the spindle Setting up a drill on the - side of the spindle Above there are two ways to setup a drill.
  • Page 107 Tool Offsets Setting ID Tools, ie Boring tools & Threading tools The procedure for setting ID tools is similar to the two previous tools. The only difference is how you will touch off to determine the turned diameter. Setting a boring tool on the ID. Setting a boring tool on the OD.
  • Page 108 Tool Offsets Setting Threading tools, continued Setting Z: The approximate location of the tool can be done by eye with the corner of the piece. Estimate the face of the part 3.12...
  • Page 109 OmniTurn Sample Part Welcome to the OmniTum. This document is a tutorial used to run a first program with the OmniTurn. It is suggested before you try to work with this tutorial that you spend some time reading the manual and gain a basic understanding of the programming and operations of the system.
  • Page 110 OmniTurn Startup sample part .7" .65" .35" .125 .25 .4 .05r 45° .4 X 20 THREAD If you are familiar with machining you might want to skip to the next section, ”TOOLING” OPERATIONS We will start with a solid piece of material 1/2” in diameter, 3” long.
  • Page 111 OmniTurn Startup sample end After the drilling we change back to the turning tool to face and finish turn the OD. With the OD finished we can thread. (if your attachment does not have an encoder for threading you will have to skip over this operation) After the threading is complete we will change back to the turning tool to turn the major diameter of the thread to help deburr the OD.
  • Page 112 Only concern yourself with understanding what we have done and how our program works so you can work with the general format to create your own. In order to enter the part into the OmniTurn you will have to enter a new program: -Turn the OmniTurn on...
  • Page 113 OmniTurn Startup sample part have the tool automatically stop before it takes a cut and look to see if it came to the right location. X.1 Z.025 • We will use the first tool to act as a material length stop. Here we are positioning the tool a little off center and in front of zero of Z.
  • Page 114 OmniTurn Startup sample part X.225 • This clears the tool, still in the feed mode G94F300Z1 • Change to rapid and move the tool to Z 1, this is clearance for a tool change T2S2500(Center drill) • The center drill is called into position and the spindle speed is changed.
  • Page 115 OmniTurn Startup sample part T4(Thread tool) • Calls the threading tool offset X0Z1 • Moves the threading tool to a safe location • Optional stop for the tool check on the first run through G04FI • This is a dwell used to allow the spindle to change speed •...
  • Page 116 OmniTurn Startup sample part Saving the program to the disk Now to save the program press Fl to get back to the main page of the word editor Then press F3 to save the program to the disk Then press F2 to exit the program Verify the program Before you run the program it is best to look for possible mistakes.
  • Page 117 Then move the slide in Z only to clear the material, do not move in X! Turn the spindle off. If you have the spindle control use the switch on the OmniTurn panel. Then measure the diameter with a micrometer Measure diameter Now press T -”SET TOOL ”...
  • Page 118 OmniTurn Startup sample part Now the control asks for the diameter of the part you just cut. Enter this measurement and press return. To go back to the jog mode and continue with the entering of the offsets press the ESC key.
  • Page 119 OmniTurn Startup sample part Setting X for a Drill Position drill so it clears part Tool #2 Tool #1 With the slide and tooling set as shown above lightly secure the center drill and holder to the slide. Then put a 1/2” bushing into the holder and a 1/2” collet in the spindle. Jog the slide until the tool holder with the 1/2”...
  • Page 120 OmniTurn Startup sample part For Tool #3 follow the same procedure with setting the drill. Tool #2 Tool #1 Tool #3 Next is the threading tool. Here we will use another technique. Instead of cutting with the tool we can use the cut surface from setting the first tool to establish the location of this tool.
  • Page 121 OmniTurn Startup sample part Then press ESC and jog the tool until it is just even with the end of the material. This location is generally not that critical so don’t waste to much time. Tool #4 Tool #2 Tool #1 Tool #3 Now that you have the tool where you want it in Z you can establish the tool offset.
  • Page 122 OmniTurn Startup sample part Checking the tool offsets Once you have entered the tool offsets you might want to check and make sure the tools go where you expect them to. One way to do this is in the MDI mode. Here you can call the tools and they will go to the set tool offset positions.
