Summary of Contents for Twothousand TT-F65
- Page 1 VEGETABLE CUTTING MACHINE OPERATION MANUAL TT-F60 / TT-F65 TT-F60 TT-F65...
-
Page 2: General Precautions
NEVER REPLACE PARTS OF THE MACHINE BY YOURSELF, BUT APPLY TO TH ASSISTANCE SERVICE. 2. TECHNICAL FEATURES .1. SPECIFICATION SHEET WEIGHT POWER ELECTRICAL DIMENSIONS MODEL WATTS CONNECTION DISC 230V/1/50Hz TT-F60 24.5 50X25X46 550W or 750W 115V/1/60Hz 300 RPM TT-F65 for your choice 50X25X47 380V/3/50Hz... -
Page 3: Installation
2.2. SUPPLY CONDITIONS AND DISPOSAL OF PACKINGS HE CUTTING MACHINE IS PACKED IN A STURDY CARDBOARD BOX WITH INTERNAL SHAPED EDGES WHICH GUARANTEE THE PERFECT INTEGRITY OF THE MACHINE DURING TRANSPORT. HE EQUIPMENT INCLUDE: INSTRUCTIONS FOR USE AND MAINTENANCE EJECTING DISC ALL THE PACKING COMPONENTS (CARTON, FOAM, STRAPS, AND SO ON) CAN EASILY BE DISPOSED OF AS HOUSEHOLD RUBBISH... -
Page 4: Use Of The Equipment
THREE-PHASE CONNECTION SINGLE-PHASE CONNECTION 3.3. SAFETY MEASURES AND TRAINING THE FINAL USER THE SKILLED PERSONNEL IN CHARGE OF THE INSTALLATION AND ELECTRIC CONNECTIONS OF THE EQUIPMENT IS RESPONSIBLE OF THE TRAINING OF THE FINAL USER, WHICH MUST ALSO BE INFORMED ON THE SAFETY MEASURES TO COMPLY WITH. - Page 5 COVER OPENING (1) DISC POSITION (2) ATTENTION TO DISC BLADES!! 4.3. CHOICE OF THE DISCS DISC CHOICE FOR VEGETABLE CUTTER MACHINE PICTURE PART NO. SIZE G002 G003 Shredding G005 G007 G010 10mm SA002 2mm (three blades) SA004 4mm (two blades) SA006 6mm (two blades) Slicer (aluminium)
- Page 6 4.4. USE OF THE DISCS THE UNIT IS SUPPLIED WITH THE EJECTOR FITTED TO THE DRIVE SPINDLE. OPEN THE COVER LOCK AND LIFT THE COVER FULLY IN ORDER TO REMOVE THE EJECTOR. BEFORE STARTING WORK, ALWAYS CHECK THE CLEANLINESS OF THE CUTTING CHAMBER, THE DRIVE SPINDLE, THE EJECTOR, THE CUTTING DISCS AND THE GRID.
-
Page 7: Cleaning And Maintenance Operations
5. CLEANING AND MAINTENANCE OPERATIONS 5.1. GENERALITIES AND PRODUCTS FOR CLEANING BEFORE CARRYING OUT ANY CLEANING OR MAINTENANCE OPERATIONS, CHECK TO MAKE SURE THAT THE MAINS SWITCH BE OFF AND THE SUPPLY PLUG DISCONNECTED FROM THE MAINS. ACCURATELY CLEAN THE EQUIPMENT AND THE DISCS EVERY DAY FOR A CORRECT OPERATION AND LIFE OF THE EQUIPMENT. - Page 8 5.3. MACHINE IDLE FOR A LONG TIME SHOULD THE MACHINE BE IDLE FOR A LONG TIME, DISCONNECT THE MAIN WALL SWITCH AND CLEAN THE MACHINE AND ITS ACCESSORIES ACCURATELY. USE WHITE VASELINE OIL (OR SIMILAR PRODUCTS) TO PROTECT ALL THE MACHINE'S ELEMENTS. THESE PRODUCTS, MAINLY MADE UP OF OILY AND DETERGENT SUBSTANCES, AND NOW AVAILABLE IN SPRAY CYLINDERS FOR EASY APPLICANT, BESIDES GIVING A GLOSSY ASPECT TO THE ALUMINIUM MAGNESTISM ALLOY, PREVENT MOISTURE...
- Page 9 380V/50HZ 380V/50HZ...
- Page 10 TT-F60 Part Name Pusher Bolt Handlebar Hopper Disc Selective disc Umbrella bolt Rubber Gasket On-off switch Screw Body Hopper lid spindle Proximity detector Strapped wheel Motor support Motor Bottom base Cross member Head screw set Small feeder hopper Spring Spindle Locking handle Locking bolt Hook...
- Page 11 TT-F65 Part Name Pusher Handlebar Bracket Hopper Disc Selective disc Umbrella bolt Rubber Gasket On-off switch Screw Body Hopper lid spindle Proximity detectort Strapped wheel Motor support Motor Bottom base Cross member Head screw set Small feeder hopper Spring Spindle...