  • Page 123 OmniTurn Startup sample part Testing the program Now that you have made sure that the tools go to where you think they should it is time to test the program you have written. Go to the Automatic mode screen. If you were still in the MDI mode you could press F1 to quit MDI, and then press A from the main menu screen.
  • Page 124 OmniTurn Startup sample part Select a lower feedrate % POSITION FEED 10.0 IPM : X +0.00000 Z +0.00000 COMMAND PERCENT FEED: 100 : X +0.00000 Z +0.00000 FILE TO BE PROCESSED Preset feedrate override using F1-F10 Automatic Single Block Manual Data Input...
  • Page 125 OmniTurn Startup sample part Press "S" to select single step mode POSITION FEED 10.0 IPM : X +0.00000 Z +0.00000 COMMAND PERCENT FEED: 100 PRESS CYCLE START Manual Data Input Automatic Single Block F1-F10 FEED 10-100% FILE IN MEMORY: SAMPLE1...
  • Page 126 OmniTurn Startup sample part Should be .250" If we now make a part and measure it there will probably be variations from what you program and the size of the finished part. These differences can come from a number of sources, minor errors in establish- ing tool offsets, tool deflections, material deflection.
  • Page 127 OmniTurn Startup sample part X: +0.86480 Z: -1.25340 X: +0.00000 Z: +0.00000 X: +1.65025 Z: -1.99200 X: +0.00000 Z: +0.00000 X: +2.91130 Z: -0.93885 X: +0.00000 Z: +0.00000 X: +0.00000 Z: +0.00000 X: +0.00000 Z: +0.00000 X: +0.00000 Z: +0.00000 X: +0.00000 Z: +0.00000...
  • Page 128 Worked Examples 1/2" x 13 thread .05r .3" .8" 1.0" In the above example, the finished part will be made part from a cutoff blank .61” diameter by 1.1” long. The first item to take care of is the layout of the job. This will entail what our sequence of operations will be.
  • Page 129 Worked Examples Tool #1 The turning tool will start at the center of the part in X and .2” away from the face in Z. This .2” in Z will give enough room in Z so that the tool will not crash into the face if the part is a little long.
  • Page 130 Worked Examples (THIS IS A SAMPLE PART FOR OMNITURN) G90 G94 F200 G92 X0 Z.2 Tool #2 X.35 Threading tool Z.01 X0F3 X.26F200 Tool #1 turning tool Z-.79F3 X.27F200 X.21 Tool #2 Threading tool Tool #1 turning tool (10) Z-.29F3 (11) X.22...
  • Page 131 Worked Examples (15) X.15 (16) G02X.2Z-.051.15K-.05 (17) Z-.3 (18) X.25Z-.35 Tool #2 (19) Z-.8 Threading tool (20) X.3Z-.85 (21) (22) X.32 Tool #1 turning tool 18 17 (23) Z.5F200 Tool #2 Threading tool Tool #1 turning tool (24) G92X.245 Z.2 (25) G33X.22Z-.81.005K.0769P Tool #2...
  • Page 132 Worked Examples 1.00" .25" .02 x 45° 2 plcs 1.00" .6125" .75" In the above example we will be using two boring tools to finish the face and ID. Tool #1 Roughing boring bar Blank Tool #2 Finishing boring bar The blank has been predrilled and is a little longer than the finished part.
  • Page 133 Worked Examples X.55 G95 F .003 Rough face G94 F200 Z.015 X.34 G95 F.002 Z-.235 Rough bore Z-1.05 X.29 G94 F200 Z.5 G92 X.55 Z.1 S3000 (10) G95 F:002 X.395 (11) X.375 Z-.02 D1 Generate chamfer with correction to effect first bore (12) Z-.25 D2 Bore first diameter with correction for shoulder length...
  • Page 134 Automatic Mode Running programs In the Automatic mode the control displays the program that it is currently running. When the control is turned on there is no program selected to run and this space is blank. Be sure that the tool offsets are correct for the program to be run. If this program is the same as when the control was last shut down, the offsets should still be the same and the program will run without resetting the tools.
  • Page 135 Automatic Mode There is a program in memory ready to run POSITION FEED 10.0 IPM : X +0.00000 Z +0.00000 COMMAND PERCENT FEED: 100 : X +0.00000 Z +0.00000 PRESS CYCLE START Automatic Single Block Manual Data Input F1-F10 FEED 10-100% FILE IN MEMORY: DEMOPR '0' FOR OPTIONAL STOP '/ ' FOR BLOCK DELETE...
  • Page 136 Automatic Mode The ”F” keys have the following functions: Quit Go back to the Main menus Offset Adjust tool offsets, correct part size Edit Input and correct programs When no file is in memory this will list all the programs on the user disk With a program in memory it will verify and plot the program Newprog This will remove the program from active memory and allow a new one to...
  • Page 137 SysRq Lock Break PgUp Key Spindle & Backspace 100% coolant On/Off Home PgUp " Caps Parts Pg Dn Key Enter Lock Catcher PgUp Parts catcher < > In/Out Shift Shift Spindle Spindle Ctrl Fn Ins Del OmniTurn front panel Keyboard...
  • Page 138 Automatic Mode Parts counter - P POSITION FEED 10.0 IPM : X +0.00000 Z +0.00000 COMMAND PERCENT FEED: 100 : X +0.00000 Z +0.00000 PRESS CYCLE START Manual Data Input Automatic Single Block F1-F10 FEED 10-100% FILE IN MEMORY: DEMOPR Parts counter '0' FOR OPTIONAL STOP '/ ' FOR BLOCK DELETE...
  • Page 139 There are a number of ways to create a new program. Here are a few: -Use the text edit in OmniTurn. First a new program name has to be created. This is done by going into the Automatic mode and typing in the new name when the control asks ”FILE TO BE PROCESSED”.
  • Page 140 Automatic Mode Function Keys On the top of the keyboard is a group of ”F” keys. These are used differently throughout the control soft- ware. Notations are made on the screen to help the operator remember how the keys are being used with the different sections of software.
  • Page 141 Automatic Mode After selecting a number and pressing Return the screen will ask X: +0.86480 Z: -1.25340 X: +0.00000 Z: +0.00000 X: +1.65025 Z: -1.99200 X: +0.00000 Z: +0.00000 X: +2.91130 Z: -0.93885 X: +0.00000 Z: +0.00000 X: +0.00000 Z: +0.00000 X: +0.00000 Z: +0.00000 X: +0.00000 Z: +0.00000 X: +0.00000 Z: +0.00000...
  • Page 142 Automatic Mode Notes: The control will allow you to clear the offsets by pressing C (for clear). Please only do this when you have had experience with the control and understand what you are doing. Clearing offsets can cause you to crash tools if it is done incorrectly! The smallest offset changes are: .00005”...
  • Page 143 Edit, On screen text editor, used to change existing programs, or enter new ones The editor is a full function text editor. In the OmniTurn you will be using only a small part of the capa- bility of the editor. In the following description the most basic functions. If you want to learn more follow the instructions given in the HELP screens.
  • Page 144 Ctrl Fn Ins Del OmniTurn front panel Keyboard Number keys: Use the number keys across the top of the keyboard. The number keys on the right side are not active as numbers unless set with the number lock key. (located above the #7 key) Cursor keys: These are the number keys on the right side of the keyboard.
  • Page 145 Automatic Mode -Notes on the Editor The text editor can help you manipulate and modify your programs. The editing functions are: F4 -Block delete This function is used to erase sections of the program. To use this function: • move the cursor to the beginning of the code that you want to erase •...
  • Page 146 F4 indication on the bottom of the screen changes to VER. Press F4 and the verification software will be called up. 1. Syntax and program check. Omniturn Verification Software Program name G94F200Z1 No errors found.
  • Page 147 Missing spindle speeds: If the program does not have a spindle speed the OmniTurn will comment. This is because a spindle speed is needed to estimate the cycle time. If you do not want to add a spindle speed to the program you can force a cycle time estimate in the verification when it asks for a spindle speed.
  • Page 148 Verification - F4 Omniturn Verification Software Program name Tool Description G92Z (LH Turning tool 008 radius) 0.10800 0.20800 (LH Threading tool) 0.00000 0.20000 Use Arrow keys to move to error and correct. ESC>Exit Secondary offsets use Offset Offsets No Secondary offsets specified.
  • Page 149 Before you show the graphics you have to chose to show them with or without the tool offset locations. If you are running this software on your OmniTurn and the tools have all been set, then enter yes. If they have not been set or you are running the software off-line, then say no.
  • Page 150 Verification -F4 Then select the tool that you want to see. Or all. Use the Up / Down arrow keys again. Then press Enter. Omniturn Verification Software Select tool for verification: Use Cursor Keys; Press Enter to make a selection. ESC>Exit Select the speed of the graphics display.
  • Page 151 Verification -F4 Window size: X = 0.550 Z = 1.364 (Z)oom (F)ull view ESC>Exit Tool number: 1 ; 2 Window size: X = 0.550 Z = 1.364 (Z)oom (F)ull view ESC>Exit Tool number: 1 ; 2 Notes about the graphics: The graphics will show the path created by the G code in the program.
  • Page 152 As an example, if you are want to skip to Tool #2 type in T2. The control will skip the code before this line and start the program with the T2 command. If you are using an OmniTurn with spindle control be sure that after your tool changes you have a spindle on (M03 or M04) and an S command.
  • Page 153 Automatic Mode Programming system, Calls up the Calcaid programming system See the section on Calcaid. Chapters 9 and 10 in this manual. Diskop, Calls up a list of Disk operations The F8 key will call up the following screen: File Handler Would you like to: 1.
  • Page 154 Automatic Mode This will exit the file handling screen and bring you back to the Automatic mode screen. Secondary tool offset screen, used to modify secondary tool offsets This function will call up the secondary offset table. There are 32 offsets available and 32 tool nose radius compensation offsets.
  • Page 155 As an example you could set the machine up and tell it you need 20 pieces. The OmniTurn will make the required amount and then stop. • If you have the infinitely variable spindle speed control this will let you tell the control what spindle speed the machine is set at.
  • Page 156 Automatic Mode POSITION FEED 10.0 IPM : X +0.00000 Z +0.00000 COMMAND PERCENT FEED: 100 : X +0.00000 Z +0.00000 FILE TO BE PROCESSED: Manual Data Input Automatic Single Block F1-F10 FEED 10-100% Preset feedrate override using F1 - F10 FILE IN MEMORY: TEST A part program must be active before '0' FOR OPTIONAL STOP...
  • Page 157 Automatic Mode Feedrate override Function Keys - Automatic Mode - Program in process When the program is running it is possible to change the feed rates. The function keys will select a percentage of the original feedrate. F1 = 10%, F2 = 20%, ..F10 = 100%. IE if you push F1 while the program is running the feedrate will drop to 10% of what ever you have set in the program.
  • Page 158 • Check that the Spindle Drive is not faulted; press the reset button on the the spindle drive cabinet located at the left side of GT-75 and GT-Jr. • Check the hatch on GT-Jr, or any interlocked doors on your system. To jog the machine with door open during setup, get the interlock bypass key from your supervisor.
  • Page 159 OmniTurn - Trouble shooting guide Positioning Problems: The slide has problems with repeating a size Using Ctrl-C & Ctrl-H to diagnose repeatability problems These two tests will determine if the problem is in the control or the axis motor without needing any addi- tional tooling or indicators.
  • Page 160 OmniTurn - Trouble shooting guide Positioning Problems: The slide has problems with repeating a size • The part is moving, check your work holding fixture • Be sure the tooling is held tightly • If you have an attachment, see if the slide is loose on the lathe •...
  • Page 161 OmniTurn - Trouble shooting guide Computer won’t complete start-up • You get a message that the OmniTurn is ”Initializing” and on the next line there is a number: ie. 255. • This indicates that the OmniTum Motion card is not found. This card has either come loose and needs to be resettled or replaced.
  • Page 162 OmniTurn - Trouble shooting guide OMNITURN MOTOR REPLACEMENT INSTRUCTIONS Removal: 1. You need to have the room to access the motor coupling on X or Z axis in order to change the motor, so first move the slide away from the motor.
  • Page 163 OmniTurn - Trouble shooting guide To Disassemble the CNC Control Un-plug power cord, then remove the blue cover. Remove six screws holding front panel. “Upper Half” To gain access to the computer, disconnect all It is not necessary to disconnect cables to front- cables at rear of CNC, remove eight screws and panel.
  • Page 164 OmniTurn - Trouble shooting guide OmniTurn CNC “Top Half” To adjust the spindle speed with a tach: 1. Issue M03 S0 from MDI; adjust SP MIN for no rotation. 2. Issue M03 S4000 (S3000 on attachments); adjust SP MAX for correct rpm.
  • Page 165 OmniTurn - Trouble shooting guide OmniTurn CNC “Connect Card” MISC SPINDLE Z MOTOR X MOTOR PWR CORD SPIN SW SPIN POT THIPR REF LS Z DRIVE X DRIVE CONNECT2A N/C ELECTRONICS ARM. RELY PORT ORFORD,OR OmniTurn CNC Servo Amplifier POTS...
  • Page 166 OmniTurn - Trouble shooting guide OmniTurn CNC “Bottom Half” POWER SUPPLY DRIVE BAY TF-486F CN8 (BLK wires to CENTER) KEYBOARD JACK HARD DRIVE IDE1 IDE2 COM1 COM2 PCI1 cpu fan COM CABLES ISA1 SLOT ISA2 SLOT VGA CARD ISA3 SLOT...
  • Page 167 OmniTurn - Trouble shooting guide Replacing the MC2 (Motion Control or C-AXIS cards) To access these cards the entire “top half” of the control must be removed: • Unplug the power cord. • Disconnect the cables at the back (two axis motors, MISC, Encoder, PLC (optional) •...
  • Page 168 Fine tipped probes, or paper clips Jewlers common screwdriver or “tweaker” 1. With the OmniTurn control completely powered down, depress ”CONTROL ON” and allow the control to boot up to the point where the message ”PLEASE TURN ON SERVOS” is displayed.
  • Page 169 Ø 5. Use a small screw driver to adjust the ”BALANCE” pot on the OMNITURN AMP. Turn the pot until the value on the screen is 0. Do this procedure with the slide at rest, no motion. Do this for both the X and Z axes.
  • Page 170 OmniTurn - Trouble shooting guide 6.13...
  • Page 171 OmniTurn - Trouble shooting guide NOTE: This drawing includes optional components and references not on all panels. LINE REVERSE PART CATCHER PLC X0 (rst) "NOT" FAULT SPINDLE COOLANT SPINDLE OR AUX (Option) DISC1 Bussmann I CDNF32 PLC 0V (Option) LIGHT IS ON WITH...
  • Page 172 OmniTurn - Trouble shooting guide 6.15...
  • Page 173 OmniTurn - Trouble shooting guide Op Plug Misc Plug 12VDC (Drv Cab) Unclamp Palm Box E-Stop Dual FEEDHOLD Palm Buttons INHIBIT CYCLE START OmniTurn 6.16...
  • Page 174 OmniTurn - Trouble shooting guide and references not on all panels. L1 AND L2. 220VAC YASKAWA GPD315 VIO 23 DOOR (Drv Cab) D6 (PLC isolation) Fault Fault 12V COM Accel: No 19 = 1.0 [2.0] Decel: No 20 = 1.0 [3.0]...
  • Page 175 OmniTurn - Trouble shooting guide 6.18...
  • Page 176 OmniTurn - Trouble shooting guide CONTROL LINE E-STOP FILTER SERVO POWER SUPPLY TO SERVO AMPS 110VAC LINE 72VDC NOTE: TS1 AND TS4 ARE PART OF CONNECT CARD PART OF MC2 CARD +12PS 12V IN +12SW ARMATURE RELAY 12SO CONTROL SERVOS...
  • Page 177 OmniTurn - Trouble shooting guide Four Way Dual Solenoid To Collet Clamp Regulator (Adj) To Collet UnClamp Four Way Single Solenoid Filter/Regulator To Parts Catcher To Parts Catcher Three Way To Spindle Bearings Regulator (6psi) To Collet Closer Lube Regulator...
  • Page 178 OmniTurn - Trouble shooting guide 6.21...
  • Page 179 OmniTurn - Trouble shooting guide NOTE: This drawing includes optional components LINE IN and references not on all panels. "NOT" FAULT SPINDLE COOLANT PART CATCHER ENABLE OR AUX DISC1 Bussmann I ON SPEN CDNF32 LIGHT IS ON WITH LIGHT IS ON SP.ON/OFF 12VDC...
  • Page 180 OmniTurn - Trouble shooting guide 6.23...
  • Page 181 OmniTurn - Trouble shooting guide NOTE: This drawing includes optional components NOTE: All relay coils have diodes: and references not on all panels. Op Plug Spindle OFF/AUTO 12VDC Palm Box E-Stop Switched 12VDC Spindle ON/OFF on Control 12V COM Sp.Pres...
  • Page 182 OmniTurn - Trouble shooting guide COOLANT PUMP 220VAC 110VAC STEP DOWN XFMR (MOUNTED OUTLETS FOR ON XFMR) WORKLAMP AND CONTROL SP.CAB YASKAWA SGDH-50 EXTERNAL REGEN 8.5 OHMS 250W 220VAC LINE SRVO.FLT MOTOR/TACH DC COM 1CN-32 Opens (TB1-22) CN4-2 Fault 12VDC...
  • Page 183 5HP SPINDLE DRIVE YASKAWA GPD315 MB: BLK FAULT to FLT-13 MC: BRN FAULT TO FLT-1 S1: RED TO MO3-8 S2: YEL TO MO4-8 R U N DSPL S4: VIO TO RESET PB-23 SC: BLU TO RESET PB-24 DATA STOP ENTER R E S E T SC: ORG TO MO3-12, MO4-12 FR: CLR ANALOG SIGNAL...
  • Page 184 • This file is stored on the system disk on the A: drive. • Exit the OmniTurn software and go to DOS. This is done by going to the main menu and pressing the left shift and then while holding it press the ESC key. If this does not work you can get to DOS through the word processor.
  • Page 185 2. Create SYSTEM DISK for your system per instructions on that page. 3. Power up your Omniturn, then drop to DOS by holding left “Shift” key and pressing “Esc” key. 4. Put new system disk in lower drive. At C:\OMNITURN prompt, type A:\UPD then press Rtrn.
  • Page 186 Then it asks if you want to make changes. Normally you don’t do anything and the system goes past this and it starts the OmniTurn software. Follow the instructions on the screen to make changes.
  • Page 187 -are secondary offsets stored for the program C: The OmniTurn software constructs a RAM disk C: drive. This is not a hard disk, it is only temporary. All information stored on this drive is lost when the system is shut down. This ”disk” is used to speed up the operation of the word processor.
  • Page 188 Word Perfect. (Save the file as an ASCII file) Then bring the disk out to the OmniTurn, put it into the B: drive and run it. The rules that you must follow...
  • Page 189 RS-232 Cable Default settings -2400, 8, 1, N FROM OMNITURN 9 PIN TO COMPUTER W/9 PIN OMNITURN 9 PIN TO COMPUTER W/25 PIN OmniTurn Computer OmniTurn Computer DB25 RX 2 2 TX TX 3 3 TX DCD 1 8 DCD...
  • Page 190 RAM BIOS Setup For a 286 Computer Date: Time: Floppy A: 1.44 Mb 3 1/2” Floppy B: 1.44 Mb 3 1/2” Hard Disk C: Hard Disk D: Primary Display: Monochrome Keyboard: Installed Disabled Video BIOS Shadow: Scratch RAM Option: Disabled Main BIOS Shadow: Turbo Speed: Enabled...
  • Page 191 Configuring the OmniTurn Since the OmniTurn is a PC in most cases all you will have to do is add a network card to the control and some software to the system disk. With the OmniTurn software you will have to adjust the PRM.SER file to look to the server for its programs.
  • Page 192 Basic system configuration for networking Computer: Here we list a simple system that will work in supporting a network for the OmniTurn. With the changing computer market it is possible to get a lot more computer for just a little bit more money.
